Installation Guide
Condenser Coil Header Bracket
Model Number
KIT15449
June 2009
Used With
T/YC*241E**(M/N/P/R)A* (with reheat)
T/YC*300E**(0/A/B/C/F/G)B*
T/YC*301E**(0/A/B/C/F/G/H/J/K/L)A*
ACC-SVN126A-EN

Advertisement

loading
Need help?

Need help?

Do you have a question about the KIT15449 and is the answer not in the manual?

Questions and answers

Related Manuals for Trane KIT15449

Summary of Contents for Trane KIT15449

  • Page 1 Installation Guide Condenser Coil Header Bracket Model Number Used With KIT15449 T/YC*241E**(M/N/P/R)A* (with reheat) T/YC*300E**(0/A/B/C/F/G)B* T/YC*301E**(0/A/B/C/F/G/H/J/K/L)A* ACC-SVN126A-EN June 2009...

  • Page 2: Warnings, Cautions And Notices

    NOTICE All brackets and weights in this kit must be installed. Parts List Required Tools KIT15449 Voyager 2 R410A bracket kit Base Bracket for R410A units 7/16" box end ratchet wrench Tube to Tube Bracket 5/16" magnetic bit 7/8"...

  • Page 3: Installation

    Installation WARNING Hazardous Voltage W/ Capacitors! Disconnect all electric power, including remote disconnects and discharge all motor start/run capacitors before servicing. Follow proper lockout/tagout procedures to ensure the power can not be inadvertently energized. Verify with an appropriate voltmeter that all capacitors have discharged.
  • Page 4 Installation Figure 2. Base bracket installation a. Bottom of tube to tube clamp close to highest tube radius. b. Base bracket parallel to #1 cicuit. c. Install 1/4" flange nuts finger tight until base bracket bottom is secured with #10 sheet metal screws. After base bracket is installed, fully tighten the 1/4"...
  • Page 5 Installation 7. Install two weights on the discharge lines in the locations shown in Figure 5 Figure depending on the unit model. NOTICE Improper location or attachment of the weights will lead to running vibration failures. The weights must be at the correct section of the tube. The edge of the weight is placed close to the bend radius.
  • Page 6 Installation Figure 6. Weight locations for T/YC*241E**(M/N/P/R) a. Position weights within one inch of the bend radius and clear of compressor. ACC-SVN126A-EN...
  • Page 8 Literature Order Number ACC-SVN126A-EN Date June 2009 Supersedes The manufacturer has a policy of continuous product and product data improvement and reserves the right to change design and specifications without notice. Only qualified technicians should perform the installation and servicing of equipment referred to in this literature.
