Operating Instructions

Product Clearances

WARNING:
DO NOT PLACE OBJECTS
WITHIN 300mm OF THE
FRONT OF THE HEATER
AND 150mm EITHER SIDE

Single Supply

It is important to be aware of how your Quantum storage heater has been installed electrically. If you Quantum has
only one electrical connection, it must be carefully confi gured to work with your off -peak electricity tariff .
Available fi xed charge times must be manually programmed into the heater to tell it when to charge; no external
timers or contactors are needed. Up-to 4 digital charge times can be set.
If charge times are not programmed into the heater, the default times will be used which are set-up by default to
support dual-supply installations: 00:00 – 00:00 or 24h charge window.
A 24h charge window in a single supply installation will cause the heater to charge continuously,
including times when off -peak electricity is not available, resulting in larger bills.
NOTE:
If electricity tariff charge times have changed, the digital charge times in the heaters settings must be
checked to ensure they match.
250 mm
300 mm
- 8 -
