SERVICE MANUAL
TECHNICAL SPECIFICATIONS
Audio Outputs:
Pads:
Sample/DAC Bit Resolution
Sounds
Sounds Accessible via Pads 8
Sounds Accessible via MIDI
Polyphony
Panning
Velocity Response
Timing Resolution
Time Signature Range
Tempo Range
Notes/Patterns/Songs
Kits
MIDI Prog Change Response Kit
Sync
Footswitch Jacks/Functions Hi-Hat and Kick
Other Features
Power
Weight
Dimensions (W x D x H)
2 TS 1/4" (main), 1 TRS 1/4" (phones)
SNR: 94 dB (A-weighted)
THD+N: ~0.004% @ 1.38 kHz
8 velocity sensitive
16 / 24
500 (w/Dynamic Articulation™)
120
32-voice
7-position user programmable
8 loudness levels via pads, 127 via MIDI
96 ppq
1-128 beats per pattern
30-300 BPM
150,000 / 200 (100 user, 100 preset) / 100
100 user, 100 preset
MIDI Clock with Song Position Pointer
Step Editing, Stereo Samples, Reverb and Compressor / EQ
effects.
Input 12VDC 500mA, center pin ground
7.1 lbs (3.2 kg)
17.2" x 14" x 2.5" (437 mm x 356 mm x 64 mm)
7-51-0337-A
MODEL:PERFORMANCE
