INSTRUCTIONS FOR MODELS
SA-2703
TOWEL RING
For additional assistance or service please contact:
SPEAKMAN
®
800-537-2107
customerservice@speakman.com
www.speakman.com
92-SA-2703-01
TOOLS AND SUPPLIES
Pencil Level Phillips Phillips
Screwdriver Drive Bit
2.5mm Hex Drill Drill Bit
Key (included) Ø3/16"
IMPORTANT
• Do not over-tighten any connections or damage
may occur.
• Be sure to read instructions thoroughly before
beginning installation.
SAFETY TIPS
Cover the drain to prevent any loss of parts. Be sure
to wear eye protection while assembling the product.
MAINTENANCE
Your new Speakman Product is designed for years of
trouble-free performance. Keep it looking new by
cleaning it periodically with a soft cloth. The use of harsh
chemicals and abrasives on any of the Speakman custom
finish products may damage the finish and void the
product warranty. Please be sure to only use approved
cleaners. Please contact Speakman for any clarification
of acceptable cleaners.
WARRANTY
Warranty information can be found at:
www.speakman.com
1
If the Mounting Plate (1) comes pre-installed in
the Accessory (2), remove the Mounting Plate
by loosening, but not removing the pre-installed
Set Screw at bottom with the included 2.5mm
Hex Key (3).
2
At the selected height, mark center point of
mounting locations onto wall referencing
the rough-in diagram.
3
Align Mounting Plate over center point marked
in previous step. Mounting Plate should be
vertical as shown below. Mark Mounting Screw
locations onto the wall surface. Remove item(s)
after marking mounting locations.
4
If mounting directly to wood stud, Plastic Anchors
are not required. If mounting to tile, acquire
proper mounting hardware capable of supporting
the accessory in use. If mounting to drywall, drill
guide holes at marked locations using a Drill
equipped with a Ø 3/16" bit.
Ø 3 / "
16
5
Insert Plastic Anchors into drilled holes and screw
in the Anchor using a Phillips Head Screwdriver,
or a Drill equipped with a Phillips Driver Bit until
the head is flush with the wall surface.
OR
6
Secure Mounting Plate (1) with the Mounting
Screws (2) provided. Verify that the Mounting
Plate is aligned vertically.
