- Page 1 INSTRUCTION MANUAL 50cm High Velocity Wall Fan Model: DCWF50A For domestic household use only.
- Page 2 IMPORTANT THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE. Note also the information presented on the appliance CAUTION: FAILURE TO FOLLOW THESE INSTRUCTIONS MAY CAUSE INJURY AND/ OR DAMAGE AND MAY INVALIDATE YOUR WARRANTY Please read the operating instructions carefully before using your dehumidifier for the first time and keep them in a safe place.
- Page 3 • Children should be supervised to ensure they do not play with the appliance. • WARNING: To avoid danger of suffocation please remove all packaging materials particularly plastic and EPS and keep these away from vulnerable people, children and babies. •...
- Page 4 Exposed to the Near water If the power cable weather outdoors wires are frayed or cut Where small children No extension leads or Where the power may be left unattended power boards cable may be damaged On a slope or Where there is risk Where it may be uneven surface...
-
Page 5: Specification
Specification DCWF50A Model no. Colour Anthracite Power supply 220-240V~, 50Hz Rated power 125W Speed settings Air speed 6m/s Timer 1-7 hours Oscillation 75° Noise level 68db(A) Weight (net) 5.8kg Dimensions (w x d x h) 545 x 257 x 662... - Page 6 Assembly NOTE: Before you use the fan, it must be fixed on a strong, flat wall surface. The distance from the floor to the low edge of the guard grill must be more than 2.3m. 1. Draw a vertical line on the wall (Fig.2) 2.
- Page 7 Assembly 3. Insert a wall plug into each hole. 4. Place the bracket on the wall by aligning the three holes with the three wall plugs (Fig.4) 5. Use the three provided tapping screws to secure the bracket. Place the screws into the three holes aligned with the bracket, and drive the screws in to secure firmly against the wall.
-
Page 8: Operation
Operation Control Panel 1. Insert the plug into the socket and press the ON/OFF button. The light above this button will turn red, as an indication that the unit is on. Automatically, the unit will start to rotate on the first speed setting, and the first blue light above the SPEED button will turn on. - Page 9 Cleaning Over time, dust can accumulate on the rear grille cover and fan blades, which can affect the fans performance. It is recommended to clean the fan at least once a month. 1. Turn the unit OFF and disconnect the appliance from the power supply. 2.
-
Page 10: Maintenance
Warranty Please refer to the warranty card in the box for warranty information. For any troubleshooting advice, please contact the relative Customer Care Centre below. Glen Dimplex Australia Pty Ltd Glen Dimplex New Zealand Ltd 1340 Ferntree Gully Road, 38 Harris Road, East Tamaki,... - Page 12 Supplied by Glen Dimplex Australia 1340 Ferntree Gully Road, Scoresby, Victoria, 3179 © Glen Dimplex Australia. All rights reserved. Material contained in this publication may not be reproduced in whole or in part, without prior permission in writing of Glen Dimplex Australia.
