Clarion PP-2538T Service Manual

PP‑2538T
SPECIFICATIONS
Output level: 3.0V +2/-2dB(at 1kHz)
Frequency Response: 17Hz to 20kHz +2/-2dB
Separation: More than 70dB
(at 1kHz, Filter:20kHz LPF)
Distortion: Less than 0.02%
(at 1kHz, Filter:20kHz LPF)
Power supply voltage: DC13.2V
Negative ground
Current consumption: 0.6A(during playing)
Dimensions(mm): 184(W) x56(H) x197.5(D)
Weight: 1.65kg
COMPONENTS
PN-2541K-A/PP-2538T-A
Main unit
NOTE
* Specifications and design are subject to change without
notice for further improvement.
* We cannot supply PWB with component parts in prin-
ciple.
When a circuit on PWB has failure, please repair it by
component parts base. Parts which are not mentioned
in service manual are not supplied.
To engineers in charge of repair or
inspection of our products.
Before repair or inspection, make sure to follow
the instructions so that customers and Engineers
in charge of repair or inspection can avoid suffer-
ing any risk or injury.
Clarion Co., Ltd.
50 Kamitoda, Toda-shi, Saitama 335-8511 Japan
Service Dept.: 5-66 Azuma , Kitamoto-shi, Saitama 364-0007 Japan
Tel: +81-48-541-2335 / 2432 FAX: +81-48-541-2703
PN‑2541K
-----------
Service Manual
NISSAN Automobile Genuine
6-Disc CD Changer Deck
PP-2538T
Model
(Genuine No.28184 4M560
/ID No.CE030)
PN-2541K
Model
(Genuine No.28184 AR260)
1. Use specified parts.
The system uses parts with special safety features against
fire and voltage. Use only parts with equivalent charac-
teristics when replacing them.
The use of unspecified parts shall be regarded as re-
modeling for which we shall not be liable. The onus of
product liability (PL) shall not be our responsibility in cases
where an accident or failure is as a result of unspecified
parts being used.
2. Place the parts and wiring back in their original positions
after replacement or re-wiring.
For proper circuit construction, use of insulation tubes,
bonding, gaps to PWB, etc, is involved. The wiring con-
nection and routing to the PWB are specially planned
using clamps to keep away from heated and high voltage
parts. Ensure that they are placed back in their original
positions after repair or inspection.
1
If extended damage is caused due to negligence during
repair, the legal responsibility shall be with the repairing
company.
3. Check for safety after repair.
Check that the screws, parts and wires are put back se-
curely in their original position after repair. Ensure for
safety reasons there is no possibility of secondary
ploblems around the repaired spots.
If extended damage is caused due to negligence of re-
pair, the legal responsibility shall be with the repairing
company.
4. Caution in removal and making wiring connection to the
parts for the automobile.
Disconnect the battery terminal after turning the ignition
key off. If wrong wiring connections are made with the
battery connected, a short circuit and/or fire may occur. If
extensive damage is caused due to negligence of repair,
the legal responsibility shall be with the repairing com-
pany.
- 1 -
Published by Service Dept.
298-6053-00 Feb.2003B
Printed in Japan
PP-2538T
PN-2541K
