Assembly Instructions
For more information contact our team: service.ec@foagroup.com
CM3752T-7PK
ASSEMBLY RATING
Tools Required For Assembly:
The Assembly Rating is a 5-point system that
Wrench
shows the degree of effort needed in
(Included)
assembling a specific product (with 1 being
Allen Wrench
easy and 5 being difficult). For some
(Included)
products, two persons are recommended.
Phillips Screwdriver
(Not Included)
DIFFICULT
EASY
2 PERSONS RECOMMENDED
Page 1 of 7
Rev: 18-06-19
Advertisement
Table of Contents
Related Manuals for Furniture of America CM3752T-7PK
Summary of Contents for Furniture of America CM3752T-7PK
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM3752T-7PK ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that Wrench shows the degree of effort needed in (Included) assembling a specific product (with 1 being Allen Wrench easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 7...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #A x 8pcs Table Top Bolt Ø5/16" x 2-1/2'' #B x 8pcs #2 x 4pcs Spring Washer Ø5/16"...
- Page 4 #A x 8pcs #B x 8pcs #C x 8pcs Align legs (#2) to the table top (#1), then secure by using bolts (#A) with washers (#B,C). ASSEMBLY IS COMPLETED Page 4 of 7...
- Page 5 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc x 6 #A x 4pcs x 6 Chair Back Bolt Ø1/4" x 3" #2 x 1pc x 6 #B x 4pcs x 6 Bolt Ø1/4"...
- Page 6 Align seat frame (#3) to the holes of the chair back (#1), then secure the middle two holes of the seat frame (#3) to the chair back (#1) by using bolts (#C) with washers (#D,E). #C x 2pcs #D x 2pcs #E x 2pcs DO NOT FULLY TIGHTEN ALL BOLTS UNTIL CHAIR ASSEMBLY IS...
- Page 7 Align front legs (#4) to the holes of the seat frame (#3), then secure by using bolts (#B) with washers (#D,E). #B x 4pcs #D x 4pcs #E x 4pcs Align seat cushion (#2) to the seat frame (#3), then secure by using screws (#G). #G x 6pcs Page 7 of 7...
