USER MANUAL
Air decontaminator and cleaner
model: Tion Clever, Tion Clever MAC

Advertisement

loading
Need help?

Need help?

Do you have a question about the Clever and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Tion Clever

Summary of Contents for Tion Clever

  • Page 1 USER MANUAL Air decontaminator and cleaner model: Tion Clever, Tion Clever MAC...

  • Page 2: Table Of Contents

    CONTENTS GENERAL INFORMATION DELIVERY SET SAFETY MEASURES TECHNICAL CHARACTERISTICS PRINCIPLE OF OPERATION AND CONTROL GETTING READY TO START MAINTENANCE SERVICE STORAGE, TRANSPORTATION, DECOMMISSIONING WARRANTY ACCEPTANCE CERTIFICATE...

  • Page 3: General Information

    (biological laboratories, clean production, etc.) To disinfect and purify the air the patented TION technology is used, which is also employed in similar medical devices. Removing or incorrectly installing at least one of the filters directly affects main function of the device.
  • Page 4 Air decontaminator and cleaner Tion Clever Copy of certificate of compliance can be found at tion.global/doc. Developed by: Airservice LLC. 7/1 Zelyonaya Roscha st., Berdsk, Novosibirsk Region, 633009, Russia. Manufactured by: Hanking Plastic Manufactory (ShenZhen) Co. Limited. #16 Xihutang Street, Longgang District, 518117, Shenzhen, Guangdong, P.R. China...
  • Page 5 Nylon dowel 8×50 Thread cutting screw 4,5×60 (for device mounting) You can upgrade a Tion Clever version device to Tion Clever MAC version. Please contact the seller's service center or any authorized service center to install the RF module Service centers addresses can be found in the warranty certificate.

  • Page 6: Safety Measures

    Air decontaminator and cleaner Tion Clever 3. SAFETY MEASURES The following designations are used throughout this User Manual: CAUTION! Failure to conform to these requirements may cause breakdown of the device or create conditions that are dangerous to human health or life.
  • Page 7 User manual Before putting the device into operation please leave it in a warm room for 4 hours to avoid its failure, formation of condensation and damage to its plastic parts after storing or transporting the device at low temperatures. Do not operate the device in rooms with the air temperature below +10°C and above +35°C.
  • Page 8 Air decontaminator and cleaner Tion Clever 4. TECHNICAL SPECIFICATIONS Technical specifications of the device are shown in Table 4.1. Table 4.1 — Technical specifications Tion Clever Tion Clever MAC Parameter Value Disinfection efficiency, % (not less) 90,0 90,0 Class of effectiveness of the device for detaining...
  • Page 9 5. OPERATING PRINCIPLE AND OPERATION 5.1. Configuration Configuration of Tion Clever disinfectant – air purifier is shown in Figure 5.1. Figure 5.1 — Configuration of Tion Clever disinfectant – air purifier 1 — front panel; 2 — fan unit; 3— indication panel; 4 — base;...
  • Page 10 Air decontaminator and cleaner Tion Clever 5.2. Principle of operation УThe device is mounted/installed onto a wall or a movable base . The fan unit (Fig. 5.1, item 2) creates a constant pressure drop inside the device, providing a directed air flow.
  • Page 11 Pairing Mode Pairing Mode is only available for devices with the Tion Clever MAC version. After Concentration of ozone in the electrostatic unit is guaranteed to be lower than TLVce. For Tion Clever MAC version.
  • Page 12 When the power is applied, the indicator light panel will turn blue and the device of Tion Clever version will start working at high (second) speed. Tion Clever MAC version device will switch to Pairing Mode for one minute before starting operation.
  • Page 13 User manual 5.3.3. Light indication The device status is monitored via the light display panel (Fig. 5.3, item 1). Figure 5.3 — The device interfaces 1 — light indication panel; 2 — decorative panel lock; 3 — power button. The light display panel consists of two parts: the lower and upper ones. The device status and its corresponding display options are described in Table 5.1.
  • Page 14 Air decontaminator and cleaner Tion Clever № Light indication Device status Display panel lights yellow for 3 seconds, then blue for Warning "Less than 60 days before filter 7 seconds, alternately (the replacement" device still operating) Display panel flashes blue Warning of non-critical contamination of the (2.8 seconds, then pauses...
  • Page 15 MagicAir microclimate control system includes a cloud data storage (a server), MagicAir mobile application, MagicAir BS310 base station and other devices. Air decontaminator and cleaner Tion Clever is an operational unit. To use it in MagicAir system you must purchase a base station and install MagicAir app to your smartphone.

  • Page 16: Getting Ready To Start

    Air decontaminator and cleaner Tion Clever 6. GETTING READY TO START 6.1. Unboxing and visual inspection Inspect the device after transportation: remove it from the transport package and make sure that it is not damaged. If there is damage ask the deliverer to confirm the damage in writing.
  • Page 17 User manual If two devices are installed in a room they should be placed as far away from each other as possible, for example, at the opposite walls of the room. When placing the device it is necessary to ensure the free flow of air into the device and the free release of air from it.
  • Page 18 Air decontaminator and cleaner Tion Clever 6.3. Mounting the device 6.3.1. Mounting on the wall To mount the device on the wall of a room please follow these steps: 6.3.1.1. Select the intended location for mounting the device on the wall using the mounting template.
  • Page 19 User manual 6.3.1.2. Use the mounting template to mark the places for the four mounting holes on the wall (Fig. 6.2); Figure 6.2 — Marking the installation location of the device 6.3.1.3. Drill 4 holes in the wall not less than 58 mm deep, insert dowels into them and introduce self-tapping screws (Fig.
  • Page 20 Air decontaminator and cleaner Tion Clever Figure 6.4 — Location of screws fixing the brackets 6.3.2. Installation of the device onto movable base To install the device onto movable base perform the following steps: 6.3.2.1. Assemble the movable base 6.3.2.2. Take the front panel off;...
  • Page 21 User manual 6.4. Electrical connection To put the device into operation, connect it to a power outlet using a cable with a plug. Required network parameters: single-phase, 230 V~, 50 Hz with protective ground. Parallel connection with other devices is allowed, provided that the rules of electrical and fire safety are observed.
  • Page 22 Air decontaminator and cleaner Tion Clever 7. SERVICE MAINTENANCE 7.1. General provisions The device requires periodic maintenance during operation. Maintenance of the device consists of cleaning the electrostatic charger unit, replacing the pre-cleaning filter and replacing complex filters. The frequency of service depending on the operating conditions is given in Table 7.1.
  • Page 23 User manual 7.2. Procedure of service maintenance CAUTION! The electrostatic unit is a source of life-threatening voltage. Prior to taking the filtering unit out of the device: 1) switch off the device by pressing the Power button on the bottom panel of the device; 2) wait for 5 minutes until the electrostatic unit gets discharged;...
  • Page 24 Air decontaminator and cleaner Tion Clever ATTENTION! Do not apply any force when wiping the corona electrodes. The rupture of the electrode will lead to a decrease in filtration efficiency and deterioration of the device's disinfecting properties. If the plates or electrodes can not be cleaned with the alcohol solution use 3% solution of hydrogen peroxide to remove the contamination.
  • Page 25 7.2.5.8. Replace the cover of the electronics unit and fix it with screws. 7.3. Troubleshooting If the device malfunction indication appears (Table 7.2) disconnect the Tion Clever air purifier from power supply. Check whether the problem can be resolved using the methods described in the "Troubleshooting"...
  • Page 26 Air decontaminator and cleaner Tion Clever MagicAir soft- № Fault Possible cause Solution ware code The display panel — Filters must be Please replace filters lights yellow for replaced within 60 (see Clause 7.2.) 3 seconds, then days blue for 7 seconds...

  • Page 27: Storage, Transportation, Decommissioning

    User manual 8. STORAGE, TRANSPORTATION AND DECOMMISSIONING Before commissioning the device and items from the delivery set should be stored and transported in their original packaging. The storage room must meet the following requirements: • air temperature −50 to +40 °C; •...

  • Page 28: Warranty

    Tion Smart microclimate JSC expresses its gratitude to you for choosing it. Tion Smart microclimate JSC sets the assigned service life for the device to 3 years, subject to the installation and operation requirements. The warranty period is 1 year and is counted from the date of sale, subject to the rules of operation.
  • Page 29 User manual Dear customers, Please contact your seller should you have any enquiries concerning warranty issues. Tion customer service support: e-mail: global@tion.ru tion.global...

  • Page 30: Acceptance Certificate

    Air decontaminator and cleaner Tion Clever ACCEPTANCE CERTIFICATE Air decontaminator and cleaner Tion Clever Serial number Conforms to TU 28.25.14.110-005-41364524-2017 and recognized as serviceable. QA Department Stamp Ver. 2.0.0...
  • Page 31 Tion Smart microclimate, JSC 20 Inzhenernaya st., Novosibirsk, 630090, Russia e-mail: service@tion.ru www.tion.ru...
