- Page 1 SelectSpray 2700G ™ Instructions for use and parts list Kent MODEL 56011782 English 5/00 Form Number 56041502 Nilfisk-Advance Select Spray 2700G Operator’s Manual...
-
Page 2: Table Of Contents
STATEMENT OF WARRANTY WARNING The engine exhaust from this product contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm. TABLE OF CONTENTS Nilfisk-Advance Select Spray 2700G Operator’s Manual 10-13 14-15 16-17 20-25 BACK COVER... -
Page 3: Introduction
Be sure that all damaged parts are replaced and that the mechanical problems are corrected prior to operation of the unit. If you require service, contact Nilfisk-Advance Please have the following information available for all service calls: Nilfisk-Advance Select Spray 2700G Operator’s Manual INTRODUCTION ®... -
Page 4: Important Safety Warnings
The arrester must be maintained in effective working order by the operator. See your engine or equipment dealer for spark arrester muffler options. Nilfisk-Advance Select Spray 2700G Operator’s Manual... -
Page 5: Spray Precautions
Before removing the spray nozzle or servicing the unit, ALWAYS shut off the unit and trigger the gun to release trapped pressure. Nilfisk-Advance Select Spray 2700G Operator’s Manual DANGER... -
Page 6: Detergent Cleaning Precautions
Close supervision is necessary when operating the unit near children. 10. DO NOT leave pressurized unit unattended. Shut off the unit and release trapped pressure before leaving. 11. DO NOT move the unit by pulling on the hose. ® replacement parts for Nilfisk-Advance Select Spray 2700G Operator’s Manual... -
Page 7: Adjustment Precautions
Service in a clean, dry, flat area. Block the wheels to prevent the unit from moving. 5. Follow the maintenance instructions specified in this manual. ! SAVE THESE INSTRUCTIONS ! Nilfisk-Advance Select Spray 2700G Operator’s Manual ® parts for repair of your pressure washer. -
Page 8: Features Drawing
Example: Engine (4) FEATURES LISTING 10. Detergent Strainer 11. Detergent Hose 12. Oil Sight Glass 13. Adjustable Unloader Knob 14. High Pressure Discharge Hose 15. Gun Assembly 16. Decal-Warning: Risk of Injection 17. Quick Connect Nozzle Nilfisk-Advance Select Spray 2700G Operator’s Manual... -
Page 9: Safety Decals
SAFETY DECALS & PLACEMENT FOR SELECT SPRAY 2700G. !!!DO NOT REMOVE SAFETY DECALS FROM UNIT UNLESS REPLACING WITH MOST CURRENT SAFETY DECAL!!! REFER TO PAGE 8 FOR PLACEMENT Reference #2 Decal: Caution-Engine Fuel (Part 56623222) Reference #16 Decal: Warning-Risk of Injection (Part 56633325) -
Page 10: Installation & Preparation
7. Occasional carburetor and choke adjustments will be necessary for the engine. Refer to the engine manual supplied with this unit for proper adjustment procedures. 8. Review the engine manual accompanying this pressure washer for correct engine start-up and maintenance procedures. Nilfisk-Advance Select Spray 2700G Operator’s Manual... -
Page 11: Nozzle Review
2. The nozzle assembly should be disconnected from the gun/wand assembly at this by retracting the locking ring on the quick-connect fitting to remove the nozzle. QUICK-CONNECT FITTING Nilfisk-Advance Select Spray 2700G Operator’s Manual WARNING RISK OF INJECTION CAUSING SEVERE INJURY! -
Page 12: Water Supply
A "heat dump valve" (9) has been added to this unit to protect the pump. It may begin to open and release water if the water temperature in the pump has exceeded 140°F. This will allow fresh, cool water to enter the system. Nilfisk-Advance Select Spray 2700G Operator’s Manual ® #56632999 if necessary. -
Page 13: Pre-Start Inspection Procedures
UNTIL YOU HAVE READ AND UNDERSTOOD ALL SAFETY PRECAUTIONS AND INSTRUCTIONS LISTED IN THIS MANUAL. INCORRECT OPERATION OF THIS UNIT CAN CAUSE SERIOUS INJURY!! DO NOT ALTER OR MODIFY THIS EQUIPMENT IN ANY MANNER! Nilfisk-Advance Select Spray 2700G Operator’s Manual WARNING PRESSURE WASHER... -
Page 14: Operating Instructions
10. Because your pressure washer delivers a high pressure spray and a variety of spray patterns, there are many cleaning jobs that can be done without the use of detergents. If a cleaning agent is required, see "Cleaning With Detergents" pg. 15 for the correct procedures. Nilfisk-Advance Select Spray 2700G Operator’s Manual... -
Page 15: Cleaning With Detergents
4. Once pressure is relieved, disconnect the nozzle assembly. 5. Disconnect and drain gun, wand and hoses. 6. Wipe unit clean and store with gun, wand and hoses in a safe, non-freezing area. Nilfisk-Advance Select Spray 2700G Operator’s Manual QUICK CONNECT DETERGENT... -
Page 16: Storage & Maintenance
Nozzles should be replaced whenever pressure is less than 85% of the maximum. The frequency of replacement will depend upon such variables as mineral content in the water and number of hours the nozzle is used. Nilfisk-Advance Select Spray 2700G Operator’s Manual... -
Page 17: Winterizing
NOTE: When using this procedure, caution should be used as ice chips can form from drops of water which could cause the unit to burst if starting before completely thawed. Nilfisk-Advance Select Spray 2700G Operator’s Manual RISK OF UNIT BURSTING! DO NOT STORE/OPERATE UNIT IN A FREEZING ENVIRONMENT! ®... -
Page 18: Troubleshooting
Ball & Spring in Venturi stuck. Ball & Spring in Venturi reversed, missing or corroded. Gun is malfunctioning. Nilfisk-Advance Select Spray 2700G Operator’s Manual REMEDY Refer to the Engine Manual accompanying your unit. Allow to thaw. If any part of the unit becomes frozen;... - Page 19 NOTES Nilfisk-Advance Select Spray 2700G Operator’s Manual...
-
Page 20: Parts Listing
FRAME ASSEMBLY FOR 2700G Nilfisk-Advance Select Spray 2700G Operator’s Manual... - Page 21 Gun & Wand Assy. Quick Connect Plug Grip Handle Wand-36" w/Handle Quick Connect Socket O-ring Decal-Warning: Risk of Injection *Must order in one foot lengths. Nilfisk-Advance Select Spray 2700G Operator’s Manual FRAME ASSEMBLY FOR 2700G JP27030KHB PART # QTY. 56623233 56623216 56623221 56623319...
- Page 22 PUMP ASSEMBLY (56623203) Nilfisk-Advance Select Spray 2700G Operator’s Manual...
- Page 23 Single Valve Assy. (Inc. 44-48) (See 56623342) O-ring Valve Seat (See 56623342) Valve Plate (See 56623342) Valve Spring (See 56623342) Valve Cage (See 56623342) Bolt Nilfisk-Advance Select Spray 2700G Operator’s Manual PUMP ASSEMBLY (56623203) PART # QTY. REF. # DESCRIPTION 56633192 Lockwasher 56633461...
- Page 24 GUN ASSEMBLY (56632913) Nilfisk-Advance Select Spray 2700G Operator’s Manual...
- Page 25 Screw Brass Housing Gun Repair Kit Brass Plug Plastic Cover Pipe Assembly Trigger Pin Trigger/Safety Lock-off Pipe Assembly- Inlet Complete Gun Assembly Nilfisk-Advance Select Spray 2700G Operator’s Manual 0MGEN013N-080294 GUN ASSEMBLY (56632913) PART # QTY. 56623123 56623182 56623126 56623336 56623234...
- Page 26 Nilfisk-Advance Select Spray 2700G Operator’s Manual...
- Page 27 Nilfisk-Advance Select Spray 2700G Operator’s Manual...
- Page 28 This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. Nilfisk-Advance, Inc. 14600 21st Avenue North Plymouth, MN 55447-3408 Nilfisk-Advance Select Spray 2700G Operator’s Manual...
