Technical documentation
Room thermostat (TA)
(external optional)
Modulation coil
(MOD)
STNME ed 07/03
By means of the adjustment board, this enables operation of the boiler
during heating when room temperature is below that required.
If fitted singly, connection is made to terminals 6 and 9 of connector M3
after removing the pre-existing jumper P1.
If fitted together with clock (OP) it must be connected to
terminals 8 and 9 of connector M3 after removing jumper P1.
LOADS
This is powered by the modulation board with a variable signal.
Permits changing the pressure of the gas to the burner.
17
Technical documentation
Double-contact
switch
NIKE MINI
