Setting Surface Controls

Radiant surface elements may appear to
have cooled after they have been turned off. The
glass surface may still be hot and burns may occur if the
glass surface is touched before it has cooled sufficiently.
Do not place plastic items such as salt
and pepper shakers, spoon holders or plastic
wrappings on top of the range when it is in use. These
items could melt or ignite. Potholders, towels or wooden
spoons could catch fire if placed too close to the surface
elements.
Do not allow aluminum foil, empty
glass/porcelain cookware or ANY material that can
melt to make contact with the ceramic cooktop. If
these items melt on the cooktop they may damage the
ceramic cooktop.
Single radiant surface elements
To operate a single radiant element:
1. Place correctly sized cookware on single radiant surface
element.
2. Press the On/Off keypad on the Electronic Surface
Element control until tone sounds. If no heat setting is
selected within 6 seconds of pressing the
On/Off keypad the control will turn off.
+
3. Press the High/ keypad to start at the Hi setting and
then press Low/— to scroll down to desired heat
setting, or press the Low/— keypad to start at the Lo
setting and press High/
setting (Fig 1).
4. When cooking is complete, press the On/Off keypad to
turn the radiant surface element OFF before removing
the cookware.
+
to scroll up to the desired heat
Fig. 1

Dual radiant surface element

To operate a dual radiant element:
1. Place correctly sized cookware on dual radiant surface
element.
2. Press the On/Off keypad on the Electronic Surface
Element control until tone sounds. If noheat setting is
selected within 6 seconds of pressing the
On/Off keypad the control will turn off.
+
3. Press the High/ keypad to start at the Hi setting and
then press Low/— to scroll down to desired heat
setting, or press the Low/— keypad to start at the Lo
setting and press High/
setting.
4. Press the Burner Size keypad to toggle between one
(Fig. 2) or two (Fig. 3) elements.
5. When cooking is complete, press the On/Off keypad to
turn the radiant surface element OFF before removing
the cookware.
Fig. 2
Heating with inner
(small) element only
Heated areas are shown darkened.
10
+
to scroll up to the desired heat
Fig. 3
Heating with both
elements
