- Page 1 Version: E220704 Manual Safe Driving 2...
- Page 2 Important Information General Before using your ALGE-TIMING device read the complete manual carefully. It is part of the device and contains important information about installation, safety and its intended use. This manual cannot cover all conceivable applications. For further information or in case of problems that are mentioned not at all or not sufficiently detailed, please contact your ALGE-TIMING representative.
-
Page 3: Table Of Contents
Manual TIMY3 – Safe Driving 2 Table of Content General Information about the Timy3 ................ 4 Control elements....................4 Timy3 Models ....................... 4 TIMY3 Software ....................5 Installation of Device Drivers................. 6 Switch On ......................6 Switch Off ......................6 Setup of the System .................... -
Page 4: General Information About The Timy3
Timy3 – Safe Driving 2 General Information about the Timy3 A device description for the TIMY3 is available in the manual “General”. This includes general information about the device and operating instructions. This manual is specific made only to the operation instruction when using the program “Save Driving 2”. -
Page 5: Timy3 Software
Manual TIMY3 – Safe Driving 2 TIMY3 Software Available programs for the Timy3: Stopwatch: universal timing program which is suitable for several heats (run/total time) Backup: to measure time of day times (e. g. as backup-system or as time reference... -
Page 6: Installation Of Device Drivers
Timy3 – Safe Driving 2 Installation of Device Drivers Separate operating instructions are available for installing the drivers (e.g. for USB). You can request these instructions from your ALGE-TIMING representative or download from our homep- age www.alge-timing.com. Switch On •... -
Page 7: Setup Of The System
Manual TIMY3 – Safe Driving 2 Setup of the System - 7 -... -
Page 8: Program "Save Driving 2
(delay adjustable). After the set delay, the other signals are displayed. If the speed measurement (SPEED) is activated, the speed measurement starts and appears in the Timy3 display <Speed = ---.->. If channel C1 (second photocell) is triggered, the speed will appear on the display panel after the set delay. -
Page 9: Symbol Adjustment
Manual TIMY3 – Safe Driving 2 Symbol Adjustment The control of the scoreboard was programmed in such a way that the user can control it flexibly. Switch between both displays with after impulse from C0 shows the display after impulse from C0 shows the display... -
Page 10: Speed Measurement Adjustments
Operation • After switching on, the system is immediately ready. If an impulse from the photocell on channel 0 reaches the Timy3 it activated the brake • light on the display. The green direction arrows or the red traffic lights are depending on the setting and delay •... -
Page 11: Display Time On The Display Board
Manual TIMY3 – Safe Driving 2 3.3.1 Display Time on the Display Board When pressing <MENÜ> <DISPLAY> and <DELAY TIME 1> you can select the display dura- tion of the speed. If you set zero (0), then the speed will be shown until the next measurement. -
Page 12: Display Board
Manual Timy3 – Safe Driving 2 Display Board The „Save Driving 2“ Display Board consists of two displays. Display 1 - Top Part: D-LINE600-O-3-E0 Display 2 - Bottom Part: D-POL-2AGLR+2FL300-R+1FL300-W Display Board Interface RS232 interface for the display board (banana sockets). The characters are output in ASCII- Code. -
Page 13: Display Board Connections
Manual TIMY3 – Safe Driving 2 Display Board Connections - 13 -... -
Page 14: Mounting Of The Display Board
Manual Timy3 – Safe Driving 2 Mounting of the Display Board - 14 -... - Page 15 Manual TIMY3 – Safe Driving 2 - 15 -...
- Page 16 Manual Timy3 – Safe Driving 2 Subject to changes and misprints Copyright by ALGE-TIMING GmbH Rotkreuzstr. 39 6890 Lustenau / Austria www.alge-timing.com - 16 -...
