3.

OPTIONAL STEPS

Steps 24, 25 and 26 can optionally be performed in the MQTT Box software, which can be downloaded for free via the link
http://workswithweb.com/mqttbox.html.
27. Run the MQTT Box software and click Create MQTT Client.
28. In the configuration window, fill in the available fields with the following values:
MQTT Client Name: Enter client name. Ex.: AWS Broker.
Protocol: mqtt / tls.
Host: Enter the Endpoint address saved in Step 21. Ex.: a2jsauz3jc3c1e-ats.iot.us-east-2.amazonaws.com.
SSL / TLS Version: TLSv1.2.
SSL / TLS Certificate Type: Self signed certificates.
CA File: Load the Amazon Root CA certificate. Ex.: AmazonRootCA1.pem.
Client certificate file: Load the "thing" certificate. Ex.: 993cb74d0b-certificate.pem.crt.txt.
Client key file: Load the private key certificate. Ex.: 993cb74d0b-private.pem.key.
You do not need to make any changes to the other settings.
NOVUS AUTOMATION
Fig. 32 – Create MQTT Client
Fig. 32 – MQTT Box configuration
12/13
