Zamel RTN-01 Operation

OPERATION RANGE
Symbol ROP-01 ROP-02 ROB-01 SRP-02 SRP-03 RWG-01 RWL-01 ROM-01 ROM-10 RDP-01 RTN-01
RNK-02 180 m 200 m 200 m 200 m
RNK-04 180 m 200 m 200 m 200 m
P-256/8 230 m 250 m 250 m 250 m
P-257/4 (2) 180 m 200 m 200 m 200 m
RNM-10 230 m 250 m 250 m 250 m
RNP-01 160 m 180 m 180 m 180 m
RNP-02 160 m 180 m 180 m 180 m
RNL-01 160 m 180 m 180 m no*
RTN-01 200 m 200 m 200 m 200 m
RCR-01 160 m 180 m 180 m no*
RTI-01 160 m 180 m 180 m 180 m
RXM-01 230 m 250 m 250 m 250 m
* 1-channel transmitters do not cooperate with roller blind controllers
CAUTION: The given range concerns open area - an ideal condition without any natural or artificial ob-
stacles. If there are some obstacles between a transmitter and a receiver, it is advisable to decrease the
range according to: wood and plaster: from 5 to 20%, bricks: from 10 to 40%, reinforced concrete: from 40
to 80%, metal: from 90 to 100%, glass: from 10 to 20%, Over- and underground medium and high electrical
power lines, radio and television transmitters, GSM transmitters set close to a device system have also a
negative influence on the range.
200 m 250 m 180 m 250 m 250 m
200 m 250 m 180 m 250 m 250 m
250 m 300 m 200 m 300 m 300 m
200 m 250 m 180 m 250 m 250 m
250 m 300 m 200 m 300 m 300 m
180 m 200 m 160 m 200 m 200 m
180 m 200 m 160 m 200 m 200 m
no* 200 m 160 m 200 m 200 m
200 m 250 m 200 m 250 m 250 m
no* 200 m 160 m 200 m 200 m
180 m 200 m 160 m 200 m 200 m
250 m 300 m 200 m 300 m 300 m
RETRANSMITTER
RTN-01
180 m 250 m
180 m 250 m
230 m 300 m TECHNICAL DATA
180 m 250 m
230 m 300 m
Input rated voltage:
160 m 200 m
Input voltage tolerance:
160 m 200 m
Nominal frequency:
160 m 200 m
Nominal power consumption:
200 m 250 m
160 m 200 m Optic signalling of supply voltage:
160 m 200 m
Maximum load current of socket output:
230 m 300 m
Transmission:
Coding way:
Coding:
Maximum number of transmitters:
Range:
Optic signalling of transmission:
Ambient temperature range:
Operating position:
Casing mounting:
Casing protection degree:
Protection level:
Overvoltage category:
Pollution degree:
Surge voltage:
Dimensions:
Weight:
Reference standard:
230 V AC
-15 ÷ +10 %
50 / 60 Hz
0,45 W
LED green diode
16 A
radio 868,32 MHz
unidirectional
addressing transmission
32
up to 250 m in the open area
LED red diode
-10 ÷ +55 C
o
free
230 V AC socket
IP20 (PN-EN 60529)
II
II
2
1 kV (PN-EN 61000-4-5)
160 x 66 x 90 mm
0,180 kg
PN-ETSI EN 300 220-1,
PN-ETSI EN 300 220-1,
PN-EN 60950, PN-EN 61000
