Component Balun Specifications:
Models and Dimensions
UR-P3 (in-wall Decora™ version): 4.1"h x 1.4" w x 2.0"d.
UR-V3 (black enclosure): 1.1"h x 2.6"w x 2.8"d (28 x 66 x 71 mm).
US-P3 (in-wall Decora™ version): 4.1"h x 1.4"w x 2.0"d.
US-V3 (black enclosure): 1.1"h x 2.6"w x 2.8"d (28 x 66 x 71 mm).
US3-Hub (black stackable enclosure).
Video Bandwidth: 450 MHz +/- 3 dB.
Video Input: Receive unit: 0.5 V to 2V.
Video Output: Send unit: 0.5 V to 2 V.
Input and Outputs:
Send Unit: three RCA input jacks, one RJ-45 out-jack, one-DC
power input.
Receive Unit: three RCA output jacks, one RJ-45 out-jack.
US3-Hub: Three RCA input jacks, six RJ-45 output jacks, one DC
power input, one input and one output link RJ45 jack.
Power
Send Unit: 12 VDC (one PS1202 power supply will power one
send and one receive and is connected to the send unit only.)
Receive Unit: 12 VDC (from send or hub).
US3-Hub: 15 VDC (one PS1506, included, will power the hub
and up to six receives).
Warranty
Knoll Systems warrants its products sold in the USA and Canada by authorized
Knoll dealers to be free of defects in materials and workmanship. This warranty
extends for three full years from the date of purchase by the original consumer.
Any products returned to Knoll Systems and found to be defective by Knoll
Systems within the warranty period will be repaired or replaced at Knoll Systems
option, at no charge. Knoll Systems will not be responsible for the actual cost of
installation or removal of the product, nor for any incidental or consequential
damages. Some states do not allow the exclusion or limitation of incidental or
consequential damages, so the above limitation may not apply to you. This
warranty gives you specific legal rights. You may have additional legal rights
that vary from state to state.
Knoll Systems www.knollsystems.com
145 Tyee Drive Point Roberts, WA 98281
12140 Horseshoe Way, Richmond BC V7A 4V4
tel (604) 272 4555, fax (604) 272 5595
Made in Canada
Knoll Systems All Rights Reserved
UR-P3 Component Video Receiver
UR-V3 Component Video Receiver
US-P3 Component Video Sender
US-V3 Component Video Sender
Installation Instructions v1.1
Warning: To be installed and/or used in accordance with
appropriate electrical codes and regulations. If you are not sure
about any part of these instructions, consult a qualified
electrician.
Caution: Do not install this product in an electrical junction box
with 110V or higher unless an approved barrier separates the
high and low voltage sections.
Introduction: Thank you for your purchase of a Knoll active
balun system. This system is specifically designed to send a
three wire Pb, Pr, Y component or RGB signal safely down a cat
5 or cat 5e wire up to 500 feet without encountering image
problems. Balun is an acronym for:
BALance – UNbalance
The send module takes a conventional component signal and
balances it (signal is not tied to a ground reference) then sends
it via cat 5 to the receive module (with power from the send
module). The receive module unbalances the component signal
back to its former state. This process does not allow any stray
magnetism of any sort to contaminate the signal while it is
being transported.
Features:
Tabletop box design or Decora™ style available.
Will safely send 480i/p, 720p and 1080i/p signals.
PS1202 power supply required on send side only.
6 output hub available
Mix and match decora style and tabletop style.
