Key Digital Xplosion Series KD-CDA12 Specifications

Video/Audio Distribution Amps
KD-CDA12
KD-CDA12 is a 12 Channel Component/RGBHV Video/Audio Distribution Amplifier
Key Benefits
4
Distributes 1 or 2 YPrPb/RGBHV sources to
12 YPrPb/RGBHV outputs/displays
4
Can support 2 inputs to 6 outputs on each side or
1 input to 12 outputs on both sides
4
Supports Left, Right analog stereo, and Coaxial/Digital
(PCM) Audio distribution
Key Solutions
Simultaneously distributes a one or two Video/Audio source up to 12 displays
›
Is heat resistant and can withstand noisy environments
›
Built-in video amplifier circuitry allows cable (RG6) runs up to 300 ft.
›
without signal degradation

4
Bandwidth of 350 MHz supports all resolutions
up to 1080p
4
Each channel/output can support cable runs up to 300 ft.
4
Can be daisy chained to support additional output
to more displays
4
Incorporates 3 Key Digital Exclusive Technologies
™
General Info
Power: 100VAC to 240VAC,
›
50Hz and 60Hz, NTSC, PAL
Rack Mount: No
›
Remote Control: No
›
Enclosure Type: Metal
›
Dimensions:
›
12.5" x 6" x 1.75"
Shipping Carton Dimensions:
›
16" x 9" x 6"
Product Weight: 4 lbs
›
Shipping Weight: 6 lbs
›
Retail Environment Application
Model: KD-CDA12
Plasma /LCD
HDTV Cable Box
DVD Player
*All Component sources can
be substituted with RGBHV
Key Digital Exclusive Technologies
®
Plasma /LCD
KD-CDA12
