Speakman SB-3241 Instructions

INSTRUCTIONS FOR MODELS
SB-3241
For additional assistance or service please contact:
SPEAKMAN
®
800-537-2107
customerservice@speakman.com
www.speakman.com
92-SB-3241-01
3
Position Faucet and Cover Bells on sink. Lower into position.
4
Assemble Washers (1) and Mounting Nuts (2) onto Faucet Shanks and wrench tighten.
(DO NOT OVER TIGHTEN MOUNTING NUTS).
TOOLS AND SUPPLIES
Adjustable Slip Joint
Wrench Wrench
HELPFUL TOOLS & SUPPLIES:
Thread Seal Safety
Tape Glasses

IMPORTANT

• Do not over-tighten any connections or damage
may occur.
• Be sure to read instructions thoroughly before
beginning installation.
• This faucet has an operating range of 20-80 psi.

SAFETY TIPS

Cover your drain to prevent loss of parts. Be sure to
wear eye protection while cutting pipe.

MAINTENANCE

Your new Speakman Product is designed for years of
trouble-free performance. Keep it looking new by
cleaning it periodically with a soft cloth. The use of harsh
chemicals and abrasives on any of the Speakman custom
finish products may damage the finish and void the
product warranty. Please be sure to only use approved
cleaners. Please contact Speakman for any clarification
of acceptable cleaners.

WARRANTY

Warranty information can be found at:
www.speakman.com
1
Turn off Water Supplies. Ensure mounting surface requirements are as follows:
• Two (2) Holes; 8" on Center, DIA 13/16" Min to DIA 1-1/2" Max.
• Surface Thickness 1-3/16" Max
Refer to Rough-In diagram.
8"
[203mm]
2
Remove Inlet Nuts (1), Mounting Nuts (2), and Washers (3) from Faucet.
5
Assemble Water Supply Lines. Use ½" IPS faucet connections (not supplied). Use wrenches to tighten
Connections. Do not overtighten.
INLET SUPPLIES NOT INCLUDED
13
16
[21mm]
1
1
2
[38mm]
½"-14 NPSM
"
MIN
"
MAX
