Pressure Control - Task Force Tips HANDLINE Maintenance Manual

4f
From
SLIDE VALVE
T.O. and
S.T.O.
2f

PRESSURE CONTROL

# DESCRIPTION
1p 5/16-18 X 3/4 SOCKET HEAD CAP SCREW
2p LOCKING SLEEVE
3p PRESSURE CONTROL ASSEMBLY
HANDLINE 100 PSI
HANDLINE 75 PSI
4p PRESSURE CONTROL ASSEMBLY
DUAL FORCE 100/55 PSI
DUAL-FORCE 75/45 PSI
5p O-RING 005
6p SPRING
7p 5/32" TORLON BALL
8p KNOB LABEL - 100 PSI STANDARD
KNOB LABEL - 75 PSI STANDARD/LOW
9p KNOB
10p DOME PLUG
©Copyright Task Force Tips, Inc. 2003 - 2010
3f
6f
1p
From
2p
FRONT
END
SHELL
QTY PART#
1 VT31-18SH750
1 HX571
1 HX840-KIT
1 HX840-75-KIT
1 HXD840-KIT
1 HXDL840-KIT
2 VO-005
1 VM4195
1 VB156TO
1 HXD752
1 HXD752L
1 HXD560
1 VM4124
SHELL FRONT END
# DESCRIPTION
2f NAME LABEL HANDLINE - 100 PSI
NAME LABEL HANDLINE - 75 PSI
NAME LABEL DUAL-FORCE 100/55 PSI
NAME LABEL DUAL-FORCE 75/45 PSI
3f GUIDE BALLS
4f SHAPER GUIDE
6f BARREL LABEL - SINGLE PRESS
DUAL-FORCE
7f BARREL ASSEMBLY - HANDLINE
8f 3/16" BALLS
9f O-RING 336
10f SHAPER WITH BUMPER
7f
8f
9f
4p
3p
5p
For
SINGLE
PRESSURE
HANDLINE
QTY PART#
1 HX745
1 HX745L
1 HXD745
1 HXD745L
3 VB344TO
1 HXD510
1 H740
1 HD740
1 HX850-KIT
48 V2115
1 VO-336
1 H500
10f
To
PRESSURE
CONTROL
PARTS
6p
8p
7p
9p
10p
For
DUAL-FORCE
LIH-020 September 25, 2010 Rev06
