- Page 1 Original Instructions Version 1 CORDLESS AIR COMPRESSOR 20582...
-
Page 2: Preface
All photographs and drawings within this manual are document is part of the product; retain it for the life supplied by Draper Tools to help illustrate correct of the product, passing it on to subsequent holders. operation of the product. -
Page 3: Table Of Contents
2. Contents 1. Preface 1.1 Product Reference 1.2 Revisions 1.3 Understanding the Safety Content 1.4 Copyright © Notice 2. Contents 3. Warranty 4. Product Introduction 4.1 Scope 4.2 Specification 5. Health and Safety Information 5.1 General Safety Instructions for Compressors 5.2 General Safety Information for Battery Packs and Chargers 5.3 Connection to the Power Supply 6. -
Page 4: Warranty
This warranty period covers parts and labour for 24 months from the date of Your Draper Tools guarantee is not effective until you can purchase. Where tools have been hired out, the warranty produce, upon request, a dated receipt or invoice to period covers 90 days from the date of purchase. -
Page 5: Product Introduction
LED lamp for visibility and to attract operate or maintain the product, and retain it for later use. attention. Any other application beyond the conditions established for use will be considered misuse. Draper Tools accepts no responsibility for improper use of this product. 4.2 Specification Stock No. -
Page 6: Health And Safety Information
• WARNING! NEVER charge non-rechargeable adaptor or charger cords are damaged, they must batteries. be replaced by a special cord available from Draper Tools or its authorised service agents. • WARNING! DO NOT use the battery if there is evidence of leakage. If battery fluid comes into • ALWAYS ensure that the air hose and valve... -
Page 7: Connection To The Power Supply
5. Health and Safety Information 5.3 Connection to the Power Supply Always ensure that the power supply on the machine’s rating plate is compatible with the power supply to which you intend to connect it. The rechargeable battery pack is supplied with a UK standard three-pin plug and is intended for connection to a domestic power supply rated at 230V AC. -
Page 8: Identification And Unpacking
6. Identification and Unpacking 6.1 Product Overview (10) (11) LCD pressure display Attachment lock Compressor power button SMD LED light on/off switch Increase pressure button SMD LED light Decrease pressure button (10) Battery release button Trigger (11) 12V Battery pack Trigger lock –... -
Page 9: What's In The Box
If any part is occurred during shipment. damaged or missing, do not attempt to use the product. Please contact the Draper Helpline; contact details can be found at the back of this manual. (B1) -
Page 10: Preparing The Air Compressor
Charging may take up to three hours. The compressor (10) should run for approximately 15 minutes on a full charge. Important: To preserve the battery health, Draper Tools recommends that the compressor charging time does not exceed five hours. 7.2 Using the 12V DC In-Car Adaptor Fig. -
Page 11: Notes On Battery Life
• High-pressure loading or excessive back pressure may result in increased battery consumption. • Cold temperatures may result in increased battery consumption; Draper Tools recommends using the 12V DC in-car adaptor in cold conditions. – 11 –... -
Page 12: Operating Instructions
8. Operating Instructions Important: Read all Health and Safety instructions 3. To change the display pressure units, press the before using this product. compressor power button repeatedly until the required units are displayed. 8.1 Using the Compressor 4. Screw the threaded hose connector (B2) onto the Important: ALWAYS follow the manufacturer’s valve of the item to be inflated;... -
Page 13: Using The Inflation Adaptors
8. Operating Instructions 8.2 Using the Inflation Adaptors To attach the needle adaptor (C) or inflation adaptor (D), screw it into the threaded hose connector (B2) until tight. Operate the compressor as described in 8.1 Using the Compressor. 8.3 Using the Light Fig. -
Page 14: Maintenance And Troubleshooting
9. Maintenance and Troubleshooting Important: Maintenance and repairs should be carried • Keep all ventilation openings clean from dust and dirt. out ONLY by authorised and suitably qualified personnel. • Keep the air hose and adaptors clean and free from obstructions. WARNING! Disconnect the battery or power supply before carrying out any maintenance on the product. -
Page 15: Disposal
10. Disposal At the end of its working life, or when it can no longer be repaired, dispose of the product according to local regulations. Contact your local authority for details of collection schemes in your area. In all circumstances: • DO NOT dispose of power tools with domestic waste • DO NOT incinerate • DO NOT abandon in the environment... -
Page 16: Explanation Of Symbols
11. Explanation of Symbols Includes a surface-mounted diode Read the instruction manual LED light WEEE – Warning! Waste Electrical & Electronic Equipment Do not dispose of Waste Electrical & Electronic Equipment in with domestic rubbish Class II construction (Double insulated) UKCA –... - Page 17 Notes – 17 –...
- Page 18 Notes – 18 –...
- Page 19 Notes – 19 –...
- Page 20 General Enquiries: +44 (0) 23 8026 6355 General Fax: +44 (0) 23 8026 0784 Service / Warranty Repair Agents For aftersales servicing or warranty repairs, please contact the Draper Tools Product Helpline for details of an agent in your area. © Published by Draper Tools Limited...
