Knoll DIR10P Installation Instructions

DIR10P Digital Infrared Receiver Specifications:
Specifications
Infrared carrier frequency: 30-60kHz
Indoor reception range:
Outdoor reception range:
Nominal reception angle:
Transmission wire maximum length: 1000' (300m)
Emitter wire requirements: two conductor, minimum 24 gauge
Power requirements:
Dimensions:
Requires 12VDC power supply and emitter.
Warranty
Knoll Systems warrants its products sold in the USA and Canada by authorized
Knoll dealers to be free of defects in materials and workmanship. This warranty
extends for three full years from the date of purchase by the original consumer.
Any products returned to Knoll Systems and found to be defective by Knoll
Systems within the warranty period will be repaired or replaced at Knoll Systems
option, at no charge. Knoll Systems will not be responsible for the actual cost of
installation or removal of the product, nor for any incidental or consequential
damages. Some states do not allow the exclusion or limitation of incidental or
consequential damages, so the above limitation may not apply to you. This
warranty gives you specific legal rights. You may have additional legal rights
that vary from state to state.
Knoll Systems www.knollsystems.com
145 Tyee Drive Point Roberts, WA 98281
12140 Horseshoe Way Richmond BC V7A 4V4
tel (604) 272 4555, fax (604) 272 5595
Made in Canada Knoll Systems All Rights Reserved
150 feet + (45 meters +)
35-50 feet (10-15 meters)
50 degrees off axis
to 200', 22 gauge up to 500'
20 gauge to 1000'
Unregulated 12VDC, 40mA
2-1/2" W x 1-1/8" H x 2-3/4" D
(65 x 28 x 66mm).
DIR10P
Digital Infrared Receiver
Installation Instructions v1.1
Warning: To be installed and/or used in accordance with
appropriate electrical codes and regulations.
Introduction:
Thank you for your
purchase of a Knoll DIR10P digital
infrared receiver. This receiver
features a long indoor usable range
and it can be used in direct sunlight
and near plasma and other TV's. It is
designed to act as a remote receiver
of remote control signals that when passed through a
connection module and emitters, relays remote infrared
commands to equipment in a distant room. It is very similar to
the DIR10 with an added internal processor, so a connection
block is not needed. A single or dual emitter can be connected
to the DIR10P
Features:
• Small tabletop size, available in off white and black
cabinet colors.
• Digital processor included for direct hook up to emitters
without a connection block.
• Will relay almost all remote control types (except some
B & O and Pioneer Elite models).
• Extra emitter wire can be added up to 1000' (300m).
• Requires very little power. Suggest using PS1202 12 vdc.
