Merach MR-S02 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

MERACHMR-S02
EXERCISEBIKE
USERMANUAL
Questions or Concerns?
IMPORTANT! Please read all details before use, and retain this owner's manual for
future reference. Your satisfaction is very important to us, PLEASE CONTACT US
BEFORE THE RETURN: support@merach.com.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MR-S02 and is the answer not in the manual?

Questions and answers

Related Manuals for Merach MR-S02

Summary of Contents for Merach MR-S02

  • Page 1 MERACHMR-S02 EXERCISEBIKE USERMANUAL Questions or Concerns? IMPORTANT! Please read all details before use, and retain this owner's manual for future reference. Your satisfaction is very important to us, PLEASE CONTACT US BEFORE THE RETURN: support@merach.com.

  • Page 2: Table Of Contents

    CONTENTS SAFETY INSTRUCTIONS..............1 PRODUCT OVERVIEW................3 PARTS LIST..................4 ASSEMBLY INSTRUCTIONS...............6 PRECAUTIONS FOR USE..............14 ADJUSTMENT INSTRUCTIONS............15 BLUETOOTH CONNECTION INSTRUCTIONS.........18 INSTRUCTIONS FOR [MERACH] APP ..........19 CONNECTION AND USE ..........21 INSTRUCTIONS FOR [KINOMAP] APP CONNECTION AND USE WARM UP ..................24 TROUBLESHOOTING...............25 WARRANTY INFORMATION............26 This device contains a radio transmitter module with type approval code FCC ID ENTIFIER: 2A6QWMR-BLE001.

  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS Please properly keep this manual in a safe place for future reference. It is very important to read the entire manual thoroughly before installing and using the machine. Safe and effective training can only be achieved if the machine is properly assembled, properly maintained and used.
  • Page 4 SAFETY INSTRUCTIONS This machine is not for professional medical treatment. This product is only for family use, and the rating is HC class. The overall performance of the machine and all moving parts must be checked regularly as to ensure the safety of the product. If the moving parts are damaged, please do not use until the parts are repaired.

  • Page 5: Product Overview

    PRODUCT OVERVIEW...

  • Page 6: Parts List

    PARTS LIST Parts Name Spec. Main Frame Handlebar Post Seat Post Seat Knob Left Pedal Right Pedal Front Stabilizer Rear Stabilizer Screw Handlebar Decorative Cover (with washer) Screw Battery AAA (No.7) Allen Key Open-end 14-15 Wrench 14-15...
  • Page 7 PARTS LIST...

  • Page 8: Assembly Instructions

    ASSEMBLY INSTRUCTIONS 2.Place the wheel chock, protective paper 1.Remove the wheel chock bolt locked on and bolt aside. the main frame with A: Allen Key. (Please store them in a bag as spare) A S S E M B L Y A S S E M B L Y I N S T R U C T I I N S T R U C T I...
  • Page 9 ASSEMBLY INSTRUCTIONS 7.Complete assembly of #7 Front Stabilizer. 8.Prepare #8 Rear Stabilizer, two #9 Screws A: Allen Key. 10.Insert two #9 Screws into the holes. 9.Align the holes on #8 Rear Stabilizer and the rear bracket on the #1 Main Frame. 11.Tighten and secure the two #9 Screws 12.Complete the assembly of #8 Rear with A: Allen Key.
  • Page 10 ASSEMBLY INSTRUCTIONS 14.Pull the #5 Knob outward with one hand, 13.Loosen the #5 Knob pre-locked on the then insert the #2 Handlebar Post to #1 Main Frame, then pull it outward. #1 Main Frame with the other hand. 16.Prepare #10 Handlebar, three #12 15.Align the #5 Knob to an adjustment hole Screws and A: Allen Key.
  • Page 11 ASSEMBLY INSTRUCTIONS 20.Prepare #11 Decorative Cover. 19.Make sure three #12 Screws are all tightened. 21.Click in the #11 Decorative Cover to the 22.Complete the assembly of #10 Handlebar. #10 Handlebar. 23.Loosen the #5 Knob pre-locked on the 24.Pull the #5 Knob outward with one hand, #1 Main Frame, then pull it outward.
  • Page 12 ASSEMBLY INSTRUCTIONS 25.Align the #5 Knob to an adjustment hole 26.Prepare #4 Seat, and remove the knob in #3 Seat Post and then tighten this knob. and the washer as the photo shown. 28.Put the #4 Seat onto #3 Seat Post. 27.After removing the knob and the washer.
  • Page 13 ASSEMBLY INSTRUCTIONS 31.Make sure the #4 Seat will not wobble. 32.Prepare #6-R Right Pedal B: Open-end Wrench 14-15. 33.Make sure to match the #6-R Right Pedal 34.Screw the #6-R Right Pedal clockwise by the right crankarm (both marked R). hand onto the right crankarm (at least 3 laps) 35.Tighten the #6-R Right Pedal with the 15 36.Complete the assembly of #6-R Right end of B: Open-end Wrench 14-15,...
  • Page 14 ASSEMBLY INSTRUCTIONS 37.Prepare #6-L Left Pedal B: Open-end 38.Make sure to match the #6-L Left Pedal Wrench 14-15. the left crankarm (both marked L). 39.Screw the #6-L Left Pedal clockwise by 40.Tighten the #6-L Left Pedal with the 15 end hand onto the left crankarm (at least 3 laps) of B: Open-end Wrench 14-15, make sure it's fully tightened.
  • Page 15 ASSEMBLY INSTRUCTIONS 43.Remove the battery compartment door. .Install two #13 AAA Batteries (No. 7) according to the correct polarity. 45.Install the battery compartment door back 46.Complete assembly. and make sure it's clicked properly.

  • Page 16: Precautions For Use

    PRECAUTIONS FOR USE Transport tips： Press the #10 Handlebar downwards to land the transport wheels of the #7 Front Stabilizer on the ground to move the bike. PLEASE NOTE: This device comes with two MSDS certified AAA trial batteries. The service life of these batteries may be the same as that of standard batteries.

  • Page 17: Adjustment Instructions

    ADJUSTMENT INSTRUCTIONS You can adjust your bike as a normal road bike, which you can have the correct postures and make sure your muscles can get proper training. Make small adjustments, then pedal the bike to test the effect. I-Seat Adjustment You can adjust your seat to the most comfortable angle.
  • Page 18 ADJUSTMENT INSTRUCTIONS II-Handlebar Adjustment Loosen the knob counter-clockwise 2-3 laps, then pull the knob outwards, and use the other hand to move the handlebar post to the proper height then tighten the knob clockwise. (CAUTION: Do not exceed the MAX mark printed on the seat post while adjusting the height) Brake Resistance Knob You can increase and decrease the resistance by turning the knob as the arrow shows.
  • Page 19 ADJUSTMENT INSTRUCTIONS Leveling Adjustment If the bike wobbles during use, please adjust the 4 foot-pads on the front and rear stabilizers. Firstly, use the 14 end of the B: Open-end Wrench 14-15 to loosen the nut clockwise, adjust the foot-pads until the bike is stable, and then use the 14 end of the B: Open-end Wrench 14-15 to tighten the nut.

  • Page 20: Bluetooth Connection Instructions

    BLUETOOTH CONNECTION INSTRUCTIONS 1. Wake up the Bluetooth system This product has a built-in Bluetooth module, before connecting the App you need to pedal more than two laps to wake up the Bluetooth system. 2. Connect the APP After waking up the Bluetooth system, open the Bluetooth on your smart phone, search and connect the corresponding device through the APP and start exercising.

  • Page 21: Instructions For [Merach] App Connection And Use

    Please include your order ID and Merach app Username. 1. Download the "MERACH" APP. Please scan the QR code down below to download the MERACH APP and get the APP connection guide. MERACH APP Download APP Connection Guide 2.
  • Page 22 INSTRUCTIONS FOR [MERACH] APP CONNECTION AND USE Download and use of MERACH 3. Select the corresponding fitness equipment. 4. Update the app to the latest version. In the near future, we will upgrade the app function, adding free exercises mode, courses and various training modes to the app.

  • Page 23: Instructions For [Kinomap] App

    INSTRUCTIONS FOR [KINOMAP] APP CONNECTION AND USE Download and use of KINOMAP 1.Research "KINOMAP" in application store for download. This application can also be downloaded by scanning the QR code below. 2.Login/creating account （For existing account, directly click login);If you have no account, please click "Sign up"...
  • Page 24 INSTRUCTIONS FOR [KINOMAP] APP CONNECTION AND USE Download and use of KINOMAP 3.Selection of corresponding fitness equipment 4. Turn on Bluetooth, and choose FTMS.
  • Page 25 INSTRUCTIONS FOR [KINOMAP] APP CONNECTION AND USE Download and use of KINOMAP 5. Select "Exercise bike", and find your "MRK-S02-XXXX". 6.Start training and explore different playing methods...

  • Page 26: Warm Up

    WARM UP Do stretches before exercising. Warm muscles are easier to stretch, so start with a 5-10 minute warm-up, then do the stretch as follows - 5 times, 10 seconds or more per leg. Do it again after the workout. 1.

  • Page 27: Troubleshooting

    TROUBLESHOOTING Problem Possible Solution Turn the knob clockwise to increase resistance and counterclockwise to How to adjust gear? decrease resistance. The resistance of the bicycle is adjustable with infinitely variable speed and multiple gears. Check whether the connecting screws of the handle and the front What to do when the column tube are firmly fixed.

  • Page 28: Warranty Information

    Damage in return transit. Unsupervised use by children under 18 years old. Merach and its subsidiaries are only responsible for damages caused by the intended use or as instructed in the user manual. Some states do not allow this exclusion or limitation of incidental or consequential losses, so the above disclaimer may not apply to you.
  • Page 29 You can enjoy an additional 12-month warranty. Just active your warranty by sending the product's model name via register@merach.com, or log onto merachfit.com/pages/warranty and enter your order number (i.e. Amazon) within the first 14 days of purchase to register your new product for the extended warranty. If you are unable to provide the order number for your product, please type a short note in the order number field along with the date you received your product.
