PASSWORD ： OFF
：
SETTING
BACK EXIT

PASSWORD: Enable this function here so that you set password is valid. This function is on by
default after you set password.

SETTING: Click the confirm button to go to the password setup interface. Please use the left/right
button to set the value and then click the confirm button to confirm current option. Move the cursor
to the SAVE button and then click the confirm button to save current setup. Click the BACK button
to go to the previous menu.

BACK: Go back to the previous menu.

EXIT: Log out the system menu.
If you have forgot your password. After three times of login failure, system may pop up an 8-digit
internal code. Please contact our technical engineer for help.
3.4.4.10 Heater Control
Move the cursor to highlight HEATER CONTROL button and then click confirm button. You can go to the
th
4 menu.

HEATER CONTROL: It is to set temperature control mode. It includes three modes: auto/normal
open/normal close. Please use the left/right button on the keyboard or in the speed dome terminal
menu to set.

OPEN TEMPERATUREP: This function is on when the heater control mode is auto. It is for you to
set temperature to enable the heater.

CLOSE TEMPERATURE: This function is on when the heater control mode is auto. It is for you to
set temperature to disable the heater.

BACK: Go back to the previous menu.

EXIT: Log out the system menu.
3.4.5

Alarm Setting

Move the cursor to highlight ALARM SETTING button and then click confirm button.
Figure 3-32 Password setting
HEATER CONTROL
OPEN TEMPERATURE
COLSE TEMPERATURE
BACK
Figure 3-33 Heater control
ALARM NO
ACTION
PARAMETER
CONTACT
RELAY OUT
RESET DELAY
SAVE
BACK
Figure 3-34 Alarm setting
PASSWORD：
1 2 3 4 5
6 7 8 9 0
→ SAVE BACK
：AUTO
：03
： 12
EXIT
：1
：NONE
：NONE
：N/O
：OFF
：3S
EXIT
