Summary of Contents for Champion 90034
- Page 1 90034 Rev 90034-20090416 10006 Santa Fe Springs Road Santa Fe Springs, CA 90670 USA Made in China Owner’s Manual and Operating Instructions Gasoline Powered HYDRAULIC AUGER...
-
Page 3: Table Of Contents
Table of Contents Introduction ........1 Maintenance ........12 Portable Hydraulic Auger/Post Hole Engine Maintenance ....... 12 Digger ............1 Oil ............12 Accessories ..........1 Spark Plugs .......... 12 This Booklet ..........1 Air Filter .......... -
Page 5: Introduction
Introduction Introduction Accessories Champion Power Equipment manufactures Congratulations on your purchase of a and sells accessories designed to help you Champion Power Equipment Auger/Post get the most from your purchase. To find out Hole Digger. CPE designs and builds Augers more please visit our web site at to strict specifications. -
Page 6: Manual Conventions
NOTE If you have questions regarding your Auger/Post WARNING Hole Digger, we can help. Please call our help line at 1-877-338-0999. WARNING indicates a potentially hazardous could situation which, if not avoided, result in death or serious injury. Rev 90034-20090416... -
Page 7: Safety Rules
Rotating Hazard Rotating parts can entangle hands, feet, hair, clothing and/or accessories. Entanglement in Auger/Post Hole Digger will Traumatic amputation or severe laceration can cause serious injury or death. Keep away from Auger when engine is running. result. Rev 90034-20090416... - Page 8 DO NOT allow any material to block the cooling Fire or explosion can cause severe burns or slots. death. DO NOT use the engine if: Equipment sparks, smokes or emits flames Unintentional startup can result in entanglement, Equipment vibrates excessively traumatic amputation or laceration. Rev 90034-20090416...
-
Page 9: Controls And Features
(14) Strainer (7) Pivot bolt – Adjust pivot bolt to rotate (15) Hydraulic Pump the Auger bit and handle when drilling on a slope. (16) Auger Bit Rev 90034-20090416... -
Page 10: Assembly
Auger/Post Hole Digger. This swinging movement allows the engine and hydraulic tank to stay level, avoiding fuel and oil spillage. Use M20x60 bolt, lock washer, nut, and lock nut to attach engine carriage to frame Rev 90034-20090416... -
Page 11: Step 3 - Attach Boom
3. Make sure the hoses have enough slack to allow the engine carriage to swing freely. Step 5 – Feed the hydraulic hoses and wires through the boom Feed the hydraulic hoses and wires through the boom pole Rev 90034-20090416... -
Page 12: Step 8 - Wire Connections
Washer and (2) M12 lock nut. Tighten. 2. Attach the towing chains to the towing chain mount plate with (2) M12x45 bolts, (2) Ø12 Flat washers and (2) M12 lock nut. Bolt the first link in each towing chain. 3. Tighten all hardware Rev 90034-20090416... -
Page 13: Add Engine Oil
5. Slowly add fuel to the tank. DO NOT overfill. Allow approximately ¼ inch of space for fuel expansion. 6. Screw on the fuel cap and wipe away any spilled fuel. CAUTION Use regular unleaded gasoline with a minimum octane rating of 85. Rev 90034-20090416... -
Page 14: Operation
7. Move the throttle lever (Item A) to the 6. Periodically lift the Auger to clear loose “Fast” position. dirt from the hole. 7. If the Auger becomes stuck, squeeze the left side of the trigger to reverse the rotation of the Auger. Rev 90034-20090416... -
Page 15: See Following Diagrams
Assembly See Following Diagrams. Rev 90034-20090416... -
Page 16: Maintenance
3. Replace the drain plug. place. 4. Remove oil fill cap/dipstick to add oil. 5. Add 1.16 qt (1.1 L) of oil and replace oil fill cap/dipstick. 6. Dispose of used oil at an approved waste management facility. Rev 90034-20090416... -
Page 17: Cleaning
Auger. Contact our help line at 1-877-338-0999 to Inspect all air vents and cooling slots to locate the nearest Champion Power ensure that they are clean and unobstructed. Equipment certified service dealer for your Auger/Post Hole Digger or engine maintenance needs. -
Page 18: Storage
4. Add a fuel stabilizer into the fuel tank. 5. Change the oil. 6. Remove the spark plug and pour about ½ ounce of oil into the cylinder. Crank the engine slowly to distribute the oil and lubricate the cylinder. 7. Reattach the spark plug. Rev 90034-20090416... -
Page 19: Specifications
Overall Dimensions Weight 350 lb. (158.75 kg) Height 61 inches (154.94 cm) Width 41 inches (104.14 cm) Length 115 inches (292.1 cm) Hydraulic Oil Oil capacity is 3.9 gallons (15L). Use types 10W AW32, ASLE H-150, and ISO32 Rev 90034-20090416... -
Page 20: Auger/Post Hole Digger Parts Diagram
Specifications Auger/Post Hole Digger Parts Diagram Rev 90034-20090416... -
Page 21: Auger/Post Hole Digger Parts List
Connector Z3/4” 90034047 Flat Washer Ø6 90034048 Bolt M6x20 90034049 Lock Washer Ø6 90034050 Filter Plate 90034051 Rubber Washer 90034052 Filter 90034053 Hydraulic Hose 2550 90034054 Connector Z3/4”-M14x1.5 90034055 Hydraulic Filter Assemble 90034056 Connector Z3/4”-Z3/4” 90034057 Seal 90034058 Bearing Rev 90034-20090416... - Page 22 Hose Retaining Bracket 90034101 Bolt M10x35 90034102 Boom 90034103 Nylon Lock Nut M10 90034104 Oil Tank Block 90034105 Big Flat Washer Ø10 90034106 Engine Block 90034107 Tapping Screw ST4.8x9.8 90034108 Connector Cover 90034109 Oil Scale 90034110 Oil Plug Rev 90034-20090416...
-
Page 23: Engine Parts Diagram
Specifications Engine Parts Diagram Rev 90034-20090416... -
Page 24: Engine Parts List
Specifications Engine Parts List Item Parts Number Description ST160F-1070100H Fuel Tank Cap ST160F-1070006 Fuel Filter ST173F-1070200-E Fuel Tank ST160F-1070300-A Fuel Tank Joint ST188FD-1070006A Clip ST173F-1070001 Tube GB41-N-8 Nut M8 GB5789-FB8-25 Flange Bolt M8×25 ST160F-1030001-C Oil Filler Cap ST160F-1030002 Oil Filler Cap Packing GB5789-FB8-40 Flange Bolt M8×40 ST173F-1030200... - Page 25 GB276-BB-6206-UU Radial Ball Bearing 6206 Unsealed ST173F-1030010 Case Cover Packing 139FMD-1003003 Dowel Pin 8×14 ST160F-1128000 Diode Comp ST168F-1121100-C Switch ST177F-1030006 Crankcase ST188F-1030012 Packing ST173F-1121000 Flywheel ST173F-1080002 Cooling Fan ST173F-1060001 Starter Pulley ST188F-1050006 Flywheel Nut ST188F-1080004-D Diode Base Comp Rev 90034-20090416...
- Page 26 Specifications Item Parts Number Description ST168F-1090100 Air Cleaner Cover Nut GB97.1-85 Gasket ø6 ST160F-1040025 Pivot Adjusting Nut ST160F-1040024 Rocker Arm Bolt ST173F-1071000-E Fuel Meter Assembly...
-
Page 27: Troubleshooting
Make sure Auger/Post Hole Digger is on a flat, level surface Engine cannot supply enough power Insufficient ventilation Check for air restriction. Move to a or overheating well ventilated area Engine gallops Engine governor defective Contact the help line Rev 90034-20090416... -
Page 28: Warranty
Wear items such as filter elements, o-rings, etc. Accessory parts such as starting batteries, and Warranty Qualifications storage covers. Champion Power Equipment (CPE) will register Failures due to acts of God and other force this warranty upon receipt of your Warranty majeure events beyond the manufacturer’s Registration Card and a copy of your sales receipt control. -
Page 29: Notes
Notes Notes Rev 90034-20090416...
