2.6 Default pictures

In the main program directory, you will also find images that are used in the program:
default.png is the image displayed when the program is not able to locate an image
(default image of a talk).
In the folder curseur, you have some images like curseurDefault.png, curseur1.png,
curseur2.png, curseur3.png, curseur4.png et curseur5.png.

3 Creating a new presentation

All the information regarding the presentation are stored in the same directory, that we
call NaoDirectory. Normaly a NaoDirectory has been deployed when you installed the
software. The folder contains some example presentations , that you can try or modify.
NaoDirectory contains a file named architecture.xml, two pictures and a subdirectory for
each presentation.
Here is a an overview of the NaoDirectory structure:
3.1 Architecture file
This file list all the presentation available and the path. Here is an example of an architec-
ture file.
<? xml version = " 1.0 "
< repository >
< backgroundImage >
< welcomeImage >
< introduction >
< nameRep >
< nameXml >
</ introduction >
< presentation >
< nameRep >
< nameXml >
< imgPres >
< imgPresSelected >
</ presentation >
< presentation >
< nameRep >
< nameXml >
< imgPres >
< imgPresSelected >
Figure 3: Overview of the files in NaoDirectory
encoding = " UTF -8 "
image1 . png </ backgroundImage >
image2 . png </ welcomeImage >
presIntro </ nameRep >
presentation . xml
presNao </ nameRep >
presentation . xml
robotnao . jpg </ imgPres >
robotnaoS
presGR </ nameRep >
presentation . xml
logo_GR . png </ imgPres >
logo_GRS
? >
</ nameXml >
</ nameXml >
. jpg </ imgPresSelected >
</ nameXml >
. png </ imgPresSelected >
7 Nao Presenter- V2.1.7
