Preliminary Technical Data
Reference Part Type
Designator
R2 1k
R3 1k
R4 1k
R5 15R
R6 15R
R7 0r
R8 0r
R9 1k
R10 1k
R11 1k
R12 1k
R13 0r
R15 51r
R16 0r
R18 51r
R19 51r
R20 51r
R22 0r
R23 1k
R24 0r
R25 0r
R28 0r
R30 0r
R31 51r
R32 51r
R33 10k
R34 0r
R35 10k
R36 0r
R37 0r
R38 0r
R39 0r
R40 10k
R42 10k
R43 1k
S1 SW-PUSH-SMD
SCLK TESTPOINT
SDI TESTPOINT
SDO TESTPOINT
SL1 2 Way solder Bridge
SL2 2 Way solder Bridge
SL3 2 Way solder Bridge
SL4 2 Way solder Bridge
SL5 4-Way Solder Link
SL6 2 Way solder Bridge
SL8 4-way Solder link
SL9 2 Way solder Bridge
SL11 4-Way Solder Link
U1 AD7767/67-1/67-2
U2 ADA4841-1
U3 ADA4841-1
U4 ADM6711
Reference Designator
0.10%, 0603, Precision SMD Resistor
0.10%, 0603, Precision SMD Resistor
0.10%, 0603, Precision SMD Resistor
1%, 0603, SMD Resistor
1%, 0603, SMD Resistor
1%, 0603, SMD Resistor
1%, 0402, SMD Resistor
0.10%, 0603, Precision SMD Resistor
0.10%, 0603, Precision SMD Resistor
0.10%, 0603, Precision SMD Resistor
0.10%, 0603, Precision SMD Resistor
1%, 0603, SMD Resistor
1%, 0805, SMD Resistor
1%, 0603, SMD Resistor
1%, 0805, SMD Resistor
1%, 0805, SMD Resistor
1%, 0805, SMD Resistor
1%, 0603, SMD Resistor
0.10%, 0603, Precision SMD Resistor
1%, 0402, SMD Resistor
1%,0603, SMD Resistor
1%,0603, SMD Resistor
1%,0603, SMD Resistor
0.10%, 0603, SMD Resistor
0.10%, 0603, SMD Resistor
1%, 0603, SMD Resisitor
1%,0603, SMD Resistor
1%, 0603, SMD Resisitor
1%,0603, SMD Resistor
1%,0603, SMD Resistor
1%,0603, SMD Resistor
1%, 0402, SMD Resistor
1%, 0603, SMD Resisitor
1%, 0603, SMD Resisitor
0.10%, 0603, Precision SMD Resistor
SMD Push Button Switch (sealed 6mm x 6mm)
Red Testpoint
Red Testpoint
Red Testpoint
Solder to Link A
Solder to Link A
Solder to Link B
Solder to Link A
Solder to Link C
Solder to Link B
Solder to link C
Solder to Link B
Solder to Link B
ADC (AD7767BRUZ, AD7767-1BRUZ or
AD7767-2BRUZ)
SINGLE SUPPLY OP-AMP
SINGLE SUPPLY OP-AMP
Reset Generator
Rev. PrB | Page 23 of 24
EVAL-AD7766/66-1/66-2
Manufacturer Supplier No.
Holsworthy (Tyco) FEC 4628846
Holsworthy (Tyco) FEC 4628846
Holsworthy (Tyco) FEC 4628846
Multicomp FEC 9330631
Multicomp FEC 9330631
Multicomp FEC 9331662
Multicomp Do not insert
Holsworthy (Tyco) FEC 4628846
Holsworthy (Tyco) FEC 4628846
Holsworthy (Tyco) FEC 4628846
Holsworthy (Tyco) FEC 4628846
Multicomp FEC 9331662
Multicomp FEC 9333355
Multicomp FEC 9331662
Multicomp FEC 9333355
Multicomp FEC 9333355
Multicomp FEC 9333355
Multicomp FEC 9331662
Holsworthy (Tyco) FEC 4628846
Multicomp Do not insert
Multicomp FEC 9331662
Multicomp FEC 9331662
Multicomp FEC 9331662
Holsworthy (Tyco) FEC 4627623
Holsworthy (Tyco) FEC 4627623
Multicomp FEC 9330399
Multicomp FEC 9331662
Multicomp FEC 9330399
Multicomp FEC 9331662
Multicomp FEC 9331662
Multicomp FEC 9331662
Multicomp Do not insert
Multicomp FEC 9330399
Multicomp FEC 9330399
Holsworthy (Tyco) FEC 4628846
Omron FEC 177-807
Vero FEC 8731144
Vero FEC 8731144
Vero FEC 8731144
n/a n/a
n/a n/a
n/a n/a
n/a n/a
n/a n/a
n/a n/a
n/a n/a
n/a n/a
n/a n/a
Analog Devices AD7767BRUZ*
Analog Devices ADA4841-1YRZ
Analog Devices ADA4841-1YRZ
Analog Devices ADM6711ZAKSZ
