Owner's manual & Installation manual
Benutzerhandbuch & Installationsanleitung
Руководство пользователя и Руководство по монтажу
Manual de instalación y manual del propietario
Manuale utente e guida di installazion
Manuel de l'utilisateur et manuel d'installation
VT1010E
10" OVERHEAD MONITOR SYSTEM WITH
DVD PLAYER & USB2.0 /SD /MMC PORTS
10"-DECKENMONITORSYSTEM MIT
DVD-PLAYER & USB2.0-/SD-/MMC-PORTS
10" ПОТОЛОЧНЫЙ МОНИТОР C DVD ПЛЕЕРОМ И
ПОРТАМИ USB2.0 /SD /MMC PORTS
SISTEMA DE MONITOR AÉREO DE 10" CON
REPRODUCTOR DE DVD & PUERTOS USB2.0 /SD /MMC
SISTEMA MONITOR RIBALTABILE DA 10" CON
LETTORE DVD E PORTE USB2.0 /SD /MMC
MONITEUR SUSPENDU DE 10" AVEC
LECTEUR DE DVD ET PORTS USB2.0 /SD /MMC
Advertisement
Table of Contents
Related Manuals for Clarion VT101OE
Summary of Contents for Clarion VT101OE
- Page 1 Owner’s manual & Installation manual Benutzerhandbuch & Installationsanleitung Руководство пользователя и Руководство по монтажу Manual de instalación y manual del propietario Manuale utente e guida di installazion Manuel de l'utilisateur et manuel d’installation VT1010E 10” OVERHEAD MONITOR SYSTEM WITH DVD PLAYER & USB2.0 /SD /MMC PORTS 10”-DECKENMONITORSYSTEM MIT DVD-PLAYER &...
- Page 2 Thank you for purchasing this Clarion product. Please read this owner’s manual in its entirety before operating this equipment. After reading this manual, keep it handy, such as in your glove compartment. Save your sales receipt. The warranty at the end of this manual and your sales receipt are essential for warranty service.
-
Page 3: Table Of Contents
Contents Contents 1. FEATURES ........................3 OVERHEAD MONITOR & IMAGE FEATURES ..................3 DVD VIDEO FEATURES .......................... 4 2. PRECAUTIONS ....................... 5 OPERATING ............................. 5 GENERAL ..............................5 MAINTENANCE ............................5 INSTALLATION............................6 3. CONTROLS ........................7 MONITOR CLOSED .......................... -
Page 4: Features
Clarion is not responsible for any injury and/or property damage as a result of the improper use or viewing of the monitor. The Clarion VT1010E overhead monitor players are engineered with advanced technological designs and components to combine flexibility with reliability, and expandability for the best picture quality and ease-of-use. -
Page 5: Dvd Video Features
1. FEATURES Capability to read: DVD /DVD±R /DVD±RW /CD-DA /CD-RW/MP3 /WMA /VCD /SVCD/DivX Note: Multi-session CDs and 320kbps WMA files cannot be played on this player. 3.5 mm Audio/Video Input DVD VIDEO FEATURES DVD drive that supports the following formats: DVDs (12cm) Video CDs (12cm) Audio CDs (12cm) -
Page 6: Precautions
Do not pour liquid into the unit or insert foreign objects into the DVD drive slot. Water, humidity and foreign objects may damage internal circuitry. If the unit becomes wet, turn off all power and consult your authorized Clarion Dealer for service. Do not operate the unit until it has been inspected and repaired. ... -
Page 7: Installation
If you do not have the required knowledge, experience, and/or tools to successfully complete the installation, consult an authorized Clarion Dealer about professional installation options. VT1010E... -
Page 8: Controls
3. CONTROLS 3. CONTROLS MONITOR CLOSED Dome Light switch Monitor Release button SD/MMC ports USB port Increase button Previous button Decrease button Next button Stop button Source button Operational Menu button Play / Pause button Power button Eject button Dome Light Dome Light IR window AUX In 3.5mm... -
Page 9: Monitor Open
3. CONTROLS In the MENU mode, press to select menu item up. Previous button Skips to the previous chapter on a DVD or track on a CD. During playback, press and hold to fast reverse playback Next button Skips to the previous chapter on a DVD or track on a CD. During playback, press and hold to fast forward playback Stop button Press once to stop playback. -
Page 10: Side Profile View
3. CONTROLS LCD Off switch Turns Off the LCD screen Reset button Press with a pencil or other narrow-tipped tool to return all setup options to their factory defaults. Screw hole Used to attach the player to the mounting plate. SIDE PROFILE VIEW Insert a DVD or a CD disc into the slot Back seat... -
Page 11: Remote Control
3. CONTROLS REMOTE CONTROL Setup Mute Power Eject Numbers Goto Display Previous Stop Play or Next Audio Volume Arrow keys Menu Fast reverse Subtitle Fast forward Random Title Repeat Source Zoom Return Angle VT1010E... - Page 12 3. CONTROLS Remote control buttons functions Power button Turns the player on and off. Setup Access the setup menu. Use to modify player options. Mute Disables and enables sound. Eject Ejects the current disc from the slot. Numbers Used to directly enter track numbers and to configure some options.
-
Page 13: Operations
4. OPERATIONS 4. OPERATIONS The monitor and DVD player provide the video; headphones provide the audio. The unit receives power from the power circuit of the car’s dome light, which is replaced by the unit. OPENING THE MONITOR Press the monitor release button to lower the overhead monitor screen. Monitor Release button Looking up at the monitor from directly below. -
Page 14: Handling Discs
4. OPERATIONS Note: When closing the display panel, do not let cords or other items get caught between the display and the overhead housing. Doing so can seriously damage the screen. For safety, close the LCD panel when you are not using it. HANDLING DISCS To keep a disc clean, do not touch the play side (non-label side). -
Page 15: Using Headphones
4. OPERATIONS “Loading.” Aim the remote control directly at the IR receiver on the player and press the play/pause button ( ) or press ENTER (on the remote). Using the remote control Use the remote control only inside the vehicle. ... - Page 16 4. OPERATIONS Headphone components Power light Power switch Volume dial Headphones Installing batteries in the headphones If this is the first time you’re using the system, install batteries in the headphones. Change the batteries when you begin to hear distorted audio that cuts in and out. Rotate the left earpiece so the battery cover is accessible.
-
Page 17: Playing Dvds
4. OPERATIONS PLAYING DVDs Accessing the root menu A DVD is divided into titles and chapters. The root menu shows the contents of the disc. Some DVDs only allow you to select disc playback options from the DVD root menu. To access the root menu of the DVD, press the RETURN or TITLE button during playback. - Page 18 4. OPERATIONS Off - resumes normal playback. Repeating favorite sections To repeat a favorite section you must first mark where it begins and ends. Play back the DVD. To identify the beginning of your favorite section (point A), press the A-B button when the section starts playing back.
-
Page 19: Playing Audio Cds
4. OPERATIONS PLAYING AUDIO CDs Displaying CD information To display the playing time and current track, press DISPLAY on the remote during CD playback. Continue pressing DISPLAY on the remote to view the disc type, current time, current track number, and total number of tracks. Repeating CD tracks To repeat a track or the entire CD, press REPEAT on the remote during playback. -
Page 20: Using The Usb Storage And Sd/Mmc Card
4. OPERATIONS selected folder. To select the MP3 file, press the up and down buttons on the remote. To play the file, press the ENTER button on the remote. MP3 controls To play back to the next MP3 file, press the next button ( ... -
Page 21: Care And Maintenance
The internal parts are not serviceable by the user. Opening any components will void the warranty. All warranty service should be performed by an authorized Clarion service center. CAUTION! Changes or modifications to this product not approved by the... - Page 22 4. OPERATIONS Procedure Note: The battery type must be CR2025. Do not replace with any other battery type. Turn the remote up-side-down. Simultaneously slide the battery latch in the direction of the arrow and pull the battery holder out of the slot. Battery holder Battery latch Remove the old battery.
-
Page 23: Installation And Wiring
5. INSTALLATION AND WIRING 5. INSTALLATION AND WIRING Do not attempt to install or service your player yourself. Installation and servicing require experience in electronic equipment and automotive accessories. If you do not have the knowledge or experience this installation may be dangerous and could expose you to the risk of electric shock or other hazards. -
Page 24: Mounting And Wiring Precautions
Do not open the case. There are no serviceable parts inside. If you drop anything into the unit during installation, consult with your Clarion Dealer or an authorized Clarion service center. MOUNTING AND WIRING PRECAUTIONS The VT1010E should be mounted in the ceiling of the vehicle. The front panel controls should be easily accessible from the rear seat. - Page 25 5. INSTALLATION AND WIRING CAUTION! Make sure the switch is fully to one side or the other. Do not attempt to configure this switch once the player is in position. Cut a one-inch hole in the headliner along the backside of the ceiling bracket for the cables to pass through.
- Page 26 5. INSTALLATION AND WIRING Plug in the power harness into the overhead monitor system in the following order: ground wire, battery wire, ACC wire and door wire. Note: The red lead must be connected to the ACC or IGN wire to the ignition switch. If you do not connect this wire properly, the battery will drain / discharge prematurely.
-
Page 27: Wiring Diagram
5. INSTALLATION AND WIRING WIRING DIAGRAM B+ (Yellow) ACC (Red) GND (Black) DOOR (Green) AV OUT AV IN 2 Polarity Switch AV1 IN Cable connections VT1010E... -
Page 28: Setting Preferences
6. SETTING PREFERENCES 6. SETTING PREFERENCES ACCESSING THE ON-SCREEN DISPLAY MENUS Press SETUP on the remote to access the OSD menus. Press up arrow and down arrow on the remote to select among menu items. Press left arrow and right arrow button on remote to alternate set items. Press up arrow and down arrow button to select the option you wish to change. - Page 29 6. SETTING PREFERENCES ENGLISH, FRENCH, SPANISH PARENTAL Restricts movie viewing to appropriate ages. 1 Kid Safe Material is safe for children. Material a safe for general audiences. 3 PG Parental guidance suggested. 4 PG-13 Some material unsuitable for children under 13. 5 PG-R Some material unsuitable for children under 17.
-
Page 30: Troubleshooting
7. TROUBLESHOOTING 7. TROUBLESHOOTING If operations freeze, the screen goes blank, or the player otherwise does not function properly, try turning it off and back on again. If it still does not respond, press the reset button on the front panel. Reset button Player with the monitor open PLAYER DOES NOT TURN ON... - Page 31 7. TROUBLESHOOTING THE PICTURE IS BLURRED You may be passing near a high voltage wire, transformer, aircraft or other source of electrical interference. The picture will improve when you move away from the source interference. THE PICTURE IS VERY DARK ...
-
Page 32: Specifications
8. SPECIFICATIONS 8. SPECIFICATIONS Power supply (car battery) 12V DC (10V-16V) Test voltage 14V, negative ground Operating current <20.7W Current consumption <82.8mW Max current consumption <27.6W Mechanism Manual open and close Video system Auto, NTSC and PAL Screen 10.2”diagonal Resolution (pixels) 800 x 480 Display angle Vertical adjustable up and down;... -
Page 33: Glossary
9. GLOSSARY 9. GLOSSARY Active matrix: A flat panel display technology that produces a brighter and sharper display and a broader viewing angle than passive matrix panels. Each pixel has its own thin film transistor (TFT) and is sometimes called a “TFT screen.” Aspect ratio: The comparison of the width to the height of an object. - Page 34 Clarion Europe S.A.S Z.I. du Pré à Varois, Route de Pompey, 54670 Custines, FRANCE Clarion CO., Ltd. Rights Reserved. Copyright © 2010: CIarion Co., Ltd. Printed in China / Imprime au Chiné / Impreso en China...
