- Page 1 I N S T R U C T I O N S E N G L I S H Read this manual carefully before installing and operating the machine Rev. 00/2022 Franco s. r. l. Via Nazionale, 80 - 12010 Cervasca (CN)
-
Page 2: Table Of Contents
User and maintenance manual - UCP Fly INDEX INDEX ............................2 1 - INTRODUCTION ......................... 3 1.1 General safety instructions ....................3 1.2 Guidelines for the correct disposal of the product .............. 3 1.3 Conventions used in this manual ..................3 1.4 Keeping and updating the instruction manual.............. -
Page 3: Introduction
This appliance must only be used for the function for which it was designed: "Adiabatic humidifier/cooler". Any other use is to be considered improper and dangerous. Franco s.r.l. cannot be held responsible for any damage resulting from improper, incorrect and unreasonable use or if the appliance is used in installations which do not comply with the safety regulations in force. -
Page 4: Keeping And Updating The Instruction Manual
User and maintenance manual - UCP Fly ABBREVIATIONS Cap. = Chapter Par. = Paragraph Page = Page Fig. = Figure Tab. = Table UNITS OF MEASUREMENT The units of measurement used are those of the International System (SI). 1.4 Keeping and updating the instruction manual The instruction manual must be kept with care and must accompany the machine at all times during its life. -
Page 5: Pictograms
User and maintenance manual - UCP Fly The appliance may be used by persons with reduced physical, sensory or mental capabilities, or lack of experience or knowledge, provided that they are supervised or have received instructions concerning the safe use of the appliance and an understanding of the hazards involved. 1.6 Pictograms This section explains the meaning of the pictograms indicating the operator's qualification, the state of the machine, the hazards and the obligations/prohibitions to be respected. - Page 6 User and maintenance manual - UCP Fly SAFETY PICTOGRAMS (ISO 7010) Pictograms contained within a triangle indicate DANGER. Pictograms contained within a circle impose a PROHIBITION/OBBLIGATION. Pictogram Description Dangerous electrical voltage. General danger. Do not remove safety devices. It is forbidden to clean, oil, grease, repair or adjust moving parts by hand.
-
Page 7: Applications
User and maintenance manual - UCP Fly 1.7 Applications In industry, the machine is installed in rooms where it is necessary to maintain a certain level of humidity, e.g. in cold storage rooms for fruit and vegetables, in seasoning warehouses, in the paper and tobacco industries and in textile companies. -
Page 8: Description Of Equipment
User and maintenance manual - UCP Fly 1.10 Description of equipment Main components of the appliance (Fig. 1.10.1) Junction box Centrifugal Protection grid humidifier Electric motor Fixing bracket Fig. 1.10.1 Regulating valve Main components of the centrifugal humidifier (Fig. 1.10.2) Rotary disc Fixed disk Rear cover... -
Page 9: Transport And Handling
Franco s.r.l. of Cervasca (CN). During the warranty period, Franco s.r.l. undertakes to supply, free of charge, those parts which prove to be defective at origin. -
Page 10: Ec Declaration Of Conformity
User and maintenance manual - UCP Fly 1.15 EC Declaration of Conformity THE MANUFACTURER FRANCO s.r.l. Company Via Nazionale, 80 12010 Address Postcode Province Cervasca Italy City State DECLARES under its own responsibility that the machine Humidifier / Cooler UCP Fly H15; UCP Fly H20; UCP Fly H25... -
Page 11: Installation
User and maintenance manual - UCP Fly 2 - INSTALLATION 2.1 Preliminary operations To operate the UCP Fly humidifier, you need: • Electrical network with voltage and frequency ratings suitable for the machine, with earthing and protective devices; • Water supply connection: required pressure 2- 4 atm (0.2-0.4 MPa); •... -
Page 12: Electrical Connections
User and maintenance manual - UCP Fly To avoid the formation of condensation, maintain a distance of at least 1m from the ceiling and surrounding walls (Fig. 2.2.1) while the distance from the wall in front of the machine should be determined according to the model chosen and the amount of water sprayed. -
Page 13: Hydraulic Connections
User and maintenance manual - UCP Fly 2.4 Hydraulic connections Make the connection to the water supply and drainage lines at the points provided. (Fig. 2.4.1): • Quick water inlet connection for connecting a Ø 3/8" hose. • Quick-connect drainpipe with cap for connection of a Ø 3/8" hose. A specific accessory (Fig. -
Page 14: Operation
User and maintenance manual - UCP Fly 3 - OPERATION 3.1 Preliminary operations Before operating the humidifier, check that: • All connections, both electrical and hydraulic, have been made according to the instructions in this manual; • The humidifier is free and clean; •... -
Page 15: Maintenance
User and maintenance manual - UCP Fly 4 - MAINTENANCE The operations described in this chapter must only be carried out by authorised and qualified personnel, using suitable personal protective equipment. Before carrying out any work, disconnect the appliance from the electricity and water supplies. Check periodically that the water flow rate to the centrifuge is correct. -
Page 16: Replacing And Cleaning The Pump
User and maintenance manual - UCP Fly 4.3 Replacing and cleaning the pump To replace the pump, proceed as follows: • Unscrew the two cover screws using a Phillips screwdriver and remove the cover. • Unscrew the plastic wing nut from the float arm. Hold down the stop ring in which the pump is fitted with a fixed spanner (hex 13) and gently pull the pump out. -
Page 17: Replacing The Float
User and maintenance manual - UCP Fly Mx8 screw40 Fig. 4.4.3 Fig. 4.4.4 • Once the disc has been removed, remove the M8x40 screw by unscrewing it from the rotating disc. • Apply a small amount of grease to the crankshaft and fit the new disc, making sure the keys are aligned and pressing on the centre, without tapping or forcing. -
Page 18: Technical Characteristics
User and maintenance manual - UCP Fly 5 - TECHNICAL CHARACTERISTICS 5.1 Technical data 50Hz Versions Atomization capacity up to 25 up to 25 up to 25 Power supply single-phase single-phase single-phase IP rating IP56 IP56 IP56 Weight Air flow rate m³/h 1100 1800... -
Page 19: Overall Dimensions
User and maintenance manual - UCP Fly 5.2 Overall dimensions 5.3 Electrical diagrams Ensure that the electrical supply characteristics complies with the table. Use cables with an appropriate cross-section for the rated current (A) of the device (see Section 5.1 'Technical characteristics'). Insert a thermomagnetic differential circuit breaker on the power line upstream of the equipment. -
Page 20: Spare Parts List
User and maintenance manual - UCP Fly 6. SPARE PARTS LIST... - Page 21 User and maintenance manual - UCP Fly...
-
Page 22: Troubleshooting Guide
User and maintenance manual - UCP Fly 7. TROUBLESHOOTING GUIDE The operations described in this chapter must only be carried out by authorised and qualified personnel, using suitable personal protective equipment. Before carrying out any work, disconnect the appliance from the electricity and water supplies. PROBLEM CAUSE SOLUTION... - Page 23 User and maintenance manual - UCP Fly...
- Page 24 User and maintenance manual - UCP Fly FRANCO s.r.l. Headquarters and factory: Via Nazionale 80 - 12010 - CERVASCA (CUNEO) Italy Tel. (+39) 0171 611663 www.francosrl.com info@francosrl.com For reports or requests, please contact us at support@francosrl.com...
