Clarion PU-1569A-C Service Manual

PU-1569A
PU-1582A
SPECIFICATIONS
■
Radio section
Tuning system: PLL Frequency synthesizer system
Receive range: AM 530kHz to 1,710kHz
FM 87.9MHz to 107.9MHz
Intermediate frequency:
AM 450kHz
FM 10.7MHz
Quieting sensitivity: AM Less than 38dB
FM Less than 10dB
Separation: FM More than 26dB
Auto tuning stop sensitivity:
AM 42
FM 23
Tape section
Reproducting system:
4 track 2 program
2 channel stereo system
Wow and flutter: Less than 0.3
Separation: More than 40dB
Cross talk: More than 40dB
S/N ratio: Normal tape(120
More than 48dB(DOLBY B NR OFF)
More than 56dB(DOLBY B NR ON)
Metal tape(70
More than 50dB(DOLBY B NR OFF)
More than 58dB(DOLBY B NR ON)
Clarion Co., Ltd.
Export Division - 22-3, Shibuya 2-chome, Shibuyaku, Tokyo, 150 Japan
Service Dept.- 50 kamitoda,Toda-shi,Saitama,335 Japan Tel: 048-443-1111 FAX:048-433-6996
(at 26dB S/N)
μ
μ (at 30dB S/N)
± 3dB μ
3dB
± μ
％ (W.R.M.S)
μ s)
μ s)
Tel: 03-3400-1121
Service Manual
VOLKS WAGEN
Automobile Genuine
AM/FM Radio Cassette Stereo
PU-1569A-C
Model
Genuine No. 1CO 035 180
(
Illumination
PU-1582A-C
Model
Genuine No. 1JO 035 180A
(
Illumination
PU-1582A-D
Model
Genuine No. 1JO 035 180
(
Illumination
FF/REW time:
General
Output power:
Power supply voltage:
Consumptive current:
Dimensions(mm): 179(W)
Weight:
Dolby noise reduction manufactured under license
※
from Dolby Laboratories Licensing Corporation.
※ "DOLBY" and the double-D symbol are trademarks
of Dolby Laboratories Licensing Corporation.
※ Specifications and design are subject to change with-
out notice for further improvement.
COMPONENTS
■
PU-1569A-C/PU-1582A-C/PU-1582A-D
Main unit
- 1 -
Published by Service Dept.
298-5603-00 Jul.1997 P
Printed in Japan
： Red
： Red
： Green
120sec.(C-60)
40W × 4(MAX)
DC13.2V(10.8V to 15.6V)
Negative ground
Less than 10A(MAX)
× 50(H) × 159(D)
1.3kg
PU-1569A-C
PU-1582A-C/A-D
)
)
)
1
