- Page 1 OPERATION MANUAL PNEUMATIC BLIND RIVETS SETTING TOOL E-500RP ESSENTIAL RANGE Ø Ø ALUMINIUM - STEEL - STAINLESS STEEL...
- Page 2 TOOL CAPACITY blind rivets 3.0/3.2mm – 4.0mm – 4.8/5.0mm standard TOOL SPECIFICATIONS Air supply pressure: 0.5Mpa ~ 0.7Mpa Output traction power: 10,300 N ~ 14,420 N Stroke: 19 mm Net weight: 1.42 kgs E-500RP / User manual...
- Page 3 4) The air power of sucking the rest mandrel can be adjusted bigger or smaller, by the knob on back of the tool visible when the mandrel collector removed: 5) On the air adaptor hose (#54) equipped for this tool, there is a sliding switch for pause the air supply. To switch off for saving air. E-500RP / User manual...
-
Page 4: Tool Maintenance
To connect the tool with air supply, to pull the tool trigger (#49) 6 or 7 times, then loosen the screw (#11), let the extra air leaking out, then screw on the screw (#11) tight again. E-500RP / User manual... - Page 5 To put the pusher spring (#6) (#3), be sure the 3 jaws are seated in it correctly in onto the assembly pusher (#5), and insert it the position. back to the tool where assembly oil cylinder (#13) located. E-500RP / User manual...
-
Page 6: Troubles Shooting
• Mandrel release sucking power, ref. TOOL OPERATION Rest mandrel can not be power not sufficient section 4 sucked into mandrel collector properly • Air supply with low pressure • Increase air supply pressure within the specification range. E-500RP / User manual... - Page 7 TOOL EXPLOSIVE ILLUSTRATION E-500RP / User manual...
-
Page 8: Warranty Conditions
FRANCE Tél.: +33(0) 320 329 818 Declares hereby that the following product : Manual pneumatic hydraulic blind rivet setting tool type E-500RP Complies with the following relevant conditions : EC Machinery Directive 2006/42/EC Annex I If the machine is modified without our knowledge and consent, this EC Declaration of... - Page 9 28 rue Paul Dubrule - 59810 Lesquin - FRANCE...
