Luraco iROBOTICS 9 MAX Series User Manual page 15

on both sides of connector). (Fig. 10, Step 3)
4. Install the Remote cable clamp (Fig. 10, Step 4).
Note: This Cable Clamp must be installed to prevent data
communication failures during operation.
Remote Cable
Clamping Screw
(Must be installed)
Remote Connector
Fig.9: Remote Panel
2
Insert the Remote Cable through this leather loop
2
to secure the remote and prevent remote dropping
ATTENTION:
i9 Max Series installation videos at www.luracochairs.com
(Located on the back of the
1
Insert the Remote
Into the leather pouch
Fig.10: Remote Controller Installation
For more detailed instructions, please watch
Remote Cable Clamp
4
(Must be installed)
3
Remote Connector
(Make sure to tighten the 2 locking screws
on both sides of the connector)
15
Blood Pressure Monitor
Charging Port
Reserved for
Manufacture Use Only
Reserved for
Manufacture Use Only
chair)
