Product Description
Model EIR610-3SFP-T
Documentation Number: EIR610-3SFP-T_0708m
707 Dayton Road -- P.O. Box 1040 -- Ottawa, IL 61350 USA
Phone (815) 433-5100 -- General Fax (815) 433-5105
Phone (815) 433-5100 -- General Fax (815) 433-5105
Website:
www.bb-elec.com
Sales e-mail:
orders@bb-elec.com
-- Fax (815) 433-5109
Technical Support e-mail:
support@bb.elec.com
-- Fax (815) 433-5104
European Headquarters
B&B Electronics
Westlink Commercial Park -- Oranmore, Co. Galway, Ireland
Phone +353 91-792444 -- Fax +353 91-792445
Website:
www.bb-europe.com
Sales e-mail:
sales@bb-europe.com
Technical Support e-mail:
support@bb-europe.com
© 2008 B&B Electronics Mfg. Co. Inc. - Revised February 2008
B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com
B&B Electronics – Westlink Commercial Park – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445 – www.bb-europe.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EIR610-3SFP-T and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for B&B Electronics EIR610-3SFP-T

Summary of Contents for B&B Electronics EIR610-3SFP-T

  • Page 1 Product Description Model EIR610-3SFP-T Documentation Number: EIR610-3SFP-T_0708m 707 Dayton Road -- P.O. Box 1040 -- Ottawa, IL 61350 USA Phone (815) 433-5100 -- General Fax (815) 433-5105 Phone (815) 433-5100 -- General Fax (815) 433-5105 Website: www.bb-elec.com Sales e-mail: orders@bb-elec.com...
  • Page 2 Eight Port Managed Industrial Ethernet Switches User Manual B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com B&B Electronics – Westlink Commercial Park – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445 – www.bb-europe.com...
  • Page 3 This Equipment has been tested and found to comply with the limits for a Class-A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 4 Content Overview ..............1   Introduction ............... 1   Features ..............2   Packing List .............. 4   Hardware Description ..........5   Physical Dimensions (W x H x D) ......5   Front Panel ............... 5   Top View ..............6  ...

  • Page 5: Table Of Contents

    X-Ring Application ..........17   Coupling Ring Application ........18   Dual Homing Application ........18   Console Management ..........19   Connecting to the Console Port ......19   Pin Assignment ............19   Login in the Console Interface ....... 20  ...
  • Page 6 802.1x Commands Set ............. 39   TFTP Commands Set ............41   SystemLog, SMTP and Event Commands Set ....42   SNTP Commands Set ............43   X-ring Commands Set ............44   Web-Based Management ........46   About Web-based Management ......46  ...
  • Page 7 System Event Log - Event Configuration ....55   Fault Relay Alarm ........... 57   SNTP Configuration ..........57   IP Security .............. 60   User Authentication ..........61   Digital Input/Output..........62   Port Statistics ............63   Port Control ............64  ...
  • Page 8 RSTP - Port Configuration ..........77   SNMP Configuration ..........78   System Configuration ............78   Trap Configuration ............79   SNMPV3 Configuration ............ 80   QoS Configuration ..........83   QoS Policy and Priority Type ..........83   Port Base Priority .............
  • Page 9 Overview Introduction This managed industrial switch comes equipped with a proprietary redundant network protocol—X-Ring which provides an easy way to establish a redundant Ethernet network. With ultra high-speed recovery time (less than 300 ms) and a long MTBF (Mean Time Between Failures) the industrial switch will continue to operate until a Gigabit network infrastructure has been established, without requiring extra upgrade costs.
  • Page 10 Features 10/100/1000Base-T Mbps Ethernet ports SFP (mini-GBIC) ports (support 100/1000 Dual Mode) Full/half duplex flow control Auto-negotiation MDI/MDI-X auto-crossover Packet Buffer up to 1Mbits MAC Address up to 8Kbytes Surge (EFT) protection (3,000 VDC for power line) Ethernet EDS protection (4,000 VDC) Power Supply Wide-range Redundant Power Design Reverse Polarity Protection...
  • Page 11 Both of TX and RX Packet System Event Log System Log Server/Client SMTP e-mail Alert Relay Alarm Output System Events Security Port Security: MAC address entries/filter IP Security: IP address security management to prevent intrusion. Login Security: IEEE802.1X/RADIUS SNMP Trap Cold Start Power Status Authentication Failure...
  • Page 12 Packing List 1 x Managed Industrial Switch 1 x RS-232 DB9 to RJ-45 adapter 1 x CD Rom with this user manual 2 x Mounting Bracket and Screws Manual Documentation Number: EIR610-3SFP-T_0708M B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com B&B Electronics –...
  • Page 13 Hardware Description Physical Dimensions (W x H x D) 2.7 x 4.2 x 6.4 in (7.4 x 10.7 x 16.3 cm) Front Panel Manual Documentation Number: EIR610-3SFP-T_0708M B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com B&B Electronics –...
  • Page 14 Top View Wiring the Power Inputs Insert the positive and negative leads into the V+ and V- contacts on the terminal block connector. Tighten the wire-clamp screws Note Use 12 to 14 AWG wire Manual Documentation Number: EIR610-3SFP-T_0708M B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com B&B Electronics –...
  • Page 15 Wiring the Fault Alarm Contact Insert the wires into the fault alarm contact [NOTE] Use 12 to 24 AWG wire. [NOTE] Relay contacts are normally closed. [NOTE] The Relay Alarm also requires software configuration. Refer to the Web Based Management Fault Relay Alarm Section. Manual Documentation Number: EIR610-3SFP-T_0708M B&B Electronics Mfg Co Inc –...
  • Page 16 LED Indicators Status Meaning Green The switch is on No power available Green Power Source 1 available PWR1 Power Source 1 unavailable Green Power Source 2 available PWR2 Power Source 2 unavailable Power failure or port failure Fault Normal Operation The switch is the master of the X-Ring Green group...
  • Page 17 The port is disconnected or not operating (lower LED) at speed of 1000M Green Network device detected (Upper LED) Blinking Network is active (Upper LED) No device attached (Upper LED) P1 ~ P8 Yellow The port is operating in full-duplex mode (Lower LED) Blinking Data packet collision...
  • Page 18 All ports on this industrial switch support automatic MDI/MDI-X operation. You can use straight-through cables (See Figure below) for all network connections to PCs or servers, or to other switches or hubs. In straight-through cable, pins 1, 2, 3, and 6, at one end of the cable, are connected straight through to pins 1, 2, 3 and 6 at the other end of the cable.
  • Page 19 Cabling Use the four twisted-pair, Category 5e or above cabling for RJ-45 port connection. The cable between the switch and the link partner (switch, hub, workstation, etc.) must be less than 100 meters (328 ft.) long. The small form-factor pluggable (SFP) is a compact optical transceiver used in optical communications for both telecommunication and data communication applications.
  • Page 20 Second, insert the fiber cable of LC connector into the transceiver. LC connector to the transceiver To remove the LC connector from the transceiver, follow the steps shown below: First, press the upper side of the LC connector from the transceiver and pull it out to release.
  • Page 21 Second, push down the metal loop and pull the transceiver out by the plastic part. Pull out from the SFP module Manual Documentation Number: EIR610-3SFP-T_0708M B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com B&B Electronics –...
  • Page 22 Mounting Installation DIN-Rail Mounting First, insert the top of DIN-Rail into the track. Manual Documentation Number: EIR610-3SFP-T_0708M B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com B&B Electronics –...
  • Page 23 Then, lightly push the button of DIN-Rail into the track. Ensure the DIN-Rail is tightly on the track. To remove the industrial switch from the track, reverse the steps above. Panel Mounting Follow the steps as below to mount the industrial switch with wall mount plate. Remove the DIN-Rail from the industrial switch.
  • Page 24 Hardware Installation Installation Steps 1. Unpack the Industrial switch. 2. Ensure the DIN-Rail is tightly screwed to the Industrial switch. If not, refer to DIN-Rail Mounting section for DIN-Rail installation. To panel mount the Industrial switch, refer to Panel Mounting section. 3.

  • Page 25: X-Ring Application

    5. Connect the fiber optic cables to the industrial switch and network device. Ensure that the switch’s fiber optic transmitter is connected to the network devices receiver and vice versa. 6. Connect the fiber optic cables. 7. When all the connections are made and the LEDs show normal indications, the installation is complete.

  • Page 26: Coupling Ring Application

    Coupling Ring Application If the network has more than one X-Ring group, the coupling ring function is used to connect them and add redundancy. This ensures that transmissions between the two ring groups will not fail. The figure below is an example of the coupling ring application.

  • Page 27: Console Management

    Console Management Connecting to the Console Port Attach the DB9 end to a PC or terminal and the RJ-45 end to the console port on the switch. The PC must have support a terminal emulation program. Pin Assignment DB9 Connector RJ-45 Connector Orange/White Orange Green/White...

  • Page 28: Login In The Console Interface

    Login in the Console Interface When the connection between Switch and PC is ready, turn on the PC, run a terminal emulation program or Hyper Terminal, and configure the following communication parameters: Baud Rate: 9600 bps Data Bits: 8 Parity: none Stop Bit: 1 Flow control: None The settings of communication parameters...

  • Page 29: Cli Management

    Console login interface CLI Management After you login to the system, you will see a command prompt. To enter CLI management interface, type ‘enable’ and press enter. CLI command interface Manual Documentation Number: EIR610-3SFP-T_0708M B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com B&B Electronics –...

  • Page 30: Commands Level

    Commands Level Access Exit Modes Prompt About This Mode1 Method Method The user commands available at the user level are a subset of Begin a those available at the Enter logout User EXEC session with switch> privileged level. or quit. your switch.

  • Page 31: Commands Set List

    command n mode, Ethernet ports. (with a enter exit. specific To exist to interface) privileged while in global EXEC configuration mode, or mode end. Commands Set List System Commands Set Commands Level Description Example show config Show switch switch>show config configuration show terminal Show console...
  • Page 32 [Gateway] ip dhcp Enable DHCP client switch(config)#ip dhcp function of switch show ip Show IP information of switch#show ip switch no ip dhcp Disable DHCP client switch(config)#no ip dhcp function of switch reload Halt and perform a cold switch(config)#reload restart default Restore to default switch(config)#default...
  • Page 33 Show configuration of switch#show dhcpserver show dhcpserver configuration DHCP server configuration show dhcpserver clients Show client entries of switch#show dhcpserver clients DHCP server show dhcpserver Show IP-Binding switch#show dhcpserver ip-binding information of DHCP ip-binding server no dhcpserver Disable DHCP server switch(config)#no dhcpserver function security enable...

  • Page 34: Port Commands Set

    Port Commands Set Commands Level Description Example interface fastEthernet Choose the port for switch(config)#interface [Portid] modification. fastEthernet 2 duplex Use the duplex switch(config)#interface [full | half] configuration fastEthernet 2 command to specify switch(config-if)#duplex full the duplex mode of operation for Fast Ethernet.
  • Page 35 Set interface ingress switch(config)#interface bandwidth type broadcast-multicast-floo limit frame type to fastEthernet 2 ded-unicast ‘accept broadcast, switch(config-if)#bandwidth type multicast, and flooded broadcast-multicast-flooded-uni unicast frame’ cast bandwidth type Set interface ingress switch(config)#interface broadcast-multicast limit frame type to fastEthernet 2 ‘accept broadcast and switch(config-if)#bandwidth type multicast frame’...

  • Page 36: Trunk Commands Set

    [Enable | Disable] configuration fastEthernet 2 command to specify (config-if)#state Disable the state mode of operation for Ethernet ports. Use the disable form of this command to disable the port. show interface show interface switch(config)#interface configuration configuration status fastEthernet 2 switch(config-if)#show interface configuration show interface status...

  • Page 37: Vlan Commands Set

    could be a port range(ex.1-4) or a port list separate by a comma(ex.2, 3, 6) [Workport]: The amount of work ports, this value could not be less than zero or be large than the amount of member ports. aggregator group Assign a static trunk switch(config)#aggregator group [GroupID] [Port-list]...
  • Page 38 Vlanmode To set switch VLAN switch(vlan)#vlanmode portbase [portbase| 802.1q | mode. gvrp] switch(vlan)#vlanmode 802.1q switch(vlan)#vlanmode gvrp no vlan No VLAN Switch(vlan)#no vlan Ported based VLAN configuration Add new port based switch(vlan)#vlan port-based vlan port-based grpname VALN grpname test grpid 2 port 2-4 [Group Name] grpid switch(vlan)#vlan port-based...

  • Page 39: Spanning Tree Commands Set

    Assign a hybrid link for switch(vlan)#vlan 8021q port 3 vlan 8021q port [PortNumber] VLAN by port, if the hybrid-link untag 4 tag 3,6,8 hybrid-link untag [UntaggedVID] port belong to a trunk group, this command switch(vlan)#vlan 8021q port 3 [TaggedVID List] can’t be applied.
  • Page 40 the interval between messages the spanning tree receives from the root switch. If a switch does not receive a bridge protocol data unit (BPDU) message from the root switch within this interval, it recomputed the Spanning Tree Protocol (STP) topology. spanning-tree Use the spanning-tree switch(config)#spanning-tree...
  • Page 41 forwarding. stp-path-cost Use the spanning-tree switch(config)#interface [1~200000000] cost interface fastEthernet 2 configuration switch(config-if)#stp-path-cost 20 command to set the path cost for Spanning Tree Protocol (STP) calculations. In the event of a loop, spanning tree considers the path cost when selecting an interface to place into the forwarding state.

  • Page 42: Qos Commands Set

    stp-admin-non-stp Admin NonSTP of STP switch(config)#interface [True|False] priority on this fastEthernet 2 interface. switch(config-if)#stp-admin-non-s tp False show spanning-tree Displays a summary of switch>show spanning-tree the spanning-tree states. no spanning-tree Disable spanning-tree. switch(config)#no spanning-tree QOS Commands Set Commands Level Description Example qos policy Select QOS policy switch(config)#qos policy...

  • Page 43: Mac / Filter Table Commands Set

    auto mode Igmp-query force Set IGMP query to switch(config)#Igmp-query force force mode show igmp Displays the details of switch#show igmp configuration configuration an IGMP configuration. show igmp multi Displays the details of switch#show igmp multi an IGMP snooping entries. no igmp Disable IGMP switch(config)#no igmp snooping function...

  • Page 44: Snmp Commands Set

    000012345678 no mac-address-table Remove an entry of switch(config)#no filter hwaddr MAC address table mac-address-table filter hwaddr [MAC] (filter) 000012348678 no mac-address-table Remove dynamic entry switch(config)#no of MAC address table mac-address-table SNMP Commands Set Commands Level Description Example snmp system-name Set SNMP agent switch(config)#snmp [System Name] system name...
  • Page 45 Privacy password [Group Name] password could be empty. [Authentication Password] [Privacy Password] snmpv3 access Configure the access switch(config)#snmpv3 access context-name [Context table of SNMPV3 context-name Test group G1 Name ] agent security-level AuthPriv group match-rule Exact views V1 V1 V1 [Group Name ] security-level [NoAuthNoPriv|AuthNoP...

  • Page 46: Port Mirroring Commands Set

    [User Name] of SNMPv3 agent. Test no snmpv3 access Remove specified switch(config)#no snmpv3 access context-name [Context access table of context-name Test group G1 Name ] SNMPv3 agent. security-level AuthPr group iv match-rule Exact views V1 V1 [Group Name ] security-level [NoAuthNoPriv|AuthNoP riv|AuthPriv] match-rule...

  • Page 47: 802.1X Commands Set

    Show port monitor switch(config)#interface show monitor information fastEthernet 2 switch(config-if)#show monitor no monitor Disable source port of switch(config)#interface monitor function fastEthernet 2 switch(config-if)#no monitor 802.1x Commands Set Commands Level Description Example Use the 802.1x global switch(config)# 8021x enable 8021x enable configuration command to enable 802.1x protocols.
  • Page 48 8021x system nasid Use the 802.1x system switch(config)# 8021x system [words] nasid global nasid test1 configuration command to change the NAS ID 8021x misc quietperiod Use the 802.1x misc switch(config)# 8021x misc [sec.] quiet period global quietperiod 10 configuration command to specify the quiet period value of the switch.

  • Page 49: Tftp Commands Set

    command to set the reauth period. 8021x portstate Use the 802.1x port switch(config)#interface [disable | reject | accept | state interface fastethernet 3 authorize] configuration switch(config-if)#8021x portstate command to set the accept state of the selected port. show 8021x Displays a summary of switch>show 8021x the 802.1x properties and also the port...

  • Page 50: Systemlog, Smtp And Event Commands Set

    SystemLog, SMTP and Event Commands Set Commands Level Description Example systemlog ip Set System log server switch(config)# systemlog ip [IP address] IP address. 192.168.1.100 systemlog mode Specified the log mode switch(config)# systemlog mode [client|server|both] both show systemlog Displays system log. Switch>show systemlog show systemlog Show system log client...

  • Page 51: Sntp Commands Set

    [Systemlog|SMTP|Both] event systemlog Set port event for switch(config)#interface [Link-UP|Link-Down|Bot system log fastethernet 3 switch(config-if)#event systemlog both event smtp Set port event for switch(config)#interface [Link-UP|Link-Down|Bot SMTP fastethernet 3 switch(config-if)#event smtp both show event Show event selection switch#show event no event Disable cold start switch(config)#no event device-cold-start event type...

  • Page 52: X-Ring Commands Set

    applied. sntp daylight-period Set period of daylight switch(config)# sntp [Start time] [End time] saving time, if SNTP daylight-period 20060101-01:01 function is inactive, 20060202-01-01 this command can’t be applied. Parameter format: [yyyymmdd-hh:mm] sntp daylight-offset Set offset of daylight switch(config)#sntp [Minute] saving time, if SNTP daylight-offset 3 function is inactive, this command can’t be...
  • Page 53 Enable X-ring switch(config)#Xring enable Xring enable Xring master Enable ring master switch(config)#Xring master Xring couplering Enable couple ring switch(config)#Xring couplering Xring dualhoming Enable dual homing switch(config)#Xring dualhoming Xring ringport Configure 1st/2nd switch(config)#Xring ringport 7 8 [1st Ring Port] [2nd Ring Ring Port Port] Xring couplingport...

  • Page 54: Web-Based Management

    Web-Based Management About Web-based Management The switch has an embedded HTML web site residing in flash memory. This site offers advanced management features and allows the switch to be configured from anywhere on the network. The web site is designed for Internet Explorer 6.0 and uses Java Applets to reduce bandwidth consumption, enhance access speed, and present an intuitive user interface.

  • Page 55: Main Interface

    The login screen will appear Enter the user name and password. The default user name and password are ‘root’. Press ‘Enter’ or ‘OK’, and then the home screen will appear. Login screen Main interface Main interface Manual Documentation Number: EIR610-3SFP-T_0708M B&B Electronics Mfg Co Inc –...

  • Page 56: System Information

    System Information System Name: A name (64 bytes max) can be assigned to the switch. System Description: Displays the description of switch. Read only cannot be modified System Location: A physical location (64 bytes max) can be assigned to the switch. System Contact: Enter the name of contact person or organization Firmware Version: Displays the switch’s firmware version Kernel Version: Displays the kernel software version...

  • Page 57: Dhcp Server - System Configuration

    IP configuration interface DHCP Server – System configuration The switch can function as a DHCP server. DHCP Server: Enable or Disable the DHCP Server function. Low IP Address: the dynamic IP assign range. Low IP address is the beginning of the dynamic IP assignment range. High IP Address: the dynamic IP assign range.

  • Page 58: Dhcp Client Entries

    DHCP Server Configuration interface DHCP Client Entries DHCP client information is displayed. DHCP Client Entries interface DHCP Server - Port and IP Bindings You can assign a specific IP address that is in the dynamic IP assignment range to the specific port. When the device is connected to the port and asks for an assignment, the system will assign this IP address.

  • Page 59: Tftp - Update Firmware

    Port and IP Bindings interface TFTP - Update Firmware Provides the ability to update the switch’s firmware. Before updating, ensure you the TFTP server is ready and the firmware image is on the TFTP server. TFTP Server IP Address: Enter the TFTP server IP. Firmware File Name: Enter the name of firmware image.

  • Page 60: Tftp - Restore Configuration

    TFTP – Restore Configuration If the EEPROM image is stored on the TFTP server, you can restore it to flash memory. TFTP Server IP Address: Enter the TFTP server IP. Restore File Name: Enter the restore file name. Click Apply Restore Configuration interface TFTP - Backup Configuration You can save current EEPROM image to the TFTP server.

  • Page 61: System Event Log - Syslog Configuration

    System Event Log – Syslog Configuration Syslog Client Mode: Select the system log mode – client only, server only, or both. System Log Server IP Address: Assigned the system log server IP. Click Reload to refresh the events log. Click Clear to clear all current events log.

  • Page 62: System Event Log - Smtp Configuration

    System Event Log - SMTP Configuration Set up the mail server IP, mail account, account password, and email account for receiving event alerts. Email Alert: enable or disable the email alert function. SMTP Server IP: set up the mail server IP address. Sender: Enter the email address, e.g.

  • Page 63: System Event Log - Event Configuration

    SMTP Configuration interface System Event Log - Event Configuration When the selected events occur, the system will generate a log entry and email notification message. . System event selection: Four selections available – Cold Start, Warm Start, SNMP Authentication Failure, and X-ring topology change. Mark the checkbox to select the event.
  • Page 64 Event Configuration interface Port event selection: When a port specific event occurs, the system will generate a log entry and email notification. Three selections are available – Link UP, Link Down, and Link UP & Link Down. Manual Documentation Number: EIR610-3SFP-T_0708M B&B Electronics Mfg Co Inc –...

  • Page 65: Fault Relay Alarm

    Fault Relay Alarm Power Failure: When the check box is marked, the Fault LED will light if the power source fails. Port Link Down/Broken: When the check box is marked, the Fault LED will light if a port link goes down. Fault Relay Alarm interface SNTP Configuration The SNTP allows you to synchronize switch clocks.
  • Page 66 Local Time Zone Conversion from UTC Time at 12:00 UTC November Time Zone - 1 hour 11am Oscar Time Zone -2 hours 10 am ADT - Atlantic Daylight -3 hours 9 am AST - Atlantic Standard -4 hours 8 am EDT - Eastern Daylight EST - Eastern Standard -5 hours...
  • Page 67 ZP4 – Russia Zone 3 +4 hours 4 pm ZP5 – Russia Zone 4 +5 hours 5 pm ZP6 - Russia Zone 5 +6 hours 6 pm WAST - West Australian +7 hours 7 pm Standard CCT - China Coast, +8 hours 8 pm Russia Zone 7...

  • Page 68: Ip Security

    SNTP Configuration interface IP Security IP security function grants 10 specific IP addresses permission to access the switch through a web browser or TELNET for management. IP Security Mode: When enabled, allows management via TELNET and HTTP. Enable HTTP Server: Mark the box to grant the specified IP addresses web based management permission.

  • Page 69: User Authentication

    IP Security interface User Authentication Use this function to change the login name and password. User name: Enter the new user name (The default is ‘root’). Password: Enter the new password (The default is ‘root’). Confirm password: Confirm the new password. Click Apply User Authentication interface...

  • Page 70: Digital Input/Output

    Digital Input/Output The EIR610-3SFP-T Managed Industrial Switch contains two digital outputs and two digital inputs. Outputs are open-collector transistor switches that may be controlled by the host computer. They provide messages, which can be applied to heaters, pumps, and other electrical equipment. The digital inputs may be read by the host computer and used to sense the state of a remote digital signal.

  • Page 71: Port Statistics

    Port Statistics Provides port status. Port: The port number. Type: Displays the connection speed. Link: Displays link status —‘Up’ or ‘Down’. State: Enabled or Disabled. Tx Good Packet: Displays the number of good packets transmitted. Tx Bad Packet: Displays the number of bad packets transmitted. Rx Good Packet: Displays the number of good packets received.

  • Page 72: Port Control

    Port Control Used to configure and view port settings. Port: Select the port to configure. State: Enable or disable the port. Negotiation: Set the negotiation status of the port. Speed: Set the port link speed. Duplex: Set the port to full or half-duplex. Flow Control: Set flow control to Symmetric or Asymmetric in Full Duplex mode.

  • Page 73: Port Trunk

    Port Trunk The Link Aggregation Control Protocol (LACP) provides a standardized method for exchanging information between Partner Systems on a link. This allows their Link Aggregation Control instances to reach an agreement on the identity of the Link Aggregation Group, move the link to that Link Aggregation Group, and enable its transmission and reception functions in an orderly manner.

  • Page 74: Aggregator Information

    Delete button to delete Trunk Group. Port Trunk—Aggregator Setting interface Aggregator Information Displays static trunk group information. Port Trunk – Aggregator Information interface Manual Documentation Number: EIR610-3SFP-T_0708M B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com B&B Electronics –...

  • Page 75: State Activity

    State Activity After setting up the LACP aggregator, port state activity can be configured. Mark the port and click . The port state activity will change to Active Apply or Passive depending on its previous state. Active: The port automatically sends LACP protocol packets. Passive: The port responds only if it receives LACP protocol packets from the opposite device.

  • Page 76: Port Mirroring

    Port Mirroring Port mirroring is a method to monitor traffic in switched networks. Traffic flowing through the indicated ports can be monitored by a specified port. Destination Port: Only one port can be selected as the destination (mirror) port for monitoring both RX and TX traffic from the source port. Two ports may be configured to monitor RX and TX traffic separately.

  • Page 77: Rate Limiting

    Rate Limiting Set up each port’s bandwidth rate and frame limitation type. Ingress Limit Frame type: Select the frame type to filter. There are four options: All, Broadcast/Multicast/Flooded Unicast, Broadcast/Multicast and Broadcast only. Egress Limit: The egress rate limit is ALL. Rate Limiting interface All the ports support port ingress and egress rate control.

  • Page 78: Vlan Configuration

    VLAN configuration A Virtual LAN (VLAN) can be thought of as a broadcast domain that exists within a switch or a defined set of switches. By grouping switch ports into VLANs, traffic flooding is limited since devices can only communicate directly with devices belonging to the VLAN.
  • Page 79 VLAN – Port Based interface Click to add a new VLAN group (The maximum number of VLAN Groups is 64) Entering the VLAN name, group ID and the members of VLAN group Click Apply Manual Documentation Number: EIR610-3SFP-T_0708M B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com B&B Electronics –...

  • Page 80: 802.1Q Vlan

    VLAN—Port Based Add interface The VLAN is displayed. Delete button to delete an unwanted VLAN. Edit button to modify an existing VLAN group. Note If the configuration is not saved, it will be lost when the switch is powered off. 802.1Q VLAN Tagged-based VLAN is an IEEE 802.1Q specification, which allows VLANs to be created across devices from different venders.
  • Page 81 802.1q VLAN interface 802.1Q Configuration Enable GVRP Protocol: check the check box to enable GVRP protocol. Select the port to configure. Link Type: there are three link types. Access Link: Single switch only. Allows ports to be grouped by setting the same VID. Trunk Link: Extended application of Access Link.
  • Page 82 6. Click Apply Group Configuration Edit the existing VLAN Group. Select the VLAN group in the table list. Click Apply Group Configuration interface The VLAN group name and VLAN ID can be changed. Click Apply Manual Documentation Number: EIR610-3SFP-T_0708M B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com B&B Electronics –...

  • Page 83: Rapid Spanning Tree

    Group Configuration interface Rapid Spanning Tree The Rapid Spanning Tree Protocol (RSTP) is an evolution of Spanning Tree Protocol (STP). It provides a faster spanning tree convergence after a topology change. The switch will auto detect a device that is running STP or RSTP protocol.
  • Page 84 Hello Time (1-10): The time that controls when, the switch sends out the BPDU packet to check RSTP status. Enter a value between 1 and 10. Forward Delay Time (4-30): the number of seconds a port waits before changing from its Rapid Spanning Tree Protocol learning and listening state to the forwarding state.

  • Page 85: Manual Documentation Number: Eir610-3Sfp-T_0708M

    RSTP - Port Configuration Configure path cost and priority of each port. 1. Select the port in Port column. 1. Path Cost: The cost of the path to the other bridge from this transmitting bridge at the specified port. Enter a number 1 through 200000000. 2.

  • Page 86: Snmp Configuration

    RSTP Port Configuration interface SNMP Configuration Simple Network Management Protocol (SNMP) is the protocol developed to manage nodes (servers, workstations, routers, switches, hubs, etc.) on an IP network. SNMP enables network administrators to manage network performance, find and solve network problems, and plan for network growth. Network management systems learn of problems by receiving traps or change notices from network devices implementing SNMP.

  • Page 87: Trap Configuration

    To remove the community string, select the community string and Remove click . The default community string cannot be edited. Agent Mode: Select the SNMP version that you want to use and click Change SNMP System Configuration interface Trap Configuration A trap manager is a management station that receives traps (the system alerts generated by the switch).

  • Page 88: Snmpv3 Configuration

    Trap Managers interface SNMPV3 Configuration Context Table Configure SNMP v3 context table. Assign the context name of context table. Click to add context name. Click Remove to remove an unwanted context name. User Profile Configure SNMP v3 user table. User ID: Enter the user name. Authentication Password: Enter password.
  • Page 89 SNMP V3 configuration interface Manual Documentation Number: EIR610-3SFP-T_0708M B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com B&B Electronics – Westlink Commercial Park – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445 – www.bb-europe.com...
  • Page 90 Group Table Configure SNMP v3 group table. Security Name (User ID): Assign the user name that was set up in the user table. Group Name: Enter the group name. Click Click to remove an unwanted context name. Remove Access Table Configure SNMP v3 access table.

  • Page 91: Qos Configuration

    QoS Configuration QoS Policy and Priority Type QoS Policy: select the QoS policy rule. Use an 8,4,2,1 weighted fair queuing scheme: The switch will follow 8:4:2:1 rate to process the priority queue from the highest to the lowest queue. For example, when processing, 1 frame of the lowest queue, 2 frames of the low queue, 4 frames of the middle queue, and 8 frames of the high queue will be processed at the same time.

  • Page 92: Port Base Priority

    QoS Configuration interface Port Base Priority Port: Each port has four priority levels – High, Middle, Low, and Lowest. Click Apply Manual Documentation Number: EIR610-3SFP-T_0708M B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com B&B Electronics –...

  • Page 93: Cos Configuration

    COS Configuration Set up the COS priority level. COS priority: Set up the COS priority level 0 to 7 –High, Middle, Low, Lowest. Click Apply TOS Configuration TOS priority: the system provides 0 to 63 TOS priority levels. Each level has four types of priority – high, middle, low, and lowest. The default value is ‘Lowest’.
  • Page 94 Message Description A message sent from the querier (IGMP router or switch) Query asking for a response from each host belonging to the multicast group. A message sent by a host to the querier to indicate that the host wants to be or is a member of a given group indicated in Report the report message.

  • Page 95: X-Ring

    X-Ring X-Ring provides network redundancy similar to the Spanning Tree and Rapid Spanning Tree Protocols. However, recovery time is greatly reduced when the X-Ring protocol is used. The protocol identifies one switch as the Ring Master. Packets are blocked from the redundant path unless a ring member becomes disconnected from the rest of the network.
  • Page 96 Ring Port fails, the system will automatically upgrade the 2 Ring Port to be the working port. Enable Coupling Ring: Mark the check box to enable the coupling ring function. Coupling port: Assign the member port. Control port: Set the switch as the master switch in the coupling ring. Enable Dual Homing: Set up one of port on the switch to be the Dual Homing port.

  • Page 97: Security

    Security In this section, you can configure 802.1x and MAC address table. 802.1X/Radius Configuration 802.1x is an IEEE authentication specification that allows a client to connect to a wireless access point or wired switch but prevents the client from gaining access to the Internet until it proves authority by providing a user name and password, which is verified by a separate server.
  • Page 98 802.1x System Configuration interface 802.1x Port Configuration You can configure 802.1x authentication state for each port. The State choices are Disable, Accept, Reject and Authorize. Use the ‘Space’ key change the state value. Reject: The port is held in the unauthorized state. Accept: The port is held in the Authorized state.
  • Page 99 802.1x Per Port Setting interface Misc Configuration Quiet Period: Sets the period during which the port does not try to acquire a supplicant. TX Period: Sets the period that the port waits before retransmitting the next EAPOL PDU during an authentication session. Supplicant Timeout: Sets the period the switch waits for a supplicant response to an EAP request.

  • Page 100: Mac Address Table

    Click Apply 802.1x Misc Configuration interface MAC Address Table Uses the MAC address table to ensure the port security. Static MAC Address You can add a static MAC address. This address remains in the switch's address table, regardless of whether the device is physically connected to the switch.
  • Page 101 MAC address and click Delete Static MAC Addresses interface MAC Filtering MAC Filtering interface MAC Address: Enter the MAC address that you want to filter. Click If you want to delete the MAC address from filtering table, select the Manual Documentation Number: EIR610-3SFP-T_0708M B&B Electronics Mfg Co Inc –...
  • Page 102 MAC address and click Delete All MAC Addresses Select the port. The selected port of static MAC address information is displayed. Click Clear MAC Table to clear the port static MAC address information on the screen. All MAC Address interface Manual Documentation Number: EIR610-3SFP-T_0708M B&B Electronics Mfg Co Inc –...

  • Page 103: Factory Default

    Factory Default This resets the switch to the default configuration with the option of retaining Reset the current IP address and user name/password. Click Factory Default interface Save Configuration Saves configurations made to the system. Click Save Save Configuration interface System Reboot Reboot the switch.

  • Page 104: Trouble Shooting

    Trouble shooting Verify that 12 to 48VDC power is available. Do not exceed 48VDC. Select the proper cable to construct your network. Use unshielded twisted-pair (UTP) or shield twisted-pair (STP) cable for RJ-45 connections: 100Ω Category 3, 4, or 5 cable for 10Mbps connections, 100Ω Category 5 cable for 100Mbps, or 100 Ω...

  • Page 105: Technical Specifications

    Technical Specifications IEEE 802.3 10Base-T IEEE 802.3u 100Base-TX IEEE 802.3ab 1000Base-T IEEE 802.3z Gigabit fiber IEEE 802.3x Flow Control and Back-pressure IEEE 802.3ad Port trunk with LACP Standard IEEE 802.1d Spanning Tree IEEE 802.1w Rapid Spanning Tree IEEE 802.1p Class of Service IEEE 802.1Q VLAN Tag IEEE 802.1x User Authentication (RADIUS) IEEE 802.1ab LLDP**...
  • Page 106 100Base-TX: 2-pair UTP/STP Cat. 5 cable EIA/TIA-568 100-ohm (100m) 1000Base-T: 2-pair UTP/STP Cat. 5e or 6 cable EIA/TIA-568 100-ohm (100m) LC (Multi-mode): 50/125um or 62.5/125um Optical cable LC (Single mode): 9/125um Back-plane 7.2Gbps Packet throughput 10.7Mpps at 64bytes ability 12 ~ 48 V Redundant power with polarity reverse protection and Power Supply removable terminal block...
  • Page 107 CE EN61000-4-4 (EFT) CE EN61000-4-5 (Surge) CE EN61000-4-6 (CS) CE EN61000-4-8 CE EN61000-4-11 CE EN61000-4-12 CE EN61000-6-2 CE EN61000-6-4 Safety CE/EN60950-1 IEC60068-2-32 (Free fall) Stability testing IEC60068-2-27 (Shock) IEC60068-2-6 (Vibration) Relay output for port breakdown and power source failure. Relay Alarm Alarm Relay Contact Rating: 1A @ 24VDC Contacts normally open Manual Documentation Number: EIR610-3SFP-T_0708M...
