1:10-SCALE 2WD MONSTER TRUCK KIT
ECX03034 // ECX03034l
INSTRUCTION MANUAL
Congratulations on your purchase of the ECX
®
AMP
®
MT 2WD Monster Truck kit. This 1:10-scale
BEDIENUNGSANLEITUNG
model introduces you to the sport of RC driving.
MANUEL D'UTILISATION
Herzlichen Glückwunsch zum Kauf des ECX AMP
MANUALE DI ISTRUZIONI
MT 2WD Monster Truck. Dieses 1:10 Scale Model
öffnet Ihnen die Welt des RC Car Sports.
Nous vous félicitons pour l'achat du ECX AMP MT
2WD Monster Truck. Ce modèle 1:10 vous introduit
au sport de la conduite RC.
Congratulazioni per l'acquisto di questo AMP MT
ECX 2WD Monster Truck. Questa vettura in scala
1:10 vi introdurrà nel mondo dei modelli RC.
