OPERATION MANUAL
PNEUMATIC BLIND
RIVETS SETTING TOOL
E-649RP
ESSENTIAL RANGE
4.8
6.4
-
Ø
mm
Ø
ALUMINIUM - STEEL - STAINLESS STEEL
mm

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E-649RP and is the answer not in the manual?

Questions and answers

Summary of Contents for Scell-it E-649RP

  • Page 1 OPERATION MANUAL PNEUMATIC BLIND RIVETS SETTING TOOL E-649RP ESSENTIAL RANGE Ø Ø ALUMINIUM - STEEL - STAINLESS STEEL...
  • Page 2 Blind structural rivets Monobolts / Interlok or equivalent countersunk head or standard blind rivets 4.8mm – nosepiece P/3.3 art. code P03147-00 Blind structural rivets Monobolts / Interlok or equivalent countersunk head or standard blind rivets 6.4mm – nosepiece L/4.3 art. code P03146-00 E-649RP / User manual...
  • Page 3 4) The air power of sucking the rest mandrel can be adjusted bigger or smaller, by the knob on back of the tool visible when the mandrel collector removed: 5) On the air adaptor hose (#51) equipped for this tool, there is a sliding switch for pause the air supply. To switch off for saving air. E-649RP / User manual...
  • Page 4: Tool Maintenance

    To connect the tool with air supply, to pull the tool trigger (#46) 6 or 7 times, then loosen the screw (#11), let the extra air leaking out, then screw on the screw (#11) tight again. E-649RP / User manual...
  • Page 5 To put the pusher spring (#6) (#3), be sure the 3 jaws are seated in it correctly in onto the assembly pusher (#5), and insert it the position. back to the tool where assembly oil cylinder (#13) located. E-649RP / User manual...
  • Page 6: Troubles Shooting

    • Mandrel release sucking power, ref. TOOL OPERATION Rest mandrel can not be power not sufficient section 4 sucked into mandrel collector properly • Air supply with low pressure • Increase air supply pressure within the specification range. E-649RP / User manual...
  • Page 7 TOOL EXPLOSIVE ILLUSTRATION E-649RP / User manual...
  • Page 8: Warranty Conditions

    FRANCE Tél.: +33(0) 320 329 818 Declares hereby that the following product : Manual pneumatic hydraulic blind rivet setting tool type E-649RP Complies with the following relevant conditions : EC Machinery Directive 2006/42/EC Annex I If the machine is modified without our knowledge and consent, this EC Declaration of...
  • Page 9 Rivets de structure type Monobolts / Interlok ou équivalent, tête fraisée ou rivets standards diamètre 4,8mm – nez P/3.3 art. code P03147-00 Rivets de structure type Monobolts / Interlok ou équivalent, tête fraisée ou rivets standards diamètre 6,4mm – nez L/4.3 art. code P03146-00 E-649RP / Mode d’emploi...
  • Page 10: Avant Toute Utilisation

    (#25) régulièrement pour un bon fonctionnement de l’outil. 4) Vous pouvez régler la puissance à l’aide du bouton situé à l’arrière de l’outil. 5) Vous pouvez également suspendre l’alimentation en air (#51) en faisant coulisser la bague d’ouverture/fermeture du circuit d’alimentation. E-649RP / Mode d’emploi...
  • Page 11 (#13) lorsque vous le remplissiez. Il faut donc libérer l’air de l’outil. Connectez l’outil à l’alimentation d’air, appuyez sur la gâchette (#46) de l’outil 6 ou 7 fois, puis desserrez la vis (#11), laissez s’échapper l’air supplémentaire, puis revissez à nouveau la vis (#11) : E-649RP / Mode d’emploi...
  • Page 12 (#6) sur la tige serrage (#3) et assurez-vous qu’ils soient bien d’assemble (#5), et insérer cet ensemble dans positionnés comme sur l’outil au niveau de la partie cylindrique huilée le schéma ci-dessous : (#13) : E-649RP / Mode d’emploi...
  • Page 13 • La puissance d’aspiration • Augmentez la puissance La tige du rivet n’est pas n’est pas suffisante ; d’aspiration aspirée correctement dans le • La pression de l’air est trop • Augmenter la pression de bol récupérateur. basse. l’air E-649RP / Mode d’emploi...
  • Page 14: Vue Éclatée

    VUE ÉCLATÉE E-649RP / Mode d’emploi...
  • Page 15: Conditions De Garantie

    FRANCE Tél.: +33(0) 320 329 818 Déclare par la présente que le produit suivant : Riveteuse pneumatique hydraulique pour rivets de structure type E-649RP Conforme aux conditions suivantes : Directives européennes sur l’outillage 2006/42/CE, Annexe I En cas de modifications sur la machine à notre insu et sans notre consentement, cette déclaration de conformité...
  • Page 16 Nit strukturalny Monobolts / Interlok lub odpowiednik z kołnierzem stożkowym lub standardowy nit zrywalny 4.8mm – nosek P/3.3 art. nr P03147-00 Nit strukturalny Monobolts / Interlok lub odpowiednik z kołnierzem stożkowym lub standardowy nit zrywalny 6.4mm – nosek L/4.3 art. nr P03146-00 E-649RP / Instrukcja obsługi...
  • Page 17: Rozpoczęcie Pracy

    4) Moc zasysania powietrza można regulować, za pomocą pokrętła z tyłu narzędzia widocznego po zdjęciu pojemnika na trzpienie. 5) Wąż adaptera powietrza (# 51) wyposażony jest w przesuwny przełącznik do wstrzymania dopływu powietrza. Aby móc oszczędzać powietrze. E-649RP / Instrukcja obsługi...
  • Page 18 Dodatkowe powietrze musi zostać uwolnione z narzędzia. Podłącz narzędzie do dopływu powietrza, pociągnij za spust (#46) narzędzia 6 lub 7 razy, a następnie poluzuj śrubę (#11), wypuść dodatkowe powietrze, a następnie ponownie mocno dokręć śrubę (#11). E-649RP / Instrukcja obsługi...
  • Page 19 Umieść sprężynę w tulei zaciskowej (# 3), upewnij się, że szczęki są popychacza (# 6) na popychaczu montażowym prawidłowo osadzone. (# 5), i włóż z powrotem do narzędzia, w którym znajduje się cylinder oleju montażowego (# 13). E-649RP / Instrukcja obsługi...
  • Page 20 • Niewystarczająca moc trzpienia, patrz OBSŁUGA zasysania trzpienia NARZĘDZIA PODCZAS Trzpień nitu nie może być NITOWANIA sekcja 4 prawidłowo zassany do • Zbyt niskie ciśnienie dopływu pojemnika na trzpienie powietrza • Zwiększyć ciśnienie dopływu powietrza zgodnie ze specyfikacją E-649RP / Instrukcja obsługi...
  • Page 21 SCHEMAT NARZĘDZIA E-649RP / Instrukcja obsługi...
  • Page 22: Warunki Gwarancji

    FRANCE Tél.: +33(0) 320 329 818 Oświadcza, że następujący produkt : Ręczne pneumatyczno-hydrauliczne narzędzie do osadzania nitów typu E-649RP Jest zgodne z następującymi odpowiednimi warunkami : Dyrektywa maszynowa WE 2006/42/WE załącznik I Jeśli urządzenie zostanie zmodyfikowane bez naszej wiedzy i zgody, niniejsza Deklaracja Zgodności WE zostanie unieważniona.
  • Page 23 4,8 mm - násadka P/3.3 - obj.kód P03147-00 Strukturální/pevnostní nýty Monobolt / Interlok nebo ekvivalent - zapuštěná hlava nebo standardní trhací nýty průměr 6,4 mm - násadka L/4.3 - obj.kód P03146-00 E-649RP / NÁVOD K POUŽITÍ...
  • Page 24: Začátek Práce

    4) Výkon sání (pro transport zbytku trnu) lze regulovat otočným kolečkem na zadní straně nástroje (viditelným po odtranění sběrače trnů). 5) Na konektoru hadice přívodu vzduchu (# 51), která je standardně dodávána, je k dispozici posuvný spínač pro pozastavení přívodu vzduchu. Použitím docílíte úsporu stlačeného vzduchu. E-649RP / NÁVOD K POUŽITÍ...
  • Page 25 Pak je třeba nástroj odvzdušnit. Pro odvzdušnění - připojte nástroj k přívodu vzduchu, zmáčkněte spoušť nástroje (# 46) 6 - 7 krát, poté povolte šroub (# 11), nechte uniknout přebytečný vzduch a poté šroub (# 11) opět utáhněte. E-649RP / NÁVOD K POUŽITÍ...
  • Page 26 Vložte tlačnou se ujistěte, že jsou všechny čelisti usazeny ve pružinu (# 6) na přítlačný kolík (# 5) a vložte zpět správné poloze. do nástroje - kde je umístěn hydraulický válec (# 13). E-649RP / NÁVOD K POUŽITÍ...
  • Page 27: Odstraňování Závad

    NASTAVENÍ NÁSTROJE PRO Zbytek trnu nelze • nedostatečná síla přisávání APLIKACI TRHACÍCH NÝTŮ - bod správně nasát do • ízký tlak přívodu vzduchu sběrače trnů • Zvyšte tlak vzduchu - v rozsahu dle specifikace nástroje E-649RP / NÁVOD K POUŽITÍ...
  • Page 28 ROZLOŽENÝ POHLED NA NÁSTROJ E-649RP / NÁVOD K POUŽITÍ...
  • Page 29: Podmínky Záruky

    FRANCE Tél.: +33(0) 320 329 818 Prohlašuje, že následující produkt : Pneumaticko hydraulické nářadí pro trhací nýty typ E-649RP Splňuje následující relevantní podmínky : Směrnice EC o strojních zařízeních 2006/42 / EC Příloha I Pokud je nástroj upraven bez naši vědomosti nebo souhlasu, pozbývá toto EC ptohlášení...
  • Page 30: Istruzioni Generali Di Sicurezza

    4,8 mm – ugello P/3.3, codice articolo P03147-00 Rivetti ciechi strutturali Monobolt / Interlok o rivetti ciechi equivalenti standard o a testa svasata 6,4 mm – ugello L/4.3 art. code P03146-00 E-649RP / MANUALE UTENTE...
  • Page 31: Operazioni Preliminari

    4) È possibile regolare l’alimentazione dell’aria di aspirazione del chiodo tramite la manopola sulla parte posteriore dell’utensile visibile quando si smonta il canestro raccolta sfridi. 5) Sul tubo adattatore aria (51): è presente un interruttore a scorrimento per mettere in pausa l’alimentazione dell’aria. Serve per ridurre il consumo di aria. E-649RP / MANUALE UTENTE...
  • Page 32: Manutenzione

    (13) durante il rabbocco. È necessario eliminare l’aria in eccesso presente. Collegare l’utensile all’alimentazione della aria, premere il pulsante (48) dell’utensile per 6/7 volte, svitare la vite (11), far fuoriuscire l’aria in eccesso presente e riavvitare la vite (11). E-649RP / MANUALE UTENTE...
  • Page 33 7) Montare il kit di 3 morsetti (4) sul cono porta Montare la molla (6) sullo spintore (5) e morsetti (3) e controllare che i 3 morsetti siano reinserirlo nell’utensile dove si trova il cilindro correttamente in posizione. oleodinamico (13). E-649RP / MANUALE UTENTE...
  • Page 34 FUNZIONAMENTO Il chiodo del rivetto non viene insufficiente DELL’UTENSILE sezione 4 aspirato correttamente nel • Pressione alimentazione aria canestro raccolta sfridi • Aumentare la pressione bassa di alimentazione in base al range indicato nelle specifiche tecniche. E-649RP / MANUALE UTENTE...
  • Page 35 VISTA ESPLOSA DELL’UTENSILE E-649RP / MANUALE UTENTE...
  • Page 36: Condizioni Di Garanzia

    FRANCE Tél.: +33(0) 320 329 818 Dichiara che il seguente prodotto: Rivettatrice oleo-pneumatica manuale tipo E-649RP È conforme alle seguenti direttive: Direttiva Macchine 2006/42/CE Allegato I Se la macchina viene modificata a nostra insaputa e senza il nostro consenso, questa Dichiarazione di Conformità...
  • Page 37 E-649RP...
  • Page 38 E-649RP...
  • Page 39 E-649RP...
  • Page 40 28 rue Paul Dubrule - 59810 Lesquin - FRANCE...
