10. Technical Specifications
Weight
Total Height
Dimensions
during operation
(Length x Width x
Height)
Rotating Unit Vertical Movement
Installation Type
Packing Box Organization
138
Item
Without
CEPH unit
With
CEPH unit
Without
Base
With
Base
Without
CEPH unit
With
CEPH unit
Description
137 kg (302.0 lbs. – without Base)
190 kg (418.9 lbs. – with Base)
162 kg (357.1 lbs. – without Base)
215 kg (474.0 lbs. – with Base)
Max. 2306.0 mm (90.8")
Max. 2337.5 mm (92.1")
1144.3 (L) x 1557.5 (W) x 2306 (H)
(mm, without Base)
45.1 (L) x 61.4 (W) x 90.8 (H)
(inch, without Base)
1144.3 (L) x 1557.5 (W) x 2337.5 (H) (mm,
with Base)
45.1 (L) x 61.4 (W) x 92.1 (H)
(inch, without Base)
1905.9 (L) x 1557.5 (W) x 2306 mm (H)
(mm, without Base)
75.1 (L) x 61.4 (W) x 90.8 (H)
(inch, without Base)
1905.9 (L) x 1557.5 (W) x 2337.5 (H)
(mm, with Base)
75.1 (L) x 61.4 (W) x 92.1 (H)
(inch, with Base)
Max. 803.7 mm (31.7")
Base Stand/Wall Mount
(Default: Wall Mount type)
Main Box,
CEPH Box (Optional), Base Box (Optional)
