CAMERE RESTART: Move the cursor to current item and then click confirm button to reboot the
camera.

BACK: Go back to previous menu.

EXIT: Log out system menu.
3.4.3.1 White Balance Setup
Move the cursor to WHITE BALANCE MODE and then click confirm button, you can go to the submenu.

WHITE BALANCE MODE: Set white balance adjustment mode. There are several modes such as
auto, ATW, indoor, outdoor, and manual and etc. Please use the left/right button on the keyboard or
in the speed dome terminal menu to set.

R GAIN: Before you set R GAIN option, please note the mode is manual. Please use the left/right
button on the keyboard or in the speed dome terminal menu to set.

B GAIN: Before you set B GAIN option, please note the mode is manual. Please use the left/right
button on the keyboard or in the speed dome terminal menu to set.

BACK: Go back to previous menu.

EXIT: Log out system menu.
3.4.3.2 Exposure Setting
AE MODE
GAIN SETTING
SHUTTER
IRIS SETTING
EXPOSURE COMP
SLOW SHUTTER
NEXT PAGE
BACK
Figure 3-11 Exposure setting
HIGH LIGHT REUDCE
AE RECOVERY
BACK
Figure 3-13 Next page

AE MODE: Here you can set the camera exposure mode. It includes: auto/manual/AV (iris
priority)/TV (shutter priority). Please use the left/right button on the keyboard or in the speed dome
terminal menu to set.
o
Auto: The gain, iris, shutter are in auto mode.
o
Manual: You need to set the gain setting, shutter, and iris setting manually.
o
Iris Priority (AV): It is for you to set the iris manually. Gain and shutter are in auto mode.
o
Shutter Priority (TV): It is for you to set the shutter manually, Gain and iris are in auto
mode.

GAIN SETTING: It is to set camera gain. Please use the left/right button on the keyboard or in the
speed dome terminal menu to set.

SHUTTER: It is to set camera shutter. Please use the left/right button on the keyboard or in the
speed dome terminal menu to set.
： AUTO
WB MODE
： 50
R GAIN
： 50
B GAIN
BACK
Figure 3-10 White balance
：AUTO
：2
：1/50
：4
：8
：ON
EXIT
：OFF
：15M
EXIT
EXIT
AGC GAIN LIMIT
SLOW SHUTTER LIMIT
NOISE REDUCTION
3D NOISE REDUCTION
BLC
WDR SETTING
NEXT PAGE
BACK
Figure 3-12 Next page
11
：2
：1/25
：3
：OFF
：OFF
