3.4.3.4 Day/Night Setting
Move the cursor to DAY/NIGHT SETTING and then click confirm button, you can go to the submenu.

DAY/NIGHT: It is to set camera day/night switch mode. Please use the left/right button on the
keyboard or in the speed dome terminal menu to set.

THRESHOLD: The speed dome can switch the day/night mode when it reached the threshold you
set here.

DAY/NIGHT MODE: It is to set day/night switch mode. Click left/right button to set.

SAVE: This button is for DAY TIME and NIGHT TIME setup. After you set the day time (or night
time), you need to move the cursor here and then click confirm button to save current time setup.
For other setups, you do not need to use this button.

BACK: Go back to previous menu.

EXIT: Log out system menu.
3.4.3.5 Focus Setting

FOCUS MODE: It is to set the camera focus mode. It includes several modes such as auto, manual,
semiautomatic. Please use the left/right button on the keyboard or in the speed dome terminal menu
to set.

FOCUS LIMIT: It is to set the camera focus limit. Please use the left/right button on the keyboard or
in the speed dome terminal menu to set.

AF SENSITIVITY: It is to set the camera focus sensitivity. Please use the left/right button on the
keyboard or in the speed dome terminal menu to set.

IR CORRECTION: It is to set the camera IR light focus correction. Please use the left/right button
on the keyboard or in the speed dome terminal menu to set.

BACK: Go back to previous menu.

EXIT: Log out system menu.
3.4.3.6 Image Adjust
Move the cursor to IMAGE ADJUST and then click confirm button to go to the submenu to set.
DAY/NIGHT
THRESHOLD
DAY/NIGHT TYPE
SAVE
BACK
Figure 3-15 Day/night setting
FOCUS MODE
FOCUS LIMIT
AF SENSITIVITY
IR CORRECTION
BACK
Figure 3-16 Focus setting
HUE
BRIGHTNESS
SATURATION
CHROMA SUPPRESS
GAMMA
CONTRAST
STYLE
BACK
Figure 3-17 Image Adjust
：AUTO
： 4
：ELECTRONIC
EXIT
： AUTO
：10CM
： NORMAL
： ATUO
EXIT
：50
：50
：50
：01
：50
：50
：STANDARD
EXIT
