Altronix eBridge100RM Installation Manual page 4

Fig. 4
100m max.
100m max.
100m max.
100m max.
NetWay8M - Front Panel
Ethernet Switch
––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
Maximum Length of Coax/CAT5 Type vs.
Cable Type Total Power Consumption
RG59u/23awg
RG59u/23awg
RG59U/22awg
RG59U/22awg
RG59U/20awg
RG59U/20awg
RG59U/18awg
RG59U/18awg
CAT5e
CAT5e
Altronix is not responsible for any typographical errors.
–––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
140 58th Street, Brooklyn, New York 11220 USA | 718-567-8181 | fax: 718-567-9056
website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty
IIeBridge100RM Rev. 111413
- 4 -
Multiple PoE Camera Connection:
PoE/PoE+ over Coax/CAT5e
eBridge100RM
500m max.
PoE/PoE+ over Coax/CAT5e
eBridge100RM
500m max.
PoE/PoE+ over Coax/CAT5e
eBridge100RM
500m max.
PoE/PoE+ over Coax/CAT5e
eBridge100RM
500m max.
Local Area Network (LAN)
Camera Power/PoE Class:
13W
25W
13W
25W
13W
25W
13W
25W
13W
25W
eBridge100TM
eBridge100ST
eBridge100TM
eBridge100ST
+ PoE --
SHUTDOWN
or Laptop connection
Max Data Distance
300m
300m
300m
300m
300m
300m
300m
300m
500m
500m
G19U
PoE compliant
100m max.
PoE compliant
100m max.
PoE compliant
100m max.
PoE compliant
100m max.
Legend:
Structured Cable
Coax
Max Power Distance
264m
132m
334m
167m
532m
266m
846m
423m
846m
423m
eBridge100RM Installation Guide
PoE Camera
PoE Camera
PoE Camera
PoE Camera
MEMBER
