- Page 1 25 & 50 LITRE COMPRESSORS STOCK No. PART No. 52624 DA25/201 55274 DA25/230 33825 DA25/250 52625 DA50/201 55275 DA50/230 33826 DA50/250 • INSTRUCTIONS • IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY TO ENSURE THE SAFE AND EFFECTIVE USE OF THIS TOOL.
-
Page 2: Table Of Contents
PART Nos. DA25/201, DA25/230, DA25/250, DA50/201, DA50/230, DA50/250. Whilst every effort has been made to ensure accuracy of information given in this manual is correct at the time of going to print, the Draper Tools policy of continuous improvement determines the right to change specification without notice. -
Page 3: Specification / Guarantee
This guarantee applies in lieu of any other guarantee expressed or implied and variations of its terms are not authorized. Your Draper guarantee is not effective unless you can produce upon request a dated receipt or invoice to verify your proof of purchase within the 12 month period. -
Page 4: Safety Warning
Please read the following instructions carefully. Failure to do so could lead to serious personal injury. IMPORTANT: Draper Tools recommends that this compressor should not be modified or used for any application other than that for which it was designed. If you are unsure of it’s relative applications do not hesitate to contact us in writing and we will advise you. -
Page 5: Power Supply
POWER SUPPLY CONNECTING YOUR COMPRESSOR TO A POWER SUPPLY A separate electrical socket should be used for your machine. The circuit should not be less that a 13 amp ring main which should be protected by a 30 amp fuse or miniature circuit breaker rated at 30 amps. If an extension cable is used, use only 3-core extension leads with 3-pin sockets which will accept the machine’s plug. -
Page 6: Know Your Air Compressor
KNOW YOUR AIR COMPRESSOR ✱✌ ✫✌ ✪✌ PRESSURE GAUGE - ✮✌ indicates air pressure in receiver. ✫✌ ON/OFF SWITCH ✪✌ ✲✌ ✬✌ ✬✌ MOTOR ✭✌ RESERVOIR INSPECTION PLUG ✮✌ MOTOR COWLING - covers/protects moving parts. ✯✌ AIR RECEIVER - ✭✌ stores air. -
Page 7: Operation Cont'd
OPERATION Cont’d 4. To start the compressor turn the switch to the ON position as shown in Fig.4. The pressure switch is pre-set at the factory and the compressor is also fitted with an overload safety relief valve in the event of the pressure switch not functioning correctly. -
Page 8: Maintenance Cont'd
MAINTENANCE Cont’d PRESSURE SWITCH SETTINGS: The delivery pressure setting can drift over a period of time and will require periodic adjustment. Ensure that the pressure switch settings are correctly adjusted and maintained at the correct level. This will help prevent faults occurring which can result in reduced performance and possible failure. -
Page 9: Optional Accessories
OPTIONAL ACCESSORIES The following accessories are available from your local Draper air tool stockist. ⁄ " Combination Filter ⁄ " Combined Regulator/Lubricator Mini Oiler Filter/Regulator Part No.4222/3. Part No.4255. Part No.4222/3. Stock No.51857. Stock No.22311. Stock No.51858. HEAVY DUTY HEAVY DUTY ⁄... -
Page 10: Trouble Shooting Guide
TROUBLE SHOOTING GUIDE SYMPTOMS POSSIBLE CAUSES Thermal overload protection trips. Oil level low. Wrong direction of rotation. Pressure switch failure/motor overload. High oil consumption. Air filter clogged. Wrong type of oil. Broken piston rings. Oil pumping. Air filter clogged. Wrong type of oil Oil level too high. - Page 11 NOTES...
