Daikin VRV 5 REYA8A7Y1B Installer And User Manual page 175

REMA5+REYA8~20A7Y1B
VRV 5 heat recovery
4P687640-1 – 2022.07
Charge port / Service port
Stop valve
Filter
Check valve
Pressure relief valve
Thermistor
Solenoid valve
Heat sink (PCB)
Capillary tube
Expansion valve
4‑way valve
Propeller fan
High pressure switch
*PL: low pressure sensor
*PH: high pressure sensor
Oil separator
Accumulator
Heat exchanger
Compressor
PHE: plate heat exchanger
DT: double tube heat exchanger
Distributor
Liquid receiver
Muffler
27 Technical data
|
Installer and user reference guide
175
