Analog Devices EVAL-AD7766EDZ Manual page 21

Preliminary Technical Data
Reference Part Type
Designator
C45 0.1uF
C46 1nF
C47 0.1uF
C48 0.1uF
C49 0.1uF
C50 0.1uF
C51 10uF
C52 10uF
C53 0.1uF
C54 0.1uF
C55 10uF
C56 10uF
C57 10uF
C59 10uF
C60 100pF
C61 0.1uF
C62 0.1uF
C63 10uF
C64 10uF
C67 10uF
C68 100pF
C69 1nF
C72 10uF
C73 4.7uF
C74 100pF
C75 0.1uF
C77 10nF
C78 10nF
C79 10uF
C80 10uF
C81 100pF
C85 10uF
C86 10uF
C87 10uF
C88 0.1uF
C89 10uF
C90 1nF
C91 100pF
C92 0.1uF
C93 100pF
C94 100pF
C95 10uF
C96 0.1uF
C97 0.1uF
C98 10uF
C99 10nF
C100 10nF
C101 2.2nF
C102 2.2nF
C103 10uF
C104 0.1uF
C108 10uF
Reference Designator
16V X7R Multilayer Ceramic Capacitor
50V X7R Multilayer Ceramic Capacitor
16V X7R Multilayer Ceramic Capacitor
16V X7R Multilayer Ceramic Capacitor
16V X7R Multilayer Ceramic Capacitor
16V X7R Multilayer Ceramic Capacitor
20v Tantalum Capacitor
20v Tantalum Capacitor
16V X7R Multilayer Ceramic Capacitor
16V X7R Multilayer Ceramic Capacitor
20v Tantalum Capacitor
20v Tantalum Capacitor
20V Tantalum Capacitor
20V Tantalum Capacitor
50V NPO Multilayer Ceramic Capacitor
16V X7R Multilayer Ceramic Capacitor
16V X7R Multilayer Ceramic Capacitor
20V Tantalum Capacitor
20V Tantalum Capacitor
20V Tantalum Capacitor
50V NPO Multilayer Ceramic Capacitor
50V X7R Multilayer Ceramic Capacitor
20V Tantalum Capacitor
SMD Tantalum Capacitor
50V X7R Multilayer Ceramic Capacitor
16V X7R Multilayer Ceramic Capacitor
50V X7R Multilayer Ceramic Capacitor
50V X7R Multilayer Ceramic Capacitor
20V Tantalum Capacitor
20v Tantalum Capacitor
50V NPO Multilayer Ceramic Capacitor
20V Tantalum Capacitor
20V Tantalum Capacitor
20v Tantalum Capacitor
16V X7R Multilayer Ceramic Capacitor
20v Tantalum Capacitor
50V X7R Multilayer Ceramic Capacitor
50V X7R Multilayer Ceramic Capacitor
16V X7R Multilayer Ceramic Capacitor
50V NPO Multilayer Ceramic Capacitor
50V NPO Multilayer Ceramic Capacitor
20v Tantalum Capacitor
16V X7R Multilayer Ceramic Capacitor
16V X7R Multilayer Ceramic Capacitor
20v Tantalum Capacitor
50V X7R Multilayer Ceramic Capacitor
50V X7R Multilayer Ceramic Capacitor
50V X7R Multilayer Ceramic Capacitor
50V X7R Multilayer Ceramic Capacitor
20V Tantalum Capacitor
16V X7R Multilayer Ceramic Capacitor
20V Tantalum Capacitor
Rev. PrB | Page 21 of 24
EVAL-AD7766/66-1/66-2
Manufacturer Supplier No.
Epcos FEC 753567
Phycomp FEC 722170
Epcos FEC 753567
Epcos FEC 753567
Epcos FEC 753567
Epcos FEC 753567
AVX FEC 197-427
AVX FEC 197-427
Epcos FEC 753567
Epcos FEC 753567
AVX Do not insert
AVX Do not insert
AVX FEC 197427
AVX FEC 197427
Multicomp FEC 9406115
Epcos FEC 753567
Epcos FEC 753567
AVX FEC 197427
AVX FEC 197427
AVX FEC 197427
Multicomp FEC 9406115
Phycomp FEC 722170
AVX FEC 197427
n/a Do not insert
Phycomp FEC 3019329
Epcos FEC 753567
Epcos FEC 753-622
Epcos FEC 753-622
AVX FEC 197427
AVX FEC 197-130
Multicomp FEC 9406115
AVX FEC 197427
AVX FEC 197427
AVX FEC 197-427
Epcos FEC 753567
AVX Do not insert
Phycomp FEC 722170
Phycomp FEC 3019329
Epcos FEC 753567
Multicomp FEC 9406115
Multicomp FEC 9406115
AVX FEC 197-427
Epcos FEC 753567
Epcos FEC 753567
AVX Do not insert
Epcos FEC 753-622
Epcos FEC 753-622
Murata FEC 8819963
Murata FEC 8819963
AVX FEC 197427
Epcos FEC 753567
AVX Do not Insert
