Altronix Trove T2RM7F8SQ Installation Manual

Access & Power Integration
Altronix/Mercury Networked Rack Kits
Models Include:
T2RM7F8SQ
8 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove2R enclosure with TM2R Altronix/Mercury backplane
- One (1) eFlow104NB - Power Supply/Charger
- One (1) LINQ8ACM - Dual Input Networked Fused
Access Power Controller
- One (1) VR6 - Voltage Regulator
- One (1) PDS8 - Dual Input Fused Power Distribution Module
All components of these Trove kits are UL Listed sub-assemblies.
Please refer to the included corresponding Sub-Assembly Installation Guides for further information.
Installation Guide
All registered trademarks are property of their respective owners.
Rev. 060823
Installing Company: _________________________ Service Rep. Name: __________________________________________
Address: _________________________________________________________ Phone #: _________________________
T2RM7F8SDQ
8 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove2R enclosure with TM2R Altronix/Mercury backplane
- One (1) eFlow104NB - Power Supply/Charger
- One (1) LINQ8ACMCB - Dual Input Networked PTC
Access Power Controller
- One (1) VR6 - Voltage Regulator
- One (1) PDS8CB - Dual Input PTC Power Distribution Module
More than just power.™
