Remove The Packaging - GE JV966DSS Owner's Manual & Installation Instructions

TOOLS AND MATERIALS
REQUIRED
(NOT SUPPLIED)
Pencil and
tape measure Flat blade screwdrivers
Electric drill with
"
"
1/8 and 3/8 bits
Spirit level
Flashlight
Pliers
Hammer
Wire Cutter/
Stripper
Ladder
Additional Materials:
• 120V 60Hz. 15 or 20 Amp, 2 wire with ground.
Properly grounded branch circuit.
• Strain relief for junction box.
• 7" round metal duct, 3-1/4" x 10" rectangular duct
or 3-1/4" x 12" rectangular duct length to suit installation.
Installation Instructions
Phillips and Duct tape
"
1/4 pivoting hex socket
Safety glasses
UL Listed Wire nuts
Tin Snips
Saber saw or Key Hole Saw
Allen
Wrench

REMOVE THE PACKAGING

• Remove the small box housing the motor.
• Lift the hood out of the box.
Wood
Mounting
Support
• Remove shipping screws holding the wood mounting
piece to the back side of the hood. Set aside wood
mounting piece and screws for later installation. Do not
discard.
• Remove the
"V"
• Remove parts package from the
insert.
• Remove junction box cover and knockout.
• Install strain relief onto back or top of hood.
• Remove all tape and packing material from the
hood, duct transition and motor.
11
Hood
Motor
Parts
Package
Shipping Carton
shaped carton insert.
shaped cardboard
"V"
