code code Setting name
9 Heating and cooling set point ranges
00 Heating set point upper limit
01 Heating set point lower limit
02 Cooling set point upper limit
03 Cooling set point lower limit
(b)
04 Overshoot setting
Automatic set back function
05 Set back operation
06 Set back operation start time
07 Set back operation stop time
08 Leaving water set back value
C Setup on EKRP1HB digital I/O PCB
00 Solar priority mode setting
01 Alarm output logic
02 X1-X2 function: Bivalent operation status or
additional external backup heater
03 Bivalent ON temperature or additional external
backup heater temperature
04 Bivalent hysteresis or additional external backup
heater hysteresis
05 Not applicable.
d Benefit kWh rate power supply/local shift value weather dependent
00 Switching off heaters
01 Unit connection to benefit kWh rate power supply
02 Not applicable. Do not change the default value.
03 Local shift value weather dependent
04 Not applicable.
05 Pump operation forced off or permitted during
backup heater is forced off at benefit kWh rate
power supply ([d-00]=0 or 1)
06 Not applicable.
E Unit information readout
00 Software version
01 EEPROM version
02 Unit model identification. Do not change the default
value.
03 Liquid refrigerant temperature
04 Inlet water temperature
RKHBH/X008BB
Indoor unit for air to water heat pump system
4PW62574-1 – 10.2010
Installer setting at variance with default value
Date Value Date
Default
Value value Range
55 37~55
25 15~37
22 18~22
5 5~18
1 1~4
0 (OFF) 0/1
23:00 0:00~23:00
5:00 0:00~23:00
2 0~10
0 0/1
0 0/1
0 0/1/2
0 –25~25
3 2~10
— —
0 0/1/2/3
0 (OFF) 0/1/2
0 (OFF) —
0 (OFF) 0/1/2/3/4
— —
0 (forced
0/1
off)
— —
Read only —
Read only —
depending
—
on model
Read only —
Read only —
Step Unit
1 °C
1 °C
1 °C
1 °C
1 °C
1 —
1:00 hour
1:00 hour
1 °C
1 —
1 —
1 —
1 °C
1 °C
— —
1 —
1 —
— —
1 —
— —
1 —
— —
— —
— —
— —
1 °C
1 °C
