- Page 1 Owner’s Manual / Mode d’emploi Benutzer-Handbuch / Manuale utente Handboek / Manual de usuario Ägarehandbok / Manual do Utilizador BLT433 CM-HS1/TEL003...
-
Page 2: Fcc Statement
FCC Statement This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Déclaration FCC Ce dispositif est conforme à... -
Page 3: Table Of Contents
Contents What is included in this package? Getting to know your module What is CM-HS1 Installation Installing CM-HS1 Fix CM-HS1 to the car sun visor Fix CM-HS1 to the dashboard Pairing your CM-HS1 ® I ntroduction to Bluetooth “pairing” Pairing the module Using your CM-HS1 Operating Modes Connection... -
Page 4: What Is Included In This Package
What is included in this package? Your BLT433 Car Hands Free Kit includes: CM-HS1 Module Visor Clip CE-NET Convertor Box Visor Clip Mounting ( TEL003 ) Screw External Microphone Note Please check for the correct accessories before attempting to install BLT433 in your car, please refer to the Wiring &... -
Page 5: Getting To Know Your Module
Getting to know your module What is CM-HS1? The CM-HS1 is a Bluetooth ® car kit that offers a high quality Bluetooth ® wireless connection for in-car use and utilises your car’s built-in audio ® system. This module works with any Bluetooth mobile phone that supports ®... -
Page 6: Installation
Installation Installing CM-HS1 It is important that the module is installed with the internal microphone facing towards the user. Use the Visor Clip to fix the module to the car sun visor, and route the main cable properly. ( shown in Fig. 2 ) Use the given mounting screws to tighten the module ( shown in Fig. -
Page 7: Fix Cm-Hs1 To The Car Sun Visor
Installation Fix CM-HS1 to the car sun visor Fig. 2 Fix CM-HS1 to the dashboard Fig. 3 BLT433... -
Page 8: Pairing Your Cm-Hs1
Please refer to mobile phone user documentation for profile information. Details on mobile phone compatibility and optimum setting visit www.clarion-eu.com Note that some mobile phones will not operate correctly if paired in the wrong mode. To pair a mobile phone follow the step below: 1. - Page 9 Always make sure the operation mode in the phone is on when ® Bluetooth using a car handsfree. Compatible with most Clarion CeNET units from 2001 lineup. For detail please check compatibility chart on www.clarion-eu.com, or consult your Clarion dealer. BLT433...
-
Page 10: Using Your Cm-Hs1
Using your CM-HS1 Operating Modes Once the CM-HS1 has been paired to a phone, it will enter either Listening or Connected mode. In Listening mode the CM-HS1 will be available to establish a connection to any of the paired devices in response to an incoming call. This is typical of phones connected as a Headset. -
Page 11: Calling With The Module Using Voice Commands
Using your CM-HS1 Calling with the module using voice commands If your phone support voice-activated dialing, you can use this feature with your module. Note that voice-activated dialing on your phone must be enabled and voice tags ( name and commands ) previously stored. ( Please refer to the phone’s user documentation for instructions on storing voice tags. -
Page 12: Answering A Call
In this case, you can transfer the call to the module by following the instruction in the next section. Note: The Clarion CE-NET car stereo must set to telephone interrupt mode to able work with the BLT433, details setting of the CE-NET car stereo please refer the owner’s manual of each model. -
Page 13: Call-Waiting
Using your CM-HS1 Call-waiting Some mobile phones allow you to accept another incoming call while you are using your module. This feature varies, dependent on mobile service provider and phone model. If you normally hear a beep on your mobile phone, you will still hear this beep through your car speaker or external speaker. -
Page 14: Understanding The Cm-Hs1 Indicators
Understanding the CM-HS1 indicators CM-HS1 provides indications of pairing and calling status as described in the following table. Mode Action Consequence Name LEDs Control Duration Idle Short On @6s (Pairing Table Volume-Chord Short Start Handsfree Empty) pairing Call Short Start Handsfree pairing Pairing Alternating Flash on @ s... - Page 15 Understanding the CM-HS1 indicators Mode Action Consequence Name LEDs Control Duration Connected (Service) Call Short Start voice activated calling Call Long Return to Listening mode Connected Flash off @2s Call Short Start voice activated calling Call Long Return to Listening mode Ringing Short...
- Page 16 Understanding the CM-HS1 indicators Mode Action Consequence Name LEDs Control Duration Volume-Down Short Reduce speaker volume Volume-Up Long Mute microphone Volume-Down Long Mute microphone Call Active (MIcrophone Mute) Call Short Clear call Call Long Transfer call to mobile Volume-Up Short Increase speaker volume Volume-Down...
-
Page 17: Wiring Diagram ( Tel003 )
Wiring Diagram ( TEL003 ) To car stereo To CM-HS1 telephone mute line CE-NET in CE-NET out BLT433... -
Page 18: Specifications Cm-Hs1
Specifications ( CM-HS1 ) ® Transfer standard Bluetooth 1.0B/1.1, conforms to profile Frequency range 2.402~2.495 GHz, ISM band, license-free Radio channels Fast frequency hopping, 79 channels, 1600 frequency changes/second Range Sending performance 0 dBm (Class 3) ~approximately 10m Sensitivity –80 dBm Profile Headset profile + Hands Free Profile Interface... -
Page 19: Tel003
Specifications ( TEL003 ) 14.4V DC ( 10.8~15.6V allowable ) Power supply voltage negative ground Max. Current 4 ( 4 ~8 allowable ) Speaker Impedence Max Output Power Max Switching Input Less than 0.05% Distortion More than 85dB S/N Ratio 30Hz ~ 15kHz ( 3dB ) Frequency Response Approx. -
Page 20: Troubleshooting
Troubleshooting This section lists some problems that you might encounter while using your car handsfree. See your phone owner’s manual for configuration. Cannot pair the car handsfree with the phone The Bluetooth ® function in your phone must be set to Automatic or On. Your phone should be inside the car during the pairing procedure. -
Page 21: Additional Information
Changes or modifications to this Bluetooth ® car handsfree not expressly approved by Clarion may void the user’s authority to operate the equipment. Please check for any exceptions, due to national requirements or limitations, in usage of Bluetooth ®... -
Page 22: Installation
Additional information Installation Please note that only authorised personnel should install the Bluetooth ® car handsfree. Please check with your car dealer for recommendations on professional installation engineers. Check with your car manufacturer’s representative to be sure that all equipment for the Bluetooth ®... -
Page 23: Electronic Equipment
Additional information RF energy may affect some electronic systems in motor vehicles such as car stereo, safety equipment etc. Check with your vehicle manufacturer’s ® representative to be sure that your mobile phone or Bluetooth handsfree will not affect the electronic systems in your vehicle. Electronic equipment Most modern electronic equipment is shielded from RF energy. -
Page 24: Emergency Calls
Additional information Emergency calls IMPORTANT! ® This Bluetooth car handsfree and the electronic device connected to the handsfree operate using radio signals, cellular and landline networks as well as user- programmed functions, which cannot guarantee connection under all conditions. Therefore you should never rely solely upon any electronic device for essential communications (e.g. -
Page 25: Ec Declaration Of Conformity
EN60950: 2000 - Information technology equipment Safety Part 1 General requirements. Following the provisions of Council Directive 1999/5/EC on radio equipment and telecommunications terminal equipment and the mutual recognition of their conformity. Mörfelden-Walldorf, Germany. S. Yamakawa: President Date : 16 March 2005 On behalf of Clarion Europa GmbH... - Page 26 This manual is published by Clarion, without any warranty. Improvements and changes to this manual necessitated by typographical errors, inaccuracies of current information, or improvements to programs and/or equipment, may be made by Clarion at any time and without notice. Such changes will, however, be incorporated into new editions of this manual.
- Page 27 280-8282-01 back cover...
