Lift the Footrest up
(Note: Use the Footrest Packing Box to support
the bottom of the Footrest during
2
3
Insert Footrest Packing Box
Install Footrest Hinges (2pcs)
Fig.3: Footrest Assembly
installation)
Insert all footrest cables and
4
Air tubes thru this aperture
Fig.4: Footrest Assembly
1
11
Pull this plastic cover up to provide
5
access for all connector installation
in Steps 6 & 7
