Instructions
Rexroth NYM04.1-5PW-NNNN-NY4125
1 About this documentation
1.1 Overview – target groups & product phases
The target groups, product phases and activi-
ties that can refer to this document are marked
in rounded boxes in the following figure.
Mounting
Product phases
Selection
(assembly/installation)
Presales Aftersales
Design engineer
Mechanic/
electrician
Programmer
Technologist
Process
specialist
Target groups
To select To unpack
To prepare To mount
Activities
To install
To design
To construct
1.2 Intended Audience
This document explains technical and service
personnel of the machine builder how to safely
install the drive module mechanically and elec-
trically. This document is not the usage manu-
al.
1.3 Availability
These Instructions are part of the drive module
product delivery and must always be available
for the user.
If the drive module is handed over to another
person, these Instructions must be handed over
as well.
January 18, 2016
Bosch Rexroth AG
Electric Drives and Controls
Bgm.-Dr.-Nebel-Str. 2
D-97816 Lohr am Main
Telefon +49 (0)9352-18-0
Telefax +49 (0)9352-18-8400
www.boschrexroth.com
Engineering Operation De-commissioning
Commissioning
Programmer
Commissioning engineer
Technologist
Process specialist
Machine
operator
Maintenance
technician
Mechanic/
electrician
Service
Disposal company
To parameterize To optimize To operate To dismount
To program To test To maintain To dispose
To remove
To configure
faults
To create
To simulate
the program
1.4 Included Parts
Type code
NYM04.1-5PW-NNNN-NY4125
DOK-NY4000-DRV*NY4125*-IT04-EN-P
1.5 Variations
These Instructions apply to the drive module
with the following Type code:
 NYM04.1-5PW-NNNN-NY4125
1.6 Further Available Documentation
Title and type code
Rexroth NYCe 4000
Hardware System Manual
DOK-NY4000-HW***SYSTEM-PRRS-EN-E
Rexroth NYCe 4000
Standard Housings & Accessories Manual
DOK-NY4000-HOUSING*ACC-PRRS-EN-E
1.7 Additional Parts
The specific system housing NYS04.1-ST-03-
4125-NY4063 for the NYM04.1-5PW-NNNN-
NY4125, host adapter, Motion Control Units,
fan unit, capacitor kits, connection cables, and
more are listed in the project planning manuals
or on www.boschrexroth.com
2 Product Identification and Scope of
Delivery
2.1 Product Identification
View of the NYM04.1-5PW-NNNN-NY4125
The NYM04.1-5PW-NNNN-NY4125 can be
identified by the cover plate and the label on
the rear side of the circuit board.
 Cover plate identification
One LED is visible at the top. Below the
LED is the text 'DRV'.
At the bottom of the cover plate is the
text 'NY4125'.
Page 1 of 7
Material Description
number
R911172221 Drive module
R911336855 Instructions
Material number
R911337671
R911337672
R911336855-04_BAL_DOC
