- Page 1 Air decontaminator and purifier Clever Models: Tion Clever, Tion Clever MAC We care about the environment and strive not to create unnecessary printed materials. For that reason, please choose a language and scan the code. tion.global / tion.ru...
- Page 2 #BreatheCleanAir Dear user, Thank you for buying this air decontaminator and purifier Clever...
-
Page 3: Table Of Contents
Table of contents General information Device and package contents Getting started Display Controls Maintenance Troubleshooting Specification Safety Other requirements Warranty Compliance certificates Contacts... -
Page 4: General Information
General information The Tion Clever air decontaminator and purifier is designed to purify and disinfect indoor air by means of recirculation. 1 — the device takes air from the room; 2 — the prefilter protects the device from large waste;... - Page 5 Takes air from the room • Purifies • Provides clean air to the room Windows are closed • The breezer circulates fresh air into the room • Tion Clever provides continuous air purification • Contaminated air is forced out into the exhaust openings...
-
Page 6: Device And Package Contents
Device and package contents 1 — device; 2 — front panel; 3 — filtration unit; 4 — volumetric complex filters; 5 — prefilter; 6 — mounting template; 7 — documentation; 8 — IR remote control. -
Page 7: Getting Started
Press the power control button located on the bottom of the device. The lower half of the indicator light on the Tion Clever model will flash blue. The indicator light on the Tion Clever MAC will flash alternately between the upper and lower halves This is when the MagicAir base station should be paired. -
Page 8: Display
Display Lights The bottom and top The display panel flashes The lower half is lit blue halves flash blue yellow 3 times Operation mode at alternately MagicAir base station speed 1 Pairing mode (searching pairing error for a MagicAir base station) Both halves are lit blue The lower half flashes... -
Page 9: Controls
Operation — in this mode, the device continuously purifies indoor air. Pairing — this mode automatically activates for the Tion Clever MAC model after connection to the power supply. In this mode, the device searches for a MagicAir base station for one minute, then switches to Standby mode. - Page 10 It measures the air quality of the room, automatically controls the breezer depending on the CO level of the room, and regulates the operation of other climate control equipment. Available for iOS (11.0 and above) and Android (5.0 and above). Not included. Available to order at www.tion.ru/shop/magicair/...
-
Page 11: Maintenance
Maintenance The filtration unit contains an electrostatic unit that is a source of high static charge. Do not expose the charger's electrodes (plates or strings) to bare skin. Filter replacement Use the button to turn off Disconnect the device Remove the front panel Pull the filtration unit's the device and wait 10 from the power supply... - Page 12 Place the filtration unit in Snap the catchers into Put the front panel back Remove the device from the devicesome force) place (this may require in place the wall some force) Unscrew the lid of the Connect the device to the Press and hold the button When the indicator light electronics unit...
- Page 13 Electrostatic unit purification Do not use excessive force when cleaning the discharge electrodes (strings) Disruption of the electrode will reduce the filtration effectiveness and disinfecting properties of the device. Disconnect the device Remove the front panel Pull the filtration unit's Remove the filtration unit from the power supply catches towards you...
-
Page 14: Troubleshooting
Troubleshooting MagicAir Malfunction Possible cause Solution app code Check that the mains is supplying voltage The device doesn't start The socket is not and that it conforms to – (indicator panel is off) providing power the value given in the Specifications section of this manual Indicator panel blinks... - Page 15 If the above methods do not resolve the problem, please contact an authorized service center or Tion Service Center. Please have your personal information and the serial number of the device ready. The serial number of the device is specified on the warranty card and can also be found in the locations shown in the figure below.
-
Page 16: Specification
Specifications Parameter Tion Clever Tion Clever MAC Nominal wattage, W Disinfection efficiency, % (min.) 99,9 Efficiency class of the device for retaining pollutants, % (min.) Microorganism inactivation effectiveness of filters for all types 99,95 of viruses, bacteria and mold spores, (no less than) % Permissible temperature range in the room, °C... -
Page 17: Safety
Safety Failure to comply with these requirements may result in device breakage and/or health and safety hazards. The device is not intended for use by people (including children) with reduced physical, sensory or mental capabilities or those lacking in life experience or knowledge unless supervised or instructed by someone responsible for their safety. - Page 18 During lightning storms, the device must be turned off and unplugged from the mains. Do not reset the filter replacement counter for a new cycle without first replacing the filters. Continued use of depleted filters can lead to decreased performance, increased fan noise, and device failure.
-
Page 19: Other Requirements
Disposal Tion Smart microclimate, JSC defines the lifetime of this product as 5 years, provided installation is conducted correctly and that the rules of operation are followed. Upon the expiration of the product's service life, please discontinue using the device and contact the Vendor's service center for recommendations on the further use of the device or its disposal. -
Page 20: Warranty
Warranty Warranty terms Tion Smart microclimate, JSC sets the warranty period of this product at 2 years. This period is effective provided that the device mounting and operating guidelines have been followed. Warranty services are provided in accordance with the applicable legislation in the region of purchase. -
Page 21: Compliance Certificates
Compliance certificates Compliance certificates are publicly available online at https://tion.ru/about/doc This device is compliant with: 2014/35/EU Low Voltage Directive 2014/30/EU Electromagnetic Compatibility Equipment Directive 2014/53/EU Radio Equipment Directive 2015/863/EU Restriction of Hazardous Substances Directive Date of Manufacture DD.MM.YY. QC stamp... -
Page 22: Contacts
Contacts Contacts of Tion Smart microclimate, JSC Service Department serviсe@tion.ru tion.ru/service Manufacturer Airservice LLC. 7/1, Zelenaya Roscha St., Berdsk, Novosibirsk region, Russia, 633009 Factory Hanking Plastic Manufactory (ShenZhen) Co.Limited 16 Xihutang Street, Longgang District, Shenzhen 518117, P. R. China Person authorized to accept product claims Tion Smart microclimate, JSC Office 112, 20 Inzhenernaya St., Novosibirsk, Russia, 630090... - Page 24 #BreatheCleanAir...
