Summary of Contents for Clarion VMA7191
-
Page 1: Color Monitor
7” LCD Color Monitor OWNER’S MANUAL... -
Page 2: Table Of Contents
INTRODUCTION The Clarion VMA7191 is a full-featured 7" wide LCD Color Monitor that can be used as a stand alone monitor, or can be integrated into a mobile multimedia system. The VMA7191 has the following features: 7" wide-screen color LCD panel... -
Page 3: Description
DESCRIPTION The VMA7191 is a TFT active matrix color LCD monitor which delivers a striking picture and superior image resolution. The VMA7191 can be used to enjoy video images with the Clarion video sources, even if no TV tuner is connected. -
Page 4: Wiring Precautions
INSTALLATION The VMA7191 is a 7" monitor with an Infrared (IR) eye. It will accept a video sig- nal from any video source with composite video out. The IR eye will work direct- ly with any Clarion video source product with an IR Eye Input. -
Page 5: Mounting Options
Clarion's mounting bracket methods. The 1/4-20 hole accommodates the ZMT009 gooseneck mount when a bottom mounting screw location is necessary. The slot on the back of the VMA7191 also accom- modates dash-mount installations. In addition to this, the VMA7191 fits perfectly into all Clarion console shrouds, as well as our new headrest mounting bracket, HRM-100. -
Page 6: Notes
VMA7191 NOTES:... - Page 7 OWNER’S MANUAL...
- Page 8 661 West Redondo Beach Blvd. Gardena, CA 90247 1-800-GO-CLARION www.clarion-usa.com...
