- Page 1 Sirius_Shuttle_Vehicle_Installation.book Page 1 Friday, March 12, 2004 4:56 PM SIRCR Vehicle Installation Kit Vehicle Installation Guide...
- Page 2 Sirius_Shuttle_Vehicle_Installation.book Page 2 Friday, March 12, 2004 4:56 PM...
- Page 3 Sirius_Shuttle_Vehicle_Installation.book Page 1 Friday, March 12, 2004 4:56 PM Dear Customer Congratulations on your purchase of the world’s finest brand in the electronic industry. At Clarion we are committed to high-quality sound reproduction, and are confident that you will be pleased with your purchase.
-
Page 4: Fcc Notice
If this condition persists after corrective action, consult your dealer or experienced installation facility. Copyright and Trademarks This document is copyrighted by Clarion. You may not copy any portion of it without permission. SIRIUS is a registered trademark of SIRIUS Satellite Radio. -
Page 5: Table Of Contents
Sirius_Shuttle_Vehicle_Installation.book Page 3 Friday, March 12, 2004 4:56 PM Contents Installation cautions ... 5 Listening options ... 6 Connecting using an audio cable ... 6 Connecting using FM transmission ... 7 Install the cradle ... 7 Install the cradle in the base ... 9 Using other manufacturer’s mounts ... -
Page 6: Package Contents
Sirius_Shuttle_Vehicle_Installation.book Page 4 Friday, March 12, 2004 4:56 PM Vehicle Installation Guide 1. Package contents In addition to this manual, this kit includes the following: Power adapter Car antenna Audio cable Cradle installed on base 4 Phillips machine 4 split lock washers (M4) 4 flat washers (M4) 1 alcohol swab screws (M4 x 8 mm) -
Page 7: Installation Cautions
Sirius_Shuttle_Vehicle_Installation.book Page 5 Friday, March 12, 2004 4:56 PM 2. Installation cautions • To prevent a short-circuit, turn off the ignition and remove the negative (-) battery cable before starting to install. Connect the power wires last. • Do not install the receiver where it will receive direct sunlight or be subject to extreme temperatures. -
Page 8: Listening Options
Sirius_Shuttle_Vehicle_Installation.book Page 6 Friday, March 12, 2004 4:56 PM Vehicle Installation Guide 3. Listening options Note If you are uncomfortable installing components in your car, enlist the help of a professional installer. The Plug and Play receiver and cradle provide an audio output signal that you may connect: •... -
Page 9: Connecting Using Fm Transmission
Sirius_Shuttle_Vehicle_Installation.book Page 7 Friday, March 12, 2004 4:56 PM Connecting using FM transmission Vehicle Left side radio of cradle antenna Vehicle FM radio Power adapter Wireless connection The cradle supports ten FM transmission frequencies. Turn the Plug and Play receiver on. Confirm that the FM Transmitter option is set to FM ON. - Page 10 Sirius_Shuttle_Vehicle_Installation.book Page 8 Friday, March 12, 2004 4:56 PM Vehicle Installation Guide Caution Do not install the cradle or mounting base on a leather or fabric surface, or in a position that could impair your vision, block air bags or obstruct vehicle dashboard controls, including radio CD/cassette operational displays.
-
Page 11: Install The Cradle In The Base
Sirius_Shuttle_Vehicle_Installation.book Page 9 Friday, March 12, 2004 4:56 PM Install the cradle in the base The cradle comes with two mounting plates, one on the rear and the other on the bottom of the receiver. Rear view of cradle Bottom mounting plate Screws Bottom of cradle Mounting plates and screws... -
Page 12: Using Other Manufacturer's Mounts
Sirius_Shuttle_Vehicle_Installation.book Page 10 Friday, March 12, 2004 4:56 PM Vehicle Installation Guide Unscrew the star nut and ball strut assembly from the mounting base threaded socket. Remove the screw, lockwasher and flatwasher from the end of the ball strut. Insert the end of the ball strut into the keyed opening on the cradle mounting plate. -
Page 13: Removing The Receiver
Sirius_Shuttle_Vehicle_Installation.book Page 11 Friday, March 12, 2004 4:56 PM You may adjust the orientation of the cradle by loosening the star nut and tightening it when the cradle is in the desired viewing position. 6. Removing the receiver When it’s time to take the Plug and Play receiver with you, press the release button to remove it from the cradle and slide the receiver upwards. -
Page 14: Route The Cable
Sirius_Shuttle_Vehicle_Installation.book Page 12 Friday, March 12, 2004 4:56 PM Vehicle Installation Guide When connected to the Plug and Play receiver’s cradle, the antenna can receive the SIRIUS signal virtually anywhere as long as no obvious obstructions, such as buildings, high terrain, parking garages and tunnels block the satellite signal. - Page 15 Sirius_Shuttle_Vehicle_Installation.book Page 13 Friday, March 12, 2004 4:56 PM In SUVs and minivans, route the cable into the vehicle under the rubber molding of the hatch door or tailgate, and then under the interior trim. Note Avoid exposing the cable in the driver or passenger areas where it could become entangled in feet or other objects.
