- Page 1 OUTDOOR SPA SPA-318 PROGRAMMING INSTRUCTIONS...
-
Page 2: Function Summary
RAMMING INSTRUCTIONS 1. Illustration to buttons TEMP HEAT OZONE LOCKED VOL+ OZONE OPEN PUMP2 LIGHT BLOWER PUMP1 PUMP2 PUMP3 HOUR HEAT CLOSE PUMP3 ON/OFF Fig﹒1：Sketch map of big massage bathtub ON/OFF “ ” “ ” Frequency up- searching / Minute On/ Off RADIO HOUR... -
Page 3: Lock Operation
(2) Display and set of 12 hours am/ pm model。 (3) Circulation cleaning。 (4) CD frequency input。Display of radio frequency and storage for 10 channels。 (5) Display and 87 grades adjustment of volume。 (6) Infrared remote control。 (7) one ozone set and one bottom light。 (8) Frozen preventing control。... - Page 4 (4) Operation to circulation-cleaning settings： Circulation-cleaning only works one times every day。 The LCD can show clearly about whether circulation-cleaning setting is startup or not。See following Fig﹒ 5-6。 Fig﹒5： Circulation-cleaning off Fig﹒6：Circulation-cleaning on Circulation-cleaning setting must be in the “Power off” status and the LCD display “---” 。 PUMP3 1）...
- Page 5 the setting will be finished VOL+ 3） 、Press“ ” to continual time setting of Circulation-cleaning， it will show the minimum continue time is 1 minutes on the LCD， and this time will not flash。 It will add 5 minutes by pressing “ ”...
- Page 6 the setting will be finished Pre-heating setting is in the “Power off” status and the LCD display “---” 。 HEAT ” ，and enter to Pre-heating setting status, and the LCD flashes of “ON OFF”. 1、 Press“ CLOSE OPEN ” ，can turn on the pre-heating setting ( by opposite, if press“ ”, it will turn off the 2、...
- Page 7 HEAT finished。 the pre-heating will be turned off automatically by system or by pressing the “ ” or ON/OFF “ ” key intentionally。 *** Notice *** 1、 When setting temperature is lower or equal water temperature，Even the Pre-heating is working but the circulation PUMP and HEATER are not working。...
- Page 8 PUMP3 Fig﹒11： Radio frequency is 105.2 MHZ，Save the present frequency to channel 3 (Save channel) or Exchange the frequency form channel 3 to the present (Searching channel) AUDIO Ⅰ)、Key is the ON/OFF key for radio and CD。and it is only available in the status of power on. The first pressing is turning on the radio，...
- Page 9 3)、For example：if the temperature is set at 35℃， when the water temperature reaches or exceeds 36 ℃， the heater will be turned off automatically and the circulation pump will stop after 5 second（If PUMP3 is turn off） 。 However， when the water temperature reach or lower than 34℃， the heater will start up。 4)、...
- Page 12 Layout setting 220VAC SPK-L PUMP1 SPK-R HEAT OZONE HEAT DVD/TV BLOWER PUMP3 PUMP2 LIGHT SENSOR/LEAD-IN POWER INPUT 100A switch Creepage protector...
